USER MANUAL
2023.06
80” Floor Standing LED Poster
2.5mm Pixel Pitch
SKU: DF080NVB2
Scan QR code to visit
the product page:
1. Preface
1.1 Introduction
1.2 Safety Notice
1.3 Certification
1.4 GOB LED Modules
2. Product Introduction
2.1 Overview
2.2 Features
2.3 Specifications
3. Packing List
4. I/O Interface Instruction
5. Assembly Instructions
Contents
6. System Connection Instructions
6.1 System Connection Diagram of Single LED Poster 6.2
Startup instructions
7. Content Management & Publish
7.1 Publish via PC
7.2 Publish via Phone APP
7.3 Publish via USB
8. Connecting Multiple Posters
8.1 Connect up to 4 Units (Daisy Chain)
8.2 Displaying Content Across Multiple Screens
9. Common Faults and Trouble Shooting
2
1.1 Introduction
1) This manual is for 2.5-80” LED poster. For better application, this manual systematically introduces the product make up, interface,
specification, also the installation, wiring and content publish function.
2) Software instructions are based on built-in Nova T6 player and not applicable to other players.
1.2 Safety Notice
1. Preface
Warning！Warning！Warning！Warning！Warning！Warning！
Safety risk may
result in equipment
damage or security
issues.
Please
read this manual
before operation.
Incorrect voltage may
result in equipment
damage.
Please pay attention to
protective measures to
prevent any danger
Inflammable Harmful to eyes
The picture can't be displayed.
3
Warning! Please read below safety instructions before installation, power-on, operation and testing
Please read below safety instructions before installation, power-on, operation and testing;
Make sure to follow the safety instructions. For any questions, please contact us for assistance.
•Due to flame, electric shock, fall down, this product may cause injury to person, even death;
•This product is not suitable for swimming pools, sauna, bathroom and other humid environments;
•This product is non-waterproof, or cannot be used in complete outdoor environments;
•Please do not block the ventilation holes during operation;
•Please take moisture-proof measures when packing and stocking;
•Please do not drop, strike, scratch, warp or shake LED display or external equipment;
•Please make sure the front protection panel out of scratch with hard objects;
•Please make sure the product is operated under professional staff due to inside strong current;
•please make sure the ground is flat and even before placing the product;
4
•Please make sure this product grounded correctly to ensure safety and prevent electrical shock;
•Please cut off in thunderstorm weather or make sure taking lightning strike protection measures. Please cut off if no
long no use;
•Please cut off display power under situations of unused, disassemble, installation, maintenance;
•Please make sure the AC power meets local building & electrical standards and equipped with overload and ground
faulty protection;
•Please make sure and check electricity, cable and all connected equipments meet current requirements before using
this product;
•make sure power cable no broken, aging, humility. Please replace with a new one if any over-heat situation happens;
•Please make sure the product is operated by professional personnel due to inside strong current; for any questions,
please consult with professional personnel;
•Please take eye-protection measures and do not watch the screen directly when screen is at 100% brightness;
•Please do not use any optical devices with concentrated function to watch the screen in case of eye burn;
5
Warning: Manufacturer is not responsible for any incorrect, improper, irresponsible or unsafe
operations.
•Please make sure screen, processor and power with good heat ventilation, at least 4 inches distance from other
stuff;
•Please do not stick any objects on screen;
•Please do not refit the product and add new parts;
•Please do not exposure the product to sun, make sure the environment is less than 45 degrees;
•Please wear a helmet to prevent body injury;
•Please make sure any fixed and connected structures meet safety standards;
•Please hold the screen firmly when joint units to prevent drop or tip-over;
•Please make sure the ground is flat and even before placing the product.
6
1.3 Certification
The product has passed FCC, UL, CE and RoHS certification to meet international standards.
7
1.4GOB LED Modules
Gob Led Display is an LED Display with a glue on board (GOB) technology. This innovative
technology seals the module surface with transparent epoxy glue. This protects the LED from
any harmful accidents by making it anti-collision, waterproof, anti-UV and dust proof. The
lifespan of these LEDs is also extended due to heat dissipation caused by shield glue. GOB
technology also protects the LED from breaking as a result of any sudden accidents such as
dropping it during installation or delivery.
2. Product Introduction
2.1 Overview
•Easy operation, multiple communication modes, high brightness, low power
consumption and ultra-thin body to ensure stable and high-quality display effect
even in bright-light venues.
•It is a new product that overturns traditional LCD player (high cost, low-quality
picture, uneven brightness, heavy body and high energy consumption), which can be
installed in hotels, restaurants, shopping malls, banks, government agencies,
hospitals and so on.
2.2 Features
Features:
•Super slim in width and light in weight.
•Plug-in display, simple operation.
•USB/WIFI/HDMI/ CAT5E cable connection & PC quick management & publish.
•LAN integrated publish & remote publish via internet.
•Calibration data is saved in modules, recover factory settings in 5s. 8
2.3 Specifications
1）Display 25.5 in
79 in
2.25 in
Overall Dimensions:
(W×H×D):
25.5×76×16.5 in (LED poster)
25.5×79×16.5 in (with base)
9
16.5 in
24.5 in
2.3 Specifications
2）Main parameters
2.5-80“ LED Poster
Optical
Parameters
Pixel Pitch (mm) 2.5
LED Type SMD
Viewing Angle (H/V) 140° / 140°
Brightness(cd/m2.) ≥900 nits (±10%)
Refresh Rate(Hz) 3840 Hz
Optimized Viewing Distance (feet) ≥20’ +
Electrical
Parameters
Average Power Consumption (W/unit) 250
Max. Power Consumption (W/unit) 650
Input Voltage AC100-240V~(+/-10 %) 50/60Hz
Input Interface
USB x1, HDMI In x 1, HDMI OUT x1,
LAN x1, Audio x1 , WiFi, Ethernet
Structure
Parameters
Module Resolution (dots) 256 dots x 768 dots
Module Size in mm (W×H) 320 mm x 160 mm
Display Area in inches (W×H) 25.25” x 75.5”
Cabinet Size in inches (W×H×D) 25‘’ W x 75.5‘’ H x 2.3‘’ D
Overall Dimension in inches (W×H×D) 25‘’ W x 78‘’ H x 16.5‘’ D
Weight (kg/unit) 103 lbs.
IP Rating IP43
Operation
Parameters
Operating Temperature/ Humidity（°F/RH）14°F~104°F/10~85RH%
Certification CE / UL / FCC / RoHS 10
