Dino-Lite Handheld Digital Microscope User’s Manual

Dino-Lite Handheld Digital Microscope

AM413T

User’s Manual

Thank you for choosing Dino-Lite Handheld Digital Microscope!

Dino-Lite Handheld Digital Microscope has a wide scope of applications, such as,

1. Skin Check

2. Scalp Check

3. Industrial Inspection e.g. Printing Circuit Board(PCB)inspection, electronics

device inspection

4. Visual Assistance

5. Printing Inspection

6. Textile Inspection

7. Jewelry Inspection

8. Science Learning

9. ….. etc.

Please read this manual carefully before using Dino-Lite Handheld Digital

Microscope.

Dino-Lite Handheld Digital Microscope User’s Manual

Contents

Product Specifications.............................................................. 3

Safety Precautions ................................................................. 3

Contents and Name of Parts ..................................................... 4

Connecting to PC .................................................................... 4

System Requirements.............................................................................................4

Driver Installation Procedure.................................................................................5

Windows XP ................................................................................................5

Windows 2000 .............................................................................................9

Windows 98se ............................................................................................12

Connecting Procedure..........................................................................................18

Operate Dino-Lite Handheld Digital Microscope ..............................................18

DinoCapture Application Software......................................................................19

Picture / Video Folder..................................................................................21

Menu Function List......................................................................................24

Open The Picture .........................................................................................28

Open The Video Or Time Lapsed Video......................................................29

Q&A .................................................................................... 29

Certification ......................................................................... 31

Limited Liability .................................................................... 31

Dino-Lite Handheld Digital Microscope User’s Manual

Product Specifications

1. Resolution：1.3M.

2. Built-in 1 optical lens.

3. Magnification power：10x~200x.

4. Measurement function (via software)

5. Microtouch function

6. Built-in LED light, with LED software switch

7. Frame rate：up to 30 FPS

8. Interface：USB (PC)

Remarks: The magnification power is the ratio of the real size of the an observe

object vs. the image show on a 15” monitor

Safety Precautions

1. Avoid touching the lens with finger to protect the product from

electrostatic damage.

2. Do not attempt to service this product yourself. Opening the covers may

expose you to dangerous voltage points or other risks.

3. When hands are wet, do not plug in or remove the adaptor or other

connectors.

4. Using or storing Dino-Lite Handheld Digital Microscope, do not plug in any

other cables, not belong to Dino Digital Microscope.

5. Do not use any detergent or volatile solution, which will damage the

camera case, painted surfaces & lens. Only use a soft cleaning cloth.

6. If the lens is dirty, please use a kens brush on soft cloth to wipe clean.

Avoid touching them with your fingers. Exercise care to avoid scratching

the lens.

7. Without protection, do not put Dino Digital Microscope outdoor to avoid

the lens damaged by high temperature or humidity.

8. Using and storing Dino Digital Microscope at Temp: 0oC~ 40oC, Humidity:

45%~85%.

9. If water has entered Dino Digital Microscope device and the inspection

stage, immediately turn the power off and remove the USB cable. Do not

use dryer neither.

10. Using or storing Dino-Lite Handheld Digital Microscope, need to watch all

Dino-Lite Handheld Digital Microscope User’s Manual

cables to avoid trip over or Dino-Lite Handheld Microscope fall down.

11. To avoid electric shock, remove all electricity source before moving PC or

TV.

Contents and Name of Parts

1. Dino-Lite Handheld Digital Microscope Device

2. CD (user’s manual included)

3. USB Cable《USB2.0 / 1.1》(1.8m)

4. Dock

Connecting to PC

System Requirements

●PC’s system requirements:

9OS: Windows 98se, 2000, XP

9CPU: Pentium IV 1.5G, Celeron, AMD Athlon or above

Dino-Lite Handheld Digital Microscope User’s Manual

9Memory: 128MB

9HDD storage space: at least 150MB

( for driver and application software installation)

9Graphic card: 16-bit or above

9CD-ROM driver

9USB2.0 / 1.1 port

Driver Installation Procedure

■Power on PC and place installation CD into CD-ROM driver, do not connect

USB Cable from Dino-Lite Handheld Digital Microscope to PC before driver

installation.

■Select driver installation, and follow the instructions to complete installation.

■As driver installation completed, and if system asking for re-start, please

re-start the Windows OS.

Note: The driver needs to be installed only once for each computer.

Windows XP

1. Place the installation CD into CD-ROM driver, the installation program should be

started automatically. Otherwise, please execute the AUTORUN.EXE directly

from the CD.

2. Select “Driver Installation” from Dino-Lite Handheld digital Microscope

Installation menu screen as shown.

Dino-Lite Handheld Digital Microscope User’s Manual

3. Click “Next” to continue, as shown.

Dino-Lite Handheld Digital Microscope User’s Manual

4. When the “Software Installation” warning message appears, click “Continue

Anyway”.

5. Click “Finish” to complete the installation.

Dino-Lite Handheld Digital Microscope User’s Manual

6. Plug USB Cable to Dino-Lite Handheld Digital Microscope to connect with PC, a

“Found New Hardware Wizard” will then appear. Click “Next” to continue.

Dino-Lite Handheld Digital Microscope User’s Manual

Windows 2000

1. Place the installation CD into CD-ROM driver, the installation program should be

started automatically. Otherwise, please execute the AUTORUN.EXE directly

from the CD.

2. Select “Driver Installation” from Dino-Lite Handheld digital Microscope

Installation menu screen as shown.

3. Click “Next” to continue, as shown.
