DAG1000-1S/2S/4S User Manual

DAG1000-1S/2S/4S Analog Telephone Adapter

User Manual V1.0

Dinstar Technologies Co., Ltd.

Address: 9th Floor, Guoxing Building, Changxing Road, Nanshan District, Shenzhen, China

Postal Code: 518052

Telephone: +86 755 61919966

Fax: +86 755 2645 6659

Emails: sales@dinstar.com, support@dinstar.com

Website: www.dinstar.com

DAG1000-1S/2S/4S User Manual

Preface

Welcome

Thanks for choosing the DAG1000-1S/2S/4S Analog Telephone Adapter for VoIP! We hope

you will make full use of this rich-feature analog telephone adapter (ATA). Contact us if you

need any technical support: 86-0755-26456110/112.

About This Manual

This manual provides information about the introduction of the analog telephone adapter, and

about how to install, configure or use it. Please read this document carefully before install the

ATA.

Intended Audience

This manual is aimed primarily at the following people:

Users

Engineers who install, configure and maintain the ATA.

Revision Record

Document Name

Document Version

Firmware Version

DAG1000-1S/2S/4S Analog Telephone

Adapter User Manual V1.0

V1.0 (2016/12/12)

2.19.10.01

Conventions

ATA or device mentioned in this document refers to the DAG1000-1S, DAG1000-2S or

DAG1000-4S analog telephone adapter. Those words in red are the contents that users need to

pay attention to.

Contents

DAG1000-1S/2S/4S User Manual

III

Contents

1Product Introduction ......................................................................................................................1

1.1 Overview .....................................................................................................................................................1

1.2 Application Scenario ...................................................................................................................................1

1.3 Product Appearance......................................................................................................................................2

1.3.1 Appearance of DAG1000-1S ...............................................................................................................2

1.3.2 Appearance of DAG1000-2S ...............................................................................................................3

1.3.3 Appearance of DAG1000-4S ...............................................................................................................3

1.4 Features & Functions...................................................................................................................................4

1.4.1 Key Features .......................................................................................................................................4

1.4.2 Physical Interfaces .............................................................................................................................4

1.4.3 Voice Capabilities & Fax .....................................................................................................................4

1.4.4 FXS......................................................................................................................................................5

1.4.5 VoIP.....................................................................................................................................................5

1.4.6 Software Features................................................................................................................................5

1.4.7 Supplementary Services.......................................................................................................................6

1.4.8 Environmental.....................................................................................................................................6

1.4.9 Maintenance........................................................................................................................................6

2Quick Installation............................................................................................................................7

2.1 Installation Attentions...................................................................................................................................7

2.2 Installation Steps ..........................................................................................................................................7

2.3 Network Connection.....................................................................................................................................7

2.3.1 Network Connection Diagram under Route Mode................................................................................7

2.3.2 Network Connection Diagram under Bridge Mode ..............................................................................8

2.4 Preparations for Login..................................................................................................................................9

2.4.1 Log In Web Interface ...........................................................................................................................9

3Basic Operation.............................................................................................................................10

3.1 Methods to Number Dialing .......................................................................................................................10

3.2 Call Holding...............................................................................................................................................10

3.3 Call Waiting ...............................................................................................................................................10

3.4 Call Transfer...............................................................................................................................................10

3.4.1 Blind Transfer....................................................................................................................................10

3.4.2 Attended Transfer ..............................................................................................................................11

Contents

DAG1000-1S/2S/4S User Manual

3.5 Function of Flash-hook...............................................................................................................................11

3.6 Description of Feature Code.......................................................................................................................12

3.7 Send or Receive Fax...................................................................................................................................13

3.7.1 Fax Mode Supported .........................................................................................................................13

3.7.2 Explanation of T.38 and Pass-through................................................................................................13

3.8 Function of RST Button..............................................................................................................................14

3.9 Query IP Address and Restore Default Setting ............................................................................................14

4Configurations on Web Interface ................................................................................................15

4.1 Navigation Tree..........................................................................................................................................15

4.2 Status & Statistics.......................................................................................................................................15

4.2.1 System Information ...........................................................................................................................16

4.2.2 Registration.......................................................................................................................................18

4.2.3 TCP/UDP Statistics............................................................................................................................19

4.2.4 RTP Session.......................................................................................................................................19

4.2.5 CDR..................................................................................................................................................19

4.2.6 Record Statistics................................................................................................................................20

4.3 Quick Setup Wizard....................................................................................................................................20

4.4 Network .....................................................................................................................................................20

4.4.1 Local Network...................................................................................................................................20

4.4.2 VLAN（Virtual Local Area Network）.............................................................................................23

