Dodge 2009 Caliber Manual de usuario

CALIBER

Information is current as of September 1, 2009

www.media.chrysler.com

Note: Information shown is based on data available at time of publication (September 1, 2009).

Specifications are valid for Europe and may vary in other international markets. Vehicle model availability

may change per individual markets.

Dodge Caliber

SPECIFICATIONS

Dimensions are in millimeters (inches) unless otherwise noted.

GENERAL INFORMATION

Body Style

Five-door hatchback

Assembly Plant

Belvidere, Illinois

Vehicle Class

C-Segment

ENGINE: 2.2-LITER COMMON-RAIL DIESEL (CRD) DOHC 16-VALVE

Availability

Available on all Caliber models

Type and Description

Four cylinders in-line, turbocharged, high-pressure, direct injection

Displacement

2143 cu. cm (130.77 cu. in.)

Bore x Stroke

83 x 99 mm (3.27 x 3.90 in.)

Valve System

Chain Driven DOHC, 16-valve

Fuel Injection

Electronically controlled Delphi common rail system with high pressure

direct injection solenoid injectors

Construction

Cast-iron block, cast aluminum cylinder head, forged steel crankshaft

Compression Ratio

16.2:1

Power

120 kW (163 hp DIN) 3600 – 4200 rpm (74.0 hp DIN/L)

Torque

320 N•m (236 lb.-ft.) @ 1400 – 3600 rpm

Max. Engine Speed

5200 rpm (electronically limited)

Fuel Requirement

49 cetane diesel, DIN EN590

Oil Capacity

6.5 L (6.9 qt.) with dry filter

Coolant Capacity

9.35 L (9.9 qt.)

Emission Controls

Oxy-catalyst with Downstream Diesel-particulate Filter (DPF) and

cooled Exhaust-gas Recirculation (EGR)

Emission Class

Euro V

Fuel Consumption

Urban Cycle

TBD L/100 km

Ex-urban Cycle

TBD L/100 km

Combined Cycle

5.8 L/100 km (estimated)

CO2 (combined)

TBD g/km

CALIBER

Information is current as of September 1, 2009

www.media.chrysler.com

ENGINE: 2.0-LITER DOHC 16-VALVE I-4 WITH DUAL VVT

Availability

Available on all Caliber models

Type and Description

Four cylinders inline, tuned intake manifold with electronic Active

Charge Motion Control valves, dual counter-rotating balance shafts

Displacement

1998 cu. cm (121.9 cu. in.)

Bore x Stroke

86 x 86 mm (3.39 x 3.39 in.)

Valve System

Chain-driven DOHC, 16 valves, electronically controlled dual Variable-

valve Timing (VVT), direct-acting shimless mechanical bucket tappets

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

High-pressure die-cast aluminum block with dry iron liners,

cast-aluminum cylinder head, cast-aluminum ladder frame,

forged steel crankshaft

Compression Ratio

10.5:1

Power

115 kW (156 hp DIN) @ 6300 rpm (78 hp DIN/L)

Torque

190 N•m (140 lb.-ft.) @ 5100 rpm

Max. Engine Speed

6750 rpm (electronically limited)

Fuel Requirement

91 RON unleaded petrol

Oil Capacity

4.7 L (5.0 qt.)

Coolant Capacity

6.8 L (7.2 qt.)

Emission Controls

Single catalytic converter, dual heated oxygen sensors and

engine features

Emission Class

Euro IV

Fuel Consumption

Urban Cycle

10.1 L/100 km (5-mtx); 10.3 L/100 km (CVT)

Ex-urban Cycle

5.9 L/100 km (5-mtx); 6.7 L/100 km (CVT)

Combined Cycle

7.4 L/100 km (5-mtx); 8.0 L/100 km (CVT)

CO2 (combined)

176 g/km (5-mtx); 190 g/km (CVT)

ENGINE: 2.4-LITER, DOHC, 16-VALVE, VVT, SMPI I-4

Availability

Available on all Caliber SXT

Type and Description

Four-cylinders inline, tuned intake manifold with Electronic Active

Charge Motion Control valves, dual counter-rotating balance shafts dual

Variable-valve Timing (VVT)

Displacement

2360 cu. cm (144 cu. in.)

Bore x Stroke

88 x 97 mm (3.46 x 3.82 in.)

Valve System

Chain-driven DOHC, 16 valves, electronically controlled dual Variable-

valve Timing (VVT), direct-acting shimless mechanical bucket tappets

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

High-pressure die cast-aluminum block with dry iron liners,

cast-aluminum cylinder heads, cast-aluminum ladder frame,

forged steel crankshaft

Compression Ratio

10.5:1

Power

125 kW (170 hp DIN) @ 6000 rpm (70.8 hp DIN/L)

Torque

220 N•m (162 lb.-ft.) @ 4500 rpm

Max. Engine Speed

6400 rpm (electronically limited)

Fuel Requirement

91 RON unleaded petrol

Oil Capacity

4.7 L (5.0 qt.)

Coolant Capacity

6.8 L (7.2 qt.)

CALIBER

Information is current as of September 1, 2009

www.media.chrysler.com

Emission Controls

Dual catalytic converters, dual heated oxygen sensors and

engine features

Emission Class

Euro IV

Fuel Consumption

Urban Cycle

10.4 L/100 km (5-mtx)

Ex-urban Cycle

6.1 L/100 km (5-mtx)

Combined Cycle

7.7 L/100 km (5-mtx)

CO2 (combined)

182 g/km (5-mtx)

TRANSAXLE: T355 MAGNA DRIVELINE FIVE-SPEED MANUAL

Availability

Standard on Caliber with 2.0 L and 2.4 L

Description

Five-speed, overdrive, synchronized in all forward ratios,

cable-operated, three-plane shifter

Gear Ratios

1st

3.77

2nd

2.16

3rd

1.41

4th

1.026

5th

0.72

Reverse

3.417

Final-drive Ratio

4.12

Overall Top-gear

2.97

TRANSAXLE: AISIN BG6 SIX-SPEED MANUAL

Availability

Available with 2.2 L CRD engine

Description

Six-speed, overdrive, synchronized in all forward ratios,

cable-operated, 3-plane shifter

Gear Ratios

1st

3.54

2nd

2.05

3rd

1.37

4th

0.97

5th

0.90

6th

0.79

Reverse

3.83

Final-drive Ratio

4.06 (for gears 1–4), 3.45 (for gears 5th and 6th)

Overall Top-gear

2.73

CALIBER

Information is current as of September 1, 2009

www.media.chrysler.com

TRANSAXLE: AUTOMATIC, CVT2

Availability

Available with 2.0 L

Description

Continuously variable ratio, lockup torque converter, electronic controls

Gear Ratios

Forward

2.349:1 to 0.394:1 continuously variable

Reverse

1.75

Final-drive Ratio

6.12:1

Overall Top-gear Ratio

2.41:1

DRIVETRAIN

Front-wheel Drive

Availability

Standard

DIMENSIONS AND CAPACITIES (PRELIMINARY)(a)

Wheelbase

2635.0 (103.7)

Track, Front

1520 (59.8)

Track, Rear

1520 (59.8)

Overall Length

4414.8 (173.8)

Overall Width

1791.3 (70.5)

1983.3 (78.5) (including mirrors)

Overall Height (without roof rack)

1541.8 (60.7)

Ground Clearance

Front—208 (8.1); Rear—203 (7.9)

Fuel Tank Capacity, gal. (L)

51.5 (13.6)

Curb Weight, kg (lbs.)

(Base Vehicle shown)

2.2-liter CRD engine: 1514 (3338) – SE Model (6-mtx)

2.0-liter engine: 1360 – 1435 (2992 – 3157) – SE Model (5-mtx)

2.0-liter engine: 1360 – 1425 (2992 –3135) – SE Model (CVT)

2.4-liter engine: 1400 (3080) – SXT Model (5-mtx)

Gross Vehicle Weight, kg (lbs.)

2.2-liter CRD engine: 2010 (4431)

2.0-liter engine: 1950 (4290) (5-mtx)

2.0-liter engine: 1930 (4246) (CVT)

2.4-liter engine: 1930 (4246)

Maximum Trailer Mass (braked),

kg (lbs.)

2.0-liter engine: 1500 (3300)

2.4-liter engine: 1200 (2640)

2.2-liter CRD engine: 1500 (3300)

Maximum Trailer Mass (unbraked),

kg (lbs.)

450 (990)

Maximum Tongue Load, kg (lbs.)

80 (176)

Maximum Roof Rack Load, kg (lbs.)

68 (150)

(a) All dimensions measured at curb weight with standard 17-inch tires.

CALIBER

Information is current as of September 1, 2009

www.media.chrysler.com

ACCOMMODATIONS

Seating Capacity, F/R

2/3

Front

Head Room without Sun Roof

1012 (39.8)

Leg Room

1061.5 (41.8)

Shoulder Room

1407.8 (55.4)

Hip Room

1325.2 (52.2)

Seat Travel

Driver—260 (10.2), Passenger—260 (10.2)

Recliner Angle Range

Driver—up to 88°, Passenger—up to 76°

Rear

Head Room

988.2 (38.9)

Leg Room

906.1 (35.7)

Knee Clearance

18.6 (0.7)

Shoulder Room

1356.2 (53.4)

Hip Room

1260.8 (49.6)

DIN Cargo Volume, cu. m (cu. ft.)

.352 (12.43) (floor to ceiling, all seats up)

DIN Cargo Volume with seats folded,

cu. m (cu. ft.)

1.013 (35.7)

BODY

Layout

Transverse front-engine front-wheel drive

Construction

Unitized steel body

SUSPENSION

Front

Independent MacPherson strut, coil spring over gas-charged shock

absorbers and stabilizer bar—standard

Rear

Multi-link independent with coil springs, link-type stabilizer bar,

gas-charged shock absorbers—standard
