DirecTV HD DVR Manual de usuario

RECORD

quick START Guide Hd dVR

0806HR20

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in





























Welcome to the DIRECTV Plus® HD DVR. Now that you’re plugged in, it’s

time to start enjoying the new world of high-denition entertainment

at your convenience. This Quick Start Guide will take you step by

step through everything from pushing the power button to recording

your favorite programs. Getting started will only take a few minutes,

but it will change the way you watch TV forever. Once you’re up and

running, be sure to check out the DIRECTV Plus HD DVR User Guide

for more information on the many features of your new HD DVR.

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in









Set the MODE switch on the remote control to the DIRECTV

position, then press PWR.





Once your DIRECTV Plus® HD DVR system is properly connected, you’re ready to

begin watching TV in a whole new way.



If you are adding the HD DVR to your existing

DIRECTV® System, you’ll use the same

easy, convenient interface you’re already

accustomed to. Your Quick Menu and Guide

features will operate in the same way.

If you are a new DIRECTV customer, you can

access the Quick Menu by simply pressing the

MENU button on your remote. To access what

is showing on DIRECTV, press GUIDE twice.

To learn more, refer to the DIRECTV Plus

HD DVR User Guide you received from your

installer. Press EXIT to leave any screen and

return to watching TV.





All trademarks shown are used with permission of their respective owners.

NASCAR® is a registered trademark of the National Association for Stock Car Auto Racing, Inc.

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in









When you use the DVR control buttons, the control bar appears as a quick

reference that shows you information about the current program, including

title, progress, start time and how much of the program has been stored.



The features of your new HD DVR system will change the way you watch TV forever. You’ll be able to do

amazing things that will greatly enhance your viewing experience of live programs as well as everything

you record. Just push the DVR control buttons indicated below to use the associated features.





Starts the recorded video or paused live TV

currently on screen. Hold this button down

for slow motion.



Freezes the action of any live or

prerecorded television program. While

paused, press FFWD or REW to move

forward or backward frame by frame.



Fast-forwards recorded or live-stored

video. Press up to three times to fast-

forward at increasing speeds. (Pressing

play returns to normal play.)



Rewinds recorded or live-stored video.

Press up to three times to rewind at

increasing speeds. (Pressing play returns

to normal play.)



Automatically records live TV. (One-touch

record works on highlighted programs in

the Guide and live TV.)



While watching recorded TV, pressing this

stops playback, inserts live TV in the top

right and gives options to keep, delete or

record other episodes of your recorded show.



Jumps the program you’re watching

backwards 6 seconds and starts playing

from that point. Holding down REPLAY

jumps to the beginning of the program.



Jumps ahead in recorded or live-stored

video by 30 seconds. Hold down to continue

to the end.







DVR CONTROL BUTTONS

FPO

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in







 





Want to know how to record and watch recorded shows with your new DIRECTV Plus®

HD DVR? It’s easy, and we’ll show you how. Let’s get started.

If you would like to record a second program at the same time, simply select that program

from the Guide or tune to it and repeat the steps above. If you wish to watch a different

program while recording, you can go to another channel.

You can record up to 2 programs at once. (Requires connection of 2 satellite inputs from a

multiple-LNB DIRECTV® System antenna.)

To record the program

you’re watching, simply

press the RECORD button

once on your remote.

If you press the

RECORD button a

second time while

watching a program,

the Onscreen Display

will give you the ability

to KEEP RECORDING,

STOP & KEEP or STOP

& DELETE.





T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in



 

 









To nd a program

you’d like to record,

press the GUIDE

button twice to see

what’s playing.

Use the ARROW

buttons to highlight

the show, then press

RECORD. The Record

Icon will appear.







NOTE: If you’re watching a show that is not part of a series (a movie, a sporting

event, the news), pressing RECORD a second time will cancel the recording.



Find the show you’d like

to record in the Guide.

Highlight the show and

press RECORD.

For programs that run

in episodes, once you

choose a show to record,

you can press RECORD

a second time. This will

enact the Series Link™

feature, which will

record every episode

of your show on this

channel, even if the

time slot changes.

Press RECORD

a third time to

cancel the recording.







FPO

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in







 





To bring up the Quick

Menu options while

watching live TV, press

MENU on your remote.

Use the black ARROW

buttons to highlight

SEARCH in the Quick

Menu. Then press

SELECT.

Once you’ve selected a

search by title, person,

keyword or channel, you

can highlight a show to

display the program’s

information. Press

RECORD to record it.









Press LIST to access the

shows you’ve already

recorded in your Playlist,

or MyVOD.

™

Use the black ARROW

buttons to select the

show you want to watch,

then press PLAY.

If you would like to

delete a show, use the

ARROW buttons to nd

the program, then press

the DASH button twice

to delete.







T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in







 





Press LIST to access

shows you have already

recorded.

Press the YELLOW

button to bring up your

To Do List.

Navigate the Onscreen

list using the ARROW

buttons to see the

programs you are set

to record.







NOTE: You can use the BACK button to return to a previous screen.

Your To Do List is the list of programs you are set to record. It will list each program

separately and show you when these programs will be recorded.



Press LIST to get to your

Playlist. Then press the

YELLOW button and use

the ARROW buttons to

highlight the show you

want and press SELECT.

Highlight RECORD in

the onscreen menu and

press SELECT.

Use the ARROW and

SELECT buttons to scroll

through the menus and

choose your options,

like whether to start

recording 10 minutes

early or stop recording

5 minutes later. After

changing recording

options, highlight UPDATE

and press SELECT.







When you record a show, you want to record it in its entirety. But sometimes,

networks begin their broadcasts early. Or, the big game goes into overtime.

We’ve made it easy to change your recording options so you don’t miss a minute.

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in

Visit directv.com/hddvr for more information.

KNOWING YOUR DIRECTV PLUS® HD DVR

WATCHING TV RECORDING PROGRAMS KNOWING YOUR HD DVR

INFO

Channel Banner

When you tune to a channel, the Channel

Banner appears across the top of the screen,

displaying the channel and program you are

currently watching. The Channel Banner will

also appear if you press the INFO button.

Quick Menu

The Quick Menu lets you easily access DIRECTV

features relevant to live TV or any screen you

are currently viewing, such as the Guide. To

access the Quick Menu, press the MENU button.

Onscreen Guide

The Guide displays listings of current and

upcoming programs for up to 14 days in

advance. The top right corner shows what’s

playing on live TV. With one press, the RED and

GREEN buttons in the Guide allow you to skip

forward or backwards by 12 hours. Press the

GUIDE button on your remote to display the Guide.

The Mini Guide

The Mini Guide is a special version of the Guide

that displays only one channel at a time, allowing

you to watch live TV in full screen. Bring up the

Mini Guide by pressing the BLUE button.

DIRECTV PLUS® HD DVR FEATURES

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in

KNOWING YOUR DIRECTV PLUS® HD DVR

WATCHING TV RECORDING PROGRAMS KNOWING YOUR HD DVR

Visit directv.com/hddvr for more information.

FINDING ADDITIONAL INFORMATION

Onscreen Assistance

Selecting HELP & SETTINGS in the Quick

Menu displays a submenu of items that lets

you customize, adjust and keep track of your

DIRECTV viewing experience.

Customer Service

If you need further assistance, you can

visit directv.com/hddvr for FAQs, Technical

Troubleshooting, Help Forums and Demos.

Or call us at 1-800-531-5000.

The purpose of this Quick Start Guide is to help you start using your DIRECTV Plus®

HD DVR right away. But you may need more details to fully take advantage of all the

features and capabilities now available to you.

Please refer to your DIRECTV Plus HD DVR User Guide for complete instructions

and in-depth information on your new HD DVR system.

INFO

Search for Programs

The Search feature allows you to nd a program by

title, person, keyword or channel. Press the MENU

button, highlight SEARCH in the Quick Menu and

then push SELECT.

Recording Programs

With your DIRECTV Plus HD DVR, you can record

up to two programs at once. To record a program,

either press the RECORD button while watching

live TV or highlight a program in the Guide and

press RECORD. To learn more, reference the

Recording Programs section on page 6.

Playlist

You can access the list of programs you’ve

recorded by pressing the LIST button on your

remote. Your programs are displayed under the

MyVOD™ tab. To see which programs you are set to

record, press the YELLOW button to view your To

Do List. You may SELECT the Showcases tab to see

special programming from DIRECTV.

DIRECTV PLUS® HD DVR FEATURES (CONTINUED)

Visit directv.com/hddvr for more information.

T: 15 in

T: 9.75 in

F: 7.5 in F: 7.5 in

Otros manuales para HD DVR

Tabla de contenidos

Otros manuales de DVR de DirecTV

DirecTV

DirecTV R10 Manual de usuario

DirecTV

DirecTV DVR39 Manual de usuario

DirecTV

DirecTV Wireless Genie Mini Documento técnico

DirecTV

DirecTV HR20 Manual de usuario

DirecTV

DirecTV HR21700 Manual de usuario

DirecTV

DirecTV HR10-250 Manual de usuario

DirecTV

DirecTV HD DVR PRO Manual de usuario

DirecTV

DirecTV Genie Mini Documento técnico

DirecTV

DirecTV HD DVR Manual de usuario

DirecTV

DirecTV Genie Manual de usuario

DirecTV

DirecTV R16-300 Manual de usuario

DirecTV

DirecTV TCD2 Series Guía de inicio rápido

DirecTV

DirecTV R10 Manual de usuario

DirecTV

DirecTV Genie 2 Documento técnico

DirecTV

DirecTV HR22 Manual de usuario

DirecTV

DirecTV HR23 Manual del propietario

DirecTV

DirecTV PLUS DVR Manual de usuario

DirecTV

DirecTV HR20QSG0806 Manual de usuario

DirecTV

DirecTV HR10-250 Manual de usuario

DirecTV

DirecTV Plus HD Manual de usuario

DirecTV

DirecTV HD DVR Manual de usuario

DirecTV

DirecTV R16NC-500 Manual de usuario

DirecTV

DirecTV TiVo TCD24 Series Guía de inicio rápido

DirecTV

DirecTV PLUS DVR - MANUEL 2 Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