4.4.3 DHCP Option....................................................................................................................................24

4.4.4 QoS...................................................................................................................................................24

4.4.5 LAN Qos...........................................................................................................................................25

4.4.6 DHCP Server (Route Mode)..............................................................................................................25

4.4.7 DMZ Host (Route Mode)...................................................................................................................26

4.4.8 Forward Rule (Route Mode)..............................................................................................................27

4.4.9 Static Route (Route Mode) ................................................................................................................27

4.4.10 Firewall (Route Mode).....................................................................................................................28

4.4.11 ARP.................................................................................................................................................29

4.5 SIP Server ..................................................................................................................................................29

4.6 Port ............................................................................................................................................................32

4.7 Advanced ...................................................................................................................................................34

4.7.1 FXS Parameter ..................................................................................................................................34

4.7.2 Media Parameter................................................................................................................................36

4.7.3 SIP Parameter....................................................................................................................................37

4.7.4 Fax Parameter....................................................................................................................................44

4.7.5 Digit Map..........................................................................................................................................45

Contents

DAG1000-1S/2S/4S User Manual

4.7.6 System Parameter..............................................................................................................................46

4.8 Call & Routing ...........................................................................................................................................48

4.8.1 Port Group.........................................................................................................................................48

4.8.2 IP Trunk.............................................................................................................................................50

4.8.3 Routing Parameter.............................................................................................................................51

4.8.4 IP Tel Routing...............................................................................................................................52

4.8.5 Tel IP/Tel Routing.........................................................................................................................53

4.8.6 IP IP Routing ................................................................................................................................54

4.9 Manipulation..............................................................................................................................................54

4.9.1 IP Tel Callee .................................................................................................................................55

4.9.2 Tel IP/Tel Caller............................................................................................................................56

4.9.3 Tel IP/Tel Callee ...........................................................................................................................57

4.10 Management.............................................................................................................................................59

4.10.1 TR069 .............................................................................................................................................59

4.10.2 SNMP..............................................................................................................................................60

4.10.3 Syslog..............................................................................................................................................63

4.10.4 Provision .........................................................................................................................................63

4.10.5 Cloud server ....................................................................................................................................64

4.10.6 User Manage ...................................................................................................................................65

4.10.7 Remote Server.................................................................................................................................65

4.10.8 Action URL.....................................................................................................................................66

4.11 Security....................................................................................................................................................66

4.11.1 WEB ACL .......................................................................................................................................66

4.11.2 Telnet ACL ......................................................................................................................................67

4.11.3 Passwords........................................................................................................................................67

4.11.4 Encrypt............................................................................................................................................68

4.12 Tools.........................................................................................................................................................68

4.12.1 Firmware Upload.............................................................................................................................68

4.12.2 Data Backup....................................................................................................................................69

4.12.3 Data Restore....................................................................................................................................70

4.12.4 Ping Test..........................................................................................................................................70

4.12.5 Tracert Test......................................................................................................................................71

4.12.6 Outward Test ...................................................................................................................................71

4.12.7 Network Capture .............................................................................................................................72

4.12.8 Factory Reset...................................................................................................................................74

4.12.9 Device Restart .................................................................................................................................74

5Glossary..........................................................................................................................................75

1 Product Introduction

DAG1000-1S/2S/4S User Manual

1 Product Introduction

1.1 Overview

DAG1000-1S/2S/4S is a multi-functional analog telephone adapter which offers seamless

connectivity between IP-based telephony networks and legacy telephones (POTS), fax

machines and PBX systems.

The device provides 1, 2 or 4 FXS port(s), fax over IP and a built-in high-speed NAT router.

These powerful features and good voice quality make the device ideal for personal use and

suitable for various application environments such as SOHO and small enterprises.

Moreover, with automatic provisioning and centralized management system, the device is

easy for maintenance and deployment.

1.2 Application Scenario

The application scenario of DAG1000-1S/2S/4S analog telephone adapter is shown as

follows:

Figure 1-1 Application Scenario of DAG1000-1S/2S/4S

DAG1000-2S

LAN

Analog Phone

POTS

IP Phone

SIP Server

Fax Machine

PSTN

1 Product Introduction

DAG1000-1S/2S/4S User Manual

1.3 Product Appearance

1.3.1 Appearance of DAG1000-1S

Front View:

Back View:

Table 1-1 Description of Indicators and Interfaces of DAG1000-1S

Indicator

Definition

Status

Description

PWR

Power Indicator

The device is powered on.

Off

There is no power supply or power

supply is abnormal.

