DMP Electronics NCBox-189 Manual de usuario

DM&P Group

NCBox-189 User’s Manual

NCBox-189 i

The information in this manual is subject to change without notice for continuous

improvement in the product. All rights are reserved. The manufacturer assumes no

responsibility for any inaccuracies that may contain in this document, and makes no

commitment to update or to keep current information contain in this manual.

No part of this manual may be reproduced, copied, translated or transmitted, in whole or

in part, in any form or by any means without the prior written permission of the DMP

Electronics Inc.

Manual No.: NCBox-189-01 Ver.1.0A 1st Issued Date: Aug.19, 2012

SPECIAL NOTICE TO USERS

DMP Electronics Inc. provides no warranty with regard to this manual, the software, or

other information contained herein and hereby expressly disclaims any implied

warranties of merchantability or fitness for any particular purpose with regard to this

manual, the software, or such other information. In no event shall DMP Electronics be

liable for any incidental, consequential, or special damages, whether based on tort,

contract, or otherwise, arising out of or in connection with this manual, the software, or

other information contained herein or the use thereof.

DMP Electronics reserves the right to make any modification to this manual or the

information contained herein at any time without notice. The software described herein

is governed by the terms of a separated user license agreement or label sticker.

This product contains software owned by DMP and licensed by third parties. Use of

such software is subject to the terms and conditions of license agreements enclosed

with this product. Software specifications are subject to change without notice and may

not necessarily be identical to current retail versions.

Updates and additions to software may require an additional charge. Subscription to

online service providers may require a fee and credit card information. Financial

services may require prior arrangements with participating financial institution.

TRADEMARKS ACKNOWLEDGMENT

The NCBox-189 is the registered trademarks of DMP Electronics Inc.

Other brand names, product names or trade names appearing in this document are the

properties and registered trademarks of their respective owners. All names mentioned

herewith are served for identification purpose only.

NCBox-189 ii

OWNER’S RECORD

The serial number of this product is located at the rear panel of your NCBox series.

Refer to the model and serial number when you contact your nearest dealer or DMP

offices for services.

SAFETY INFORMATION

WARNING

Do not expose NCBOX-189 to rain or moisture, in order to prevent shock

and fire hazard.

Never install NCBox-189 in wet locations.

Do not open the cabinet to avoid electrical shock. Refer to your nearest

dealer for qualified personnel servicing.

Never touch un-insulated terminals or wire unless your power adaptor and

display monitor are disconnected.

Locate NCBox-189 as close as possible to the socket outline for easy

access and to avoid force caused by entangling of your arms with

surrounding cables from the NCBox-189.

When using NCBox-189, avoid using or installing the modem to the serial

port during a storm or a lightning.

Do not use the modem or a telephone to report a gas leak in the vicinity of

the leak.

USB connectors are not supplied with Limited Power Sources.

DO NOT ATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS (ENCASING)OF

THIS PRODUCT.PLEASE CONTACT YOUR NEAREST DEALER FOR SERVICING FROM

QUALIFIED TECHNICIAN.

REGULATORY

ATTENTION

This product has been designed and certified to comply with certain regulatory

requirements pertaining to Information Technology Equipment. This product has not

been designed for use as a medical device. Without limitation of the foregoing, this

product is not intended and has not been certified for use in a hospital or clinical

environment to diagnose, treat, or monitor patients under medical supervision, and is

not intended and has not been certified to make physical or electrical contact with

patients, nor to transfer energy to or from patients and/or to detect such energy transfer

to or from patients.

NCBox-189 iii

PURCHASE AGREEMENT

PURPOSE:

In accordance to the general commercial conduct of Trust and Fair Trade, herewith

below is the agreement for the protection for both parties, DMP and Users in pursuant of

trading.

PRODUCT DESCRIPTION:

With this product, herewith also known as NCBox-189, which is a simplified & an

economical design of an embedded NCBox-189 for CNC machine. The basic

specification of this product comprises of the x86 technology design, and with VGA

display, USB, PS/2 Keyboard, Mouse, LAN, and Audio Interfaces.

DISTRIBUTION CONVENTION:

1. This Product includes a packing box, an inner case, a PC. Upon receiving this

product, kindly please refer to the User’ Manual to check for the contents and

appearance of this product; contact immediately your nearest dealer or DMP

office for any defective or missing parts. The supplier will not be responsible for

any reported discrepancy thereafter the expiration period of 3-days from the date

of purchase.

2. In consideration of transportation and the cost of storage, the supplier provides to

the distributors a warranty of 12-months. This warranty covers the failure caused

by hardware breakdown (excluding hard drives), but does not cover the act of

misuse and mishandling.

3. The supplier will not accept unknown post, therefore if you wish to repair or to

return your goods –kindly please contact your nearest dealer to make your

declaration, and at the same time, apply for a RMA number (RMA stands for

Return Merchandise Authorization –please see the RMA form and fill-up for

authorization).

4. The freight for return goods for repair will follow the International customary

practice and convention: Both parties is to pay for freight of one shipment each.

The shipper is required to prepay the freight from the place of origin (This means

that the returnee (user) covers the freight for return goods, while the Supplier

covers the freight for goods after the repair).

5. Obsolete warranty is referred to as: (1) Expiration of warranty or (2) Damage due

to misuse within warranty. The Supplier will be taken into consideration of the

circumstances, to provide repair service with charges expense for obsolete

warranty. This expense includes the cost of material and the cost of labor.

NOTE:

If there is other particular issue not listed in the above conditions, both parties agreed to

follow the General Law of Commerce with fair and reasonable discussion in handling

and resolving the argument.

NCBox-189 iv

Table of Contents

CHAPTERS –HEADING PAGE NO.

