Diono Cambria Manual de usuario

Instruction Manual

ENGLISH

Failure to follow all written instructions and product labels can result in death or serious

injury in a crash. Carefully read and understand this instruction manual prior to using this

restraint. If you have any questions visit diono.com or contact Diono LLC. To insure proper

long-term use, store this manual under the bottom of the base.

•Use only with children whose height is between 38”and 63” and whose

weight is between 40 lbs and 120 lbs.

•Only use this restraint forward-facing.

•Use only the vehicle’s lap and shoulder belt system when restraining

the child in this booster seat.

•NEVER use with only a vehicle lap belt to restrain a child. This could

result in serious injury or death to a child.

•Some vehicle seat belt systems cannot be used with this booster seat.

Read vehicle owner’s manual and ‘Vehicle Seat Belt Systems’ section of

this manual.

•DO NOT use this booster seat without the backrest unless there is

vehicle headrest for that seating position.

•DO NOT use this booster seat without the backrest unless proper

vehicle seat belt placement can be achieved.

•DO NOT use this booster seat with any other backrest or cushions.

•To prevent injury due to product deterioration, do not use this booster seat if it has been

involved in a severe accident or if it is older than ten years.

WARNING !

Death or SERIOUS INJURY can occur.

•Never leave a child alone in a vehicle, even for a short time.

•Always secure this booster seat using vehicle seat belt or LATCH anchors even when not

occupied. In a crash, an unsecured item may cause injury to other vehicle occupants.

•Except as described in this manual, do not dissemble or modify any part of this booster

seat or vehicle seat belt.

•Register your child restraint with the manufacturer.

•Do not place anything under the booster seat to raise it o the vehicle seat.

•This restraint is not a toy. Do not let a child play with it.

•Do not leave folding vehicle seats unlatched. In the event of a sudden stop, a loose seat

back could prevent the booster seat from protecting the child as well as it should.

•In the event of an accident, the vehicle body itself provides the most signicant

passenger protection. While a properly installed restraint will improve chances for

survival in most accidents, a booster seat will not protect a child if the vehicle is too

severely impacted.

•Follow all instructions on this child restraint and in the written instructions. To insure

proper long term use, store this manual under the bottom of the base.

WARNING !

Death or SERIOUS INJURY can occur.

•According to accident statistics, the National Highway Transportation Safety Adminis-

tration (NHTSA) recommends that parents select the rear seat as the safest location to

properly install a booster seat. Please read carefully the section concerning vehicle

seat belts in this guide to insure the child’s safety. If in doubt about installing this

booster seat, please consult the vehicle owner’s manual.

WARNING: DO NOT place a child

restraint in the front seat of a

vehicle with a passenger air bag

unless the air bag is turned oﬀ.

DEATH or SERIOUS INJURY can

occur. The back seat is the safest

place for children under 12.

IMPORTANT: Children who weigh 40 lbs (18 kg) or less are best protected in a 5-point

harness restraint. Diono recommends that children remain in a 5-point harness restraint

until reaching the maximum weight or height allowed.

• If the child will not keep the vehicle shoulder belt properly positioned at all times, DO

NOT use a booster seat. You must use a harnessed child restraint.

•Maximum Child Height: Child is too tall if the top of the ears are above the top of

either the fully raised booster seat headrest or fully raised vehicle headrest.

WARNING !

Death or SERIOUS INJURY can occur.

Safety Information

GENERAL

• Cover this booster seat if vehicle is left in direct sunlight. Portions of the booster seat

can become hot enough to burn a child and cover fabric can become faded.

• Store this booster seat in a safe place when not in use. Do not store near direct heat

source or place heavy objects on top of it.

• Always make sure vehicle seat is locked in its upright position. Reclining the vehicle

seat will adversely aect the safety and performance of the child seat in an accident.

CERTIFICATION

This child restraint system conforms to all applicable Federal Motor Vehicle Safety

Standards. This restraint is not certied for use in aircraft. Lap belts in aircraft cannot

be used safely with this booster seat.