RUN

Running Indicator

Slow

Flashing

The device is running normally

Fast

Flashing

SIP account is registered successfully

Off

The device is running improperly

FXS

FXS In-use Indicator

FXS port is currently occupied by a call

Off

FXS port is idle or faulty

WAN/LAN

Network Link

Indicator

Green

Flashing

The device is properly connected to

network

Off

The device is not connected to network

or network connection is improper

RST

Reset Button

Used to reset the gateway to factory default settings.

After pressing the reset button, you need to restart

the gateway manually.

1 Product Introduction

DAG1000-1S/2S/4S User Manual

1.3.2 Appearance of DAG1000-2S

Front View:

Back View:

For the description of indicators and interfaces of DAG1000-2S, please refer to Table 1-1.

1.3.3 Appearance of DAG1000-4S

Front View:

Back View:

For the description of indicators and interfaces of DAG1000-4S, please refer to Table 1-1.

1 Product Introduction

DAG1000-1S/2S/4S User Manual

1.4 Features & Functions

1.4.1 Key Features

Cost-effective ATAwith 1, 2 or 4 FXS ports

Fax over IP (T.38 and Pass-Through)

Support IPv4 and IPv6

TR069 and SNMP

Elastix and Broadsoft Certification

Multiple codecs: G.711A/U, G.723.1, G.729A/B, G.726

Fully compatible with leading IMS/NGN and SIP-based IP telephony systems

1.4.2 Physical Interfaces

Telephone Port

DAG1000-1S: 1 FXS port (RJ11)

DAG1000-2S: 2 FXS ports (RJ11)

DAG1000-4S: 4 FXS ports (RJ11)

Ethernet Interfaces

DAG1000-1S/2S/4S:

1 WAN, 10/100Mbps (RJ45)

1 LAN, 10/100Mbps (RJ45)

1.4.3 Voice Capabilities & Fax

Codecs: G.711a/μ law, G.723.1, G.729A/B, G.726

Silence Suppression

Comfort Noise Generator(CNG)

Voice Activity Detection(VAD)

Echo Cancellation: G.168 with up to 128ms

Adaptive (Dynamic) Jitter Buffer

Hook Flash

Adjustable Gain Control

Programmable Gain Control

FAX: T.38 and Pass-through

Modem/POS

DTMF: SIP Info/RFC2833/Inband

VLAN 802.1P/802.1Q

1 Product Introduction

DAG1000-1S/2S/4S User Manual

Layer 3 QoS and DiffServ

1.4.4 FXS

FXS Connector: RJ11

Dial Mode: DTMF and Pulse

Pulse: 10 and 20 PPS

Caller ID: DTMF/FSK CLI Presentation

Max Cable Length: 3km

Reversed Polarity

Programmable Call Progress Tone

1.4.5 VoIP

Protocols: SIP v2.0 (UDP/TCP), RFC3261, SDP, RTP(RFC2833), RFC3262, RFC3263,

RFC3264, RFC3265, RFC3515, RFC2976, RFC3311

RTP/RTCP, RFC2198, RFC1889

SIP over TLS

RFC4028 Session Timer

RFC3266 IPv6 in SDP URI

RFC 3581 NAT.rport

Primary/Backup SIP Server

Outbound Proxy

DNS SRV/AQuery/NATPR Query

SIP Trunk

Early Media/EarlyAnswer\

NAT: STUN, Static/Dynamic NAT

1.4.6 Software Features

Hunting Group

Web ACL

Telnet ACL

Action URL

PPPoE/IPv4/IPv6

Digitmap

Bandwidth Optimization

Routing Rules based on Prefixes

Caller/Called Number Manipulation

Otros manuales para DAG1000-1S

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Adaptador de otras marcas

PCB Piezotronics

PCB Piezotronics 090B274 Manual de usuario

Auvidea

Auvidea J20 Manual del producto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manual de usuario

Akribis

Akribis ITF-21-BISS-MIT Manual de usuario

Tenda

Tenda W54U Manual de usuario

ROHO

ROHO AGILITY Manual de usuario

PROLiNK

PROLiNK WN2001 Manual de usuario

Hawking

Hawking HUF2 Manual de usuario

Airlink101

Airlink101 AWLC4030 Manual de usuario

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manual de usuario

Philips

Philips SWA4554S/10 Manual de usuario

JVC

JVC TS-C9D2B Manual de instrucciones

NETGEAR

NETGEAR A6100 Manual de usuario

D-Link

D-Link DWA-121 Manual de usuario

Philips

Philips SWA2037 Manual de usuario

Basalte

Basalte 0610-20 Manual de usuario

Yealink

Yealink EHS40 Manual de usuario

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manual de usuario
