dji Snail Manual de usuario
DJI SNAIL
ESC Programmer
V1.0 2016.12
User Guide
使用说明
使用說明
ユーザーガイド
사용자 가이드
Bedienungsanleitung
Guía del usuario
Guide de l’utilisateur
EN
CHS
CHT
JP
KR
DE
ES
FR
Contents
User Guide 2
使用说明 7
使用說明 12
ユーザーガイド 17
사용자가이드 22
Bedienungsanleitung 27
Guía del usuario 34
Guide de l’utilisateur 39
Compliance Information 44
2
EN
Disclaimer
Thank you for purchasing the DJI™ Snail ESC
Programmer (hereinafter referred to as “product”).
Read this disclaimer carefully before using this
product. By using this product, you hereby agree to
this disclaimer and signify that you have read it fully.
Please install and use this product in strict accordance
with the User Guide. SZ DJI TECHNOLOGY CO.,
LTD. and its afliated companies assume no
liability for damage(s) or injuries incurred directly or
indirectly from using, installing or retting this product
improperly, including but not limited to using non-
designated accessories.
DJI is a trademark of SZ DJI TECHNOLOGY CO.,
LTD. (abbreviated as “DJI”) and its afliated
companies. Names of products, brands, etc.,
appearing in this document are trademarks or
registered trademarks of their respective owner
companies. This product and document are
copyrighted by DJI with all rights reserved. No part
of this product or document shall be reproduced
3
EN
in any form without the prior written consent or
authorization of DJI.
This disclaimer is produced in various languages.
In the event of divergence among different versions,
the Chinese version shall prevail when the product
in question is purchased in China, and the English
version shall prevail when the product in question is
purchased in any other region.
Warning
1. Before using the Snail ESC Programmer, always:
a. Remove the propellers or disconnect the ESC
and motors.
b. Disconnect all connected serial devices from
your computer.
2. Handle the Snail ESC Programmer with care,
particularly the exposed metal pins.
Introduction
The Snail ESC Programmer is compatible to the Snail
430-R Racing ESC. By connecting the 430-R ESC to
4
EN
PC430-R ESC ESC Programmer
1. Download and install DJI Assistant 2 from the
Ofcial DJI website.
(http://www.dji.com/snail/info#downloads)
2. Connect the ESC Programmer to the ESC with the
PWM signal cable and to your computer using
the USB cable on the programmer.
3. Connect a battery (3-4S LiPo) to supply power to
the ESC. Do not disconnect the ESC from your
computer or the power supply until conguration
is complete.
4. Launch DJI Assistant 2. When a connection is
your PC using Snail ESC Programmer, it is possible
to set parameters and update rmware through DJI
Assistant 2.
Using ESC Programmer
5
EN
established, the software will display the connected
devices. Use your DJI account to login.
5. Click Settings to set parameters.
6. Click the rmware update and select the version
you would like to update. DJI Assistant 2 will
automatically download and update the rmware.
Restart your ESC after the update is complete.
Ensure that your computer is connected to the
Internet during the update.
Ensure that the battery level is adequate for
the update.
DO NOT unplug the USB cable during the update.
Retry update if DJI Assistant 2 displays an
update failure prompt.
If the ESC is not recognized by the DJI ESC
Assistant, check if there is more than one
FTDI device connected such as another DJI
Updater or programmer, an FTDI USB adapter
or development board (e.g. a BeagleBone,
Raspberry or Arduino board). Unplug the other
FTDI devices. Restart the DJI Assistant 2 and
the ESC, and try again.
EN
Refer to the DJI Snail Racing Propulsion
System User Manual for more information.
Specications
Length (With Cables) 152mm
Weight 5.137g
Operating Temperature Range -10°~40℃
Thiscontentissubjecttochange.
Download the latest version from
http://www.dji.com/snail
DJIisatrademarkofDJI.
Copyright©2016DJIAllRightsReserved.
7
CHS
免责声明
感谢您购买 DJITM Snail 竞速多旋翼动力系统系列配
件。在使用 Snail 竞速多旋翼动力系统系列配件之前，
请仔细阅读本声明，一旦使用，即被视为对本声明全
部内容的认可和接受。请严格遵守说明安装和使用该
产品。因用户不当使用、安装、改装（包括使用非指
定的 DJI 零配件，如：电机、电调、螺旋桨等）造成
的任何损失，深圳市大疆 TM 创新科技有限公司及其关
联公司将不承担任何责任。
DJI 是深圳市大疆创新科技有限公司及其关联公司的
商标。本文出现的产品名称、品牌等，均为其所属公
司的商标或注册商标。本产品及说明为深圳市大疆创
新科技有限公司版权所有。未经许可，不得以任何形
式复制翻印。
关于不同语言版本的免责声明可能存在的语义差异，
中国以中文版为准，其他地区以英文版为准。
8
CHS
产品使用注意事项
1. 使用电调编程器前：
a. 建议断开电调与电机的连接。若未断开连接，
务必确保电机上的螺旋桨已拆下。
b. 移除计算机上的其他串口设备。
2. 使用时谨慎操作，避免接触外露的金属引脚。
简 介
Snail 电调编程器适配于 Snail 430-R 竞速电调，用于
连接 430-R 电调至计算机，以便通过 DJI Assistant 2
进行电调参数设置及固件升级。
使 用
计算机430-R 竞速电调 电调编程器
Otros manuales para Snail
5
Tabla de contenidos
Otros manuales de Accesorios para drones y cuadricópteros de dji
dji
dji ZENMUSE XT S Manual de usuario
dji
dji AGRAS T30 Manual de usuario
dji
dji Snail 6048-3D Manual de usuario
dji
dji Snail Manual de usuario
dji
dji GOGGLES Racing Edition Manual de usuario
dji
dji E-Port Development Lit Manual de usuario
dji
dji ZENMUSE H20T Manual de usuario
dji
dji FPV GOGGLES Manual de usuario
dji
dji 1345 Instrucciones de funcionamiento y mantenimiento
dji
dji BTU Manual de usuario
dji
dji SNAIL 2305 Manual de usuario
dji
dji Ronin Series Battery Power Distributor Manual de usuario
dji
dji DL LENS Manual de usuario
dji
dji Zenmuse X9 Manual de usuario
dji
dji E5000 ADVANCED Manual de usuario
dji
dji 5048S Manual de usuario
dji
dji FC7BMC Manual de usuario
dji
dji MATRICE 300 RTK Manual de usuario
dji
dji Motion Controller Combo Manual de usuario