REGISTRATION

Visit www.diono.com to register your restraint online. Child restraints can be recalled

for safety reasons. You must register this restraint to be reached in a recall. Send your

name, address and this restraint’s model and serial number and manufacturing date to

Diono LLC, 418 Valley Avenue NW, Puyallup, WA 98371, or call 1-855 GO DIONO. For

recall information call the U.S. Government’s Vehicle Auto Safety Hotline at 1-888-327-

4236 (TTY 1-800-424-9153) or go to www.nhtsa.gov.

Safety Information (continued)

VEHICLE SEAT BELT SYSTEMS

IMPORTANT: Some vehicles have no seating positions compatible with booster seats. If in

doubt, please contact the vehicle manufacturer for assistance.

WARNING: ONLY use this booster seat with a 3-point

(lap-and-shoulder) vehicle seat belt that is NOT

motorized or anchored to the vehicle door.

In order to protect a child in an accident, this booster must be used with a compatible

vehicle seat belt.

The following seat belt types are NOT compatible with this booster seat:

• Two-point seatbelts of any kind.

• Three-point seat belts with separate retractors for lap and

shoulder sections.

• Motor-driven, automatic seat belts.

• Seat belts with anchorage points on the door.

The vehicle owner’s manual will

have complete information on the

types of seat belts in the vehicle. If

the seat belt type is listed above,

choose another seating position in

the vehicle.

VEHICLE SEATING POSITIONS

Diono and the U.S. Department of Transportation warn that children under 12 must ride in

the rear seats and away from front airbags. The only exception is if the airbag is turned o.

When using a vehicle with airbags, refer to the vehicle owner’s manual for additional

booster seat installation instructions and precautions.

WARNING: Only use this booster seat in forward-

facing vehicle seats. DO NOT use this booster seat in

side-facing or rear-facing seats in vans or station

wagons.

Seats which face

sides of vehicle. Seats which face rear of vehicle.

CUP HOLDERS

Cup holders are located on both sides of seat bottom: swivel

outward to the locked position for use. Swivel inward to the

recessed and locked position when not in use.

IMPORTANT: Do not step on or put excess weight on cup

holder which could cause it to break.

CAUTION: DO NOT use with hot liquids as this could burn a child.

Head

support

adjuster

Upper

belt

guide

Instruction

manual

LATCH

adjuster

straps

LATCH

connectors

Cup

holder

Lower

belt guide

Parts for Assembly & Installation

Booster Seat Assembly

ATTACHING THE BACKREST

1Lay backrest on at surface with front

facing down. •

2Hold seat bottom facing down. Align

seat bottom pivot bar at 90oangle with

backrest hooks. Push in to attach seat

bottom to backrest. •

3Rotate seat bottom downwards and

under back rest until a‘click’ is heard and

the seat shape is formed. •

REMOVING THE BACKREST

Follow above instructions in reverse.

ADJUSTING THE HEADREST

Squeeze the red head support adjuster on back

of booster seat head rest while adjusting its

height up or down to t the child.

LATCH Installation

To improve safety and performance, this booster seat is equipped with a unique, LATCH

system that allows secure attachment to a vehicle’s lower LATCH anchor locations.

Disengage LATCH connectors from storage slots and lay booster seat on its side.

1While depressing the cam lock lever,

2pull LATCH connectors away from the booster seat and

extend both straps all the way.

3Attach both LATCH connectors to the vehicle anchors,

starting with the connector that is furthest from you. For ease

of use, make sure open end of hooks face upward during use.

4While pushing booster against vehicle seat,

5pull one adjuster strap tight and

then the other.

NOTE: Even with LATCH properly attached and

adjusted, child seat will still have movement against

the vehicle seat back and bottom.

WARNING: Unsecured objects can become ﬂying

hazards and can cause serious injury in an accident.

Diono always recommends utilizing LATCH

installation in vehicles equipped with lower anchors.