0–UNPACKING YOUR NCBOX........................................................................................ 1

PACKING LIST........................................................................................................1

CHECK BEFORE USE ..............................................................................................1

1–PREFACE ................................................................................................................. 2

2–NCBox-189 OVERVIEW ........................................................................................... 3

3–SYSTEM SPECIFICATION .............................................................................................4

4–BIOS........................................................................................................................5

RECONFIGURING NCBox-189 ...............................................................................5

5–TECHNICAL SPECIFICATION .......................................................................................6

6–TAKING CARE YOUR NCBOX .....................................................................................7

STORING ...............................................................................................................7

USING CABLES FOR CONNECTION .......................................................................... 8

CLEANING YOUR NCBOX....................................................................................... 8

7–TROUBLESHOOTING ...................................................................................................9

TROUBLESHOOTING YOUR NCBOX..........................................................................9

NCBOX DOES NOT START.......................................................................................9

BIOS ERROR MESSAGE .......................................................................................10

“OPERATING SYSTEM NOT FOUND”......................................................................11

WARRANTY :TERMS AND CONDITION ............................................................................ 11

1 WARRANTY .........................................................................................................11

2 SERVICE AND SUPPORT .......................................................................................11

3 RETURN MERCHANDISE AUTHORIZATION (RMA) POLICY .......................................12

4 SHIPPING POLICY.................................................................................................12

NCBox-189 1

UNPACKING YOUR NCBOX

Congratulation! You have just acquired NCBox-189, please check the following

items:

PACKING LIST FOR NCBox-189 SERIES

Item

Description

Q’ty



NCBox-189

* Note: The accessories are subject to change without immediate notice.

CHECK BEFORE USE

NCBox-189

Figure 1

NCBox-189 2

PREFACE

NCBox-189:

The NCBox-189 is a complete computer, which is especially designed for CNC machine

controller come with 2 parallel ports easy connect to your stepper driver, NCBox-189

support Microsoft Windows with the Mach3 CNC software and Linux with the LinuxCNC

software, makes your CNC machine easiest install and control.

NCBox-189 3

NCBOX-189 OVERVIEW

Front Panel

Power LED

The power LED lights up when system is

turn on.

CF LED

The CF LED flashes when the system is

working. Never turn off the power when

CF LED is still flashing.

CF Slot

The system is bootable from Compact

Flash Card.

2nd Parallel Port

2nd Parallel Port (Port 378)

USB port

For connection to devices with USB

interface (HDD, CD/DVD-ROM, Memory

Stick, etc.)

Back Panel

Power switch

DC Power In (8V-24V)

PS/2 Keyboard or Mouse (6-pin)

VGA

1st Parallel port (Port 278)

LAN

USB [ort

NCBox-189 4

SYSTEM SPECIFICATION

CPU

Vortex86MX+

Main Memory

1GB DDR2

BIOS

AMI BIOS

VGA

D-Sub 15Pin

Integrated Graphics Chip

Powere Input

DC 8V-24V

Keyboard and Mouse

PS/2 Keyboard and Mouse

Peripheral

1. USB V2.0 x 3

2. Type I/II CF Slot

3. Parallel port x 2

4. RJ-45 LAN

Dimension & Weight

115 x 115 x 35 mm / 505g

Operating System

Suitable for:

Windows XP

Windows Embedded Standard

Windows Embedded Compact

Linux

NCBox-189 5

BIOS

RECONFIGURING NCBox-189

1. Take note that AMI BIOS is used in the NCBox-189. To reconfigure the NCBox-

189, depress or hit the <Del> key to enter your BIOS setup main menu.

2. Select from the menu, the desired setup for change.

3. Press <Esc> to go back to main menu.

4. Move “Exit” TAB and select “Save Settings and Exit”, press “Y” to save the changes

that you just made. NCBox-189 will restart accordingly to your new setup.

(AMI BIOS Setup menu)

Tabla de contenidos

Otros manuales de De oficina de DMP Electronics

DMP Electronics

DMP Electronics DIN PC-333x Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-3310MX Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-333x Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-4300 Manual de usuario

DMP Electronics

DMP Electronics EBOX-ALN3350 Manual de usuario

DMP Electronics

DMP Electronics EBOX-58 Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-335xDX3 Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-3350EX Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-58 Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-336x Series Manual de usuario

DMP Electronics

DMP Electronics EBOX-335xDX3Series Manual de usuario

DMP Electronics

DMP Electronics eBox-2300 Manual de usuario

DMP Electronics

DMP Electronics eBox-2300SX Manual de usuario

DMP Electronics

DMP Electronics eBOX-3350MX series Manual de usuario

DMP Electronics

DMP Electronics eBox-3300 Manual de usuario

DMP Electronics

DMP Electronics EB-336x-L2851 Manual de usuario

DMP Electronics

DMP Electronics EBOX-ALN3350 Manual de usuario

DMP Electronics

DMP Electronics EBOX-333x Series Manual de usuario

DMP Electronics

DMP Electronics eBox-2300SX-NWP Manual de usuario

DMP Electronics

DMP Electronics EBOX-3350DX2-AP Manual de usuario

DMP Electronics

DMP Electronics EBOX-3100 Manual de usuario

DMP Electronics

DMP Electronics EBOX-336 Series Manual de usuario

DMP Electronics

DMP Electronics 3300MX 3300MX-M 3300MX-H 3300MX-C 3300MX-C22... Manual de usuario

DMP Electronics

DMP Electronics EBOX-IMX8MM Series Manual de usuario

Manuales populares de De oficina de otras marcas

HP m9060n - Pavilion - Elite Hoja de especificaciones

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

HP Presario SV7000 - Desktop PC Manual de usuario

HP ProDesk 400 G5 Manual

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario
