Owner’s Manual

Model

CS1205

7207040100R06

IMPORTANT SAFETY INFORMATION: Always read this manual rst

before attempting to install or use this stove. For your safety, always

comply with all warnings and safety instructions contained in this manual

to prevent personal injury or property damage.

Table of Contents

Always use a qualied technician

or service agency to repair

this stove.

!NOTE: Procedures and

techniques that are considered

important enough to

emphasize.

CAUTION: Procedures

and techniques which, if not

carefully followed, will result in

damage to the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations . . . . . . . . . . . . . . . . .3

IMPORTANT INSTRUCTIONS . . . . . . . . . . . . . . .4

Quick Reference Guide . . . . . . . . . . . . . . . . . . . . .6

Sub-Compact Stove Installation . . . . . . . . . . . . . .6

Operation................................7

Maintenance..............................8

Warranty ...............................10

ReplacementParts........................12

Welcome & Congratulations

Thank you and congratulations for choosing to purchase an electric

stove from Electralog.

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result in

a possible electric shock, re hazard and will void the warranty.

Please record your model and serial numbers below for future

reference: model and serial numbers can be found on the Model and

Serial Number Labels of your stove.

Model Number

Serial Number

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)

Monday to Friday 8:00 a.m. to 4:30 p.m. EST

Please have your model number and product serial

number ready. (See above)

When using electrical appliances,

basic precautions should always be

followed to reduce the risk of re,

electric shock, and injury to persons,

including the following:

①Read all instructions before using

the Sub-Compact Stove.

②The heater is hot when in use.

To avoid burns, do not let bare skin

touch hot surfaces. The trim around

the heater outlet becomes hot during

heater operation. Keep combustible

materials, such as furniture, pillows,

bedding, papers, clothes, and

curtains at least 3 feet (0.9m) from

the front of the unit.

CAUTION: High Temperature.

Keep electrical cords, drapery, and

other furnishings at least 3 feet

(0.9m) from the front of the heater

and away from the side and rear.

③Extreme caution is necessary

when any heater is used by or near

children or invalids and whenever the

unit is left operating and unattended.

④Always unplug the Sub-Compact

Stove when not in use.

⑤Do not operate any unit with a

damaged cord or plug, or if the heater

has malfunctioned, or if the Sub-

Compact Stove has been dropped

or damaged in any manner. Return

heater to authorized service facility for

IMPORTANT INSTRUCTIONS

examination, electrical or mechanical

adjustment, or repair.

⑥Do not use outdoors.

⑦The Sub-Compact Stove is

not intended for use in bathrooms,

laundry areas and similar indoor

locations. Never locate heater where

it may fall into a bathtub or other

water container.

⑧Do not run the cord under

carpeting. Do not cover cord with

throw rugs, runners, or the like.

Arrange cord away from trafc area

and where it will not be tripped over.

⑨To disconnect the unit, turn the

controls off, then remove the plug

from the outlet.

⑩Do not insert or allow foreign

objects to enter any ventilation or

exhaust opening as this may cause

an electric shock or re, or damage to

the heater.

⑪ To prevent a possible re, do

not block air intake or exhaust in any

manner. Do not use on soft surfaces,

like a bed, where openings may

become blocked.

⑫All electrical heaters have hot

and arcing or sparking parts inside.

Do not use in areas where gasoline,

paint, or ammable liquids are used

or stored or where the unit will be

SAVE THESE INSTRUCTIONS

exposed to ammable vapors.

⑬Do not modify the Sub-Compact

Stove. Use it only as described in this

manual. Any other use not

recommended by the manufacturer

may cause re, electric shock or

injury to persons.

⑭To reduce the risk of electric

shock, this appliance has a polarized

plug (one blade is wider than the

other). This plug will t in a polarized

outlet only one way. If the plug does

not t fully in the outlet, reverse the

plug. If it still does not t, contact

a qualied electrician to install the

proper outlet. Do not change the

plug in any way. Avoid the use of an

extension cord. Extension cords may

overheat and cause a risk of re. If

you must use an extension cord, the

cord must be No. 14 AWG minimum

size and rated no less than 1875

Watts.

IMPORTANT INSTRUCTIONS

⑮Do not burn wood or other

materials in the Sub-Compact Stove.

⑯Do not strike the clear door

panel.

⑰ Always use a certied electrician

should new circuits or outlets be

required.

⑱Always use properly grounded,

fused and polarized outlets.

⑲Disconnect all power supply

before performing any cleaning,

maintenance or relocation of the unit.

⑳When transporting or storing the

unit and cord, keep in a dry place,

free from excessive vibration and

store so as to avoid damage.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICABLE PARTS INSIDE

Sub-Compact Stove Installation

!NOTE: A 15 Amp, 120 Volt

alternating current (VAC)

circuit is required. A dedicated

circuit is preferred but not

essential in all cases. A

dedicated circuit will be

required if, after installation,

the circuit breaker trips or

blows fuses on a regular basis

when the heater is operating.

Additional appliances on the

same circuit may exceed the

current rating of the circuit

breaker.

WARNING: Ensure the power

cord is not installed so that

it is pinched or against a

sharp edge and ensure that

the power cord is stored or

secured to avoid tripping or

snagging to reduce the risk of

re, electric shock or injury to

persons.

Construction and electrical

wiring must comply with local

building codes and other

applicable regulations to

Quick Reference Guide

① Prior to the rst use of the

Sub-Compact Stove verify the

following:

• Are the circuit breakers for the

unit on?

• Are the light bulbs in your

Sub-Compact Stove loose? (to

check, follow the instructions

for replacing the light bulbs

under the Maintenance section

of this manual)

②The heater on your Sub-

Compact Stove may emit a slight,

harmless odor when rst used.

This odor is a normal condition

caused by the initial heating of

internal heater parts and will not

occur again.

③If you have any technical

questions or concerns regarding

the operation of your Sub-

Compact Stove, or require service

contact Customer Service at

1-888-346-7539 before returning

the product to the point of

purchase.

reduce the risk of re, electric

shock and injury to persons.

Do not attempt to wire your

own new outlets or circuits. To

reduce the risk of re, electric

shock or injury to persons,

always use a licensed

electrician.

Installation

① Make sure the unit’s Main On/

Off Switch is switched Off (refer to

operating instruction section).

② Plug the unit into a 15 Amp,

120 VAC outlet. If the cord

does not reach, you may use

an extension cord rated for a

minimum of 1875 Watts.

Sub-Compact Stove Installation

Operation

The controls are located on

the right side of the heater pan

(Figure 1).

A. Main On/Off Switch

The Main On/Off switch supplies

power to all unit functions (heat/

ame).

B. Low Heat On/Off Switch

The Low Heat On/Off Switch

supplies power to the heater fan

and the heater element. When the

switch is in the On position the

heater operates on Low.

C. High Heat On/Off Switch

The High Heat On/Off Switch

Figure 1

Figure 2

Bulb

Screws

(5)

Access Panel

Operation

supplies power to the heater fan

and the heater element, when the

switch is in the ON position the

heater operates on High.

!NOTE: The Low Heat On/

Off Switch must also be in the

On position for the high heat

setting to operate.

Resetting the Temperature

Cutoff Switch

Should the heater overheat, an

automatic cut out will turn the

heater off and it will not come

back on without being reset. It

can be reset by switching the

Main On/Off Switch to Off and

waiting ve (5) minutes before

switching the unit back on.

CAUTION: If you need to

continuously reset the heater,

unplug the unit and call

Customer Service at

1-888-346-7539.

Maintenance

 WARNING: Disconnect

power before attempting any

maintenance or cleaning to

reduce the risk of re, electric

shock or damage to persons.

Light Bulb Replacement

Allow at least ve (5) minutes for

the light bulb to cool off before

touching, to avoid accidental

burning of the skin. The light bulb

needs to be replaced when you

notice a dark section of the ame

or when the clarity and detail

of the log exterior disappears.

There is one (1) bulb located at

the back of the unit behind the

access panel.

Light Bulb Requirement

Quantity of one (1) clear

chandelier or candelabra bulb

with an E-12 (small) socket base,

and 60 Watt rating.

To Replace the Bulb (Figure 2)

① Remove the ve Phillips

screws from the access panel,

located on the back of the unit,

and remove access panel.

② Locate and examine the bulb

to determine if replacement is

required.

③Unscrew the bulb counter

clockwise.

④Insert and install new bulb.

⑤Secure access panel to unit.

Clear Door Panel Cleaning

The clear door is cleaned in

the factory during the assembly

operation. During shipment,

installation, handling, etc., the

Maintenance

clear door may collect dust

particles. These can be removed

by dusting lightly with a clean, dry

cloth.

To remove ngerprints or other

marks, the clear doors can be

cleaned with a damp cloth. The

clear door should be completely

dried with a lint free cloth to

prevent water spots. To prevent

scratching, do not use abrasive

cleaners or spray liquids on the

clear door surface.

Sub-Compact Stove

Surface Cleaning

Use warm water only to clean

painted surfaces of the Sub-

Compact Stove. Do not use

abrasive cleaners.

Servicing

Except for light bulb replacement

and cleaning described

above, an authorized service

representative should perform

any other servicing.

Products to which this limited warranty

applies

This limited warranty applies to the

following models of your newly purchased

Electralog Sub-Compact Stove CS1205

and to newly purchased Electralog stove

surrounds (mantels) and trims. This limited

warranty applies only to purchases made

in any province of Canada except for

Yukon Territory, Nunavut, or Northwest

Territories or in any of the 50 States of

the USA (and the District of Columbia)

except for Hawaii and Alaska. This limited

warranty applies to the original purchaser

of the product only and is not transferable.

Products excluded from this limited

warranty

Light bulbs are not covered by this limited

warranty and are the sole responsibility of

the owner/purchaser. Products purchased

in Yukon Territory, Nunavut, Northwest

Territories, Hawaii, or Alaska are not

covered by this limited warranty. Products

purchased in these States, provinces, or

territories are sold AS IS without warranty

or condition of any kind (including, without

limitation, any implied warranties or

conditions of merchantability or tness for

a particular purpose) and the entire risk of

as to the quality and performance of the

products is with the purchaser, and in the

event of a defect the purchaser assumes

the entire cost of all necessary servicing

or repair.

What this limited warranty covers and for

how long

Products covered by this limited warranty

have been tested and inspected prior to

shipment and, subject to the provisions

of this warranty, Electralog warrants

such products to be free from defects in

material and workmanship for a period of

90 days from the date of the rst purchase

of such product.

The limited 90 day warranty period also

applies to any implied warranties that

may exist under applicable law. Some

jurisdictions do not allow limitations on

how long an implied warranty lasts, so

the above limitation may not apply to the

purchaser.

What this limited warranty does not cover

This limited warranty does not apply to

products that have been repaired (except

by Electralog or its authorized service

representatives) or otherwise altered. This

limited warranty does further not apply

to defects resulting from misuse, abuse,

accident, neglect, incorrect installation,

improper maintenance or handling, or

operation with an incorrect power source.

What to do when your unit ceases to

operate as described in this manual

Defects must be brought to the attention of

Electralog Technical Service by contacting

Electralog at 1-888-346-7539, or 1367

Industrial Road, Cambridge Ontario,

Canada N1R 7G8. Please have proof of

purchase, catalogue/model and serial

numbers available when calling. Limited

warranty service requires a proof of

purchase of the product.

What Electralog will do in the event of a

defect

In the event a product or part covered

by this limited warranty is proven to be

defective in material or workmanship

during the 90 day limited warranty period

you have the following rights:

Warranty

Otros manuales para ELECTRALOG CS1205

Tabla de contenidos

Otros manuales de Cocina de Dimplex

Dimplex

Dimplex DS4411 Manual de usuario

Dimplex

Dimplex ELECTRIC PATIO STOVE Manual de usuario

Dimplex

Dimplex Bellingham 5kW BLM5SE Manual de usuario

Dimplex

Dimplex OPTIMYST FORTROSE FOR20 Manual de usuario

Dimplex

Dimplex DS7420 Manual de usuario

Dimplex

Dimplex Optiflame Cassia Noir RTOFSTV20 Manual de instrucciones

Dimplex

Dimplex STOCKBRIDGE SKG20BL Manual de usuario

Dimplex

Dimplex Willowbrook WLL20 Manual de instrucciones

Dimplex

Dimplex Opti-myst Cassington CSN20 Manual de usuario

Dimplex

Dimplex ELECTRALOG CS4416 Manual de usuario

Dimplex

Dimplex Delaware DWR20 Manual de usuario

Dimplex

Dimplex Opti-myst Gosford Guía de inicio rápido

Dimplex

Dimplex Tango Manual de usuario

Dimplex

Dimplex Bellingham 8kW Manual de usuario

Dimplex

Dimplex ELECTRIC STOVE Manual de usuario

Dimplex

Dimplex 143041WT Manual de usuario

Dimplex

Dimplex Noir RTOPSTV20GN Manual de usuario

Dimplex

Dimplex EOSM-2007 Manual de usuario

Dimplex

Dimplex ELECTRIC STOVE Manual de usuario

Dimplex

Dimplex COURCHEVEL CVL20E Manual de instrucciones

Dimplex

Dimplex Ritz Manual de usuario

Dimplex

Dimplex DCS19W Manual de usuario

Dimplex

Dimplex Bellingham BLM4iSE Manual de usuario

Dimplex

Dimplex Opti-myst Cassington CSN20 Manual de usuario

Manuales populares de Cocina de otras marcas

Arada

Arada Cassette Stove Manual de usuario

Parmco

Parmco FS 600 Manual de usuario

MCZ

MCZ SUITE AIR 10 M2 Manual de usuario

HearthStone

HearthStone Stowe DV 8321 Guía de solución de problemas

Cattara

Cattara FAMILY Manual de usuario

Stanley

Stanley Argon F500 OVAL Manual de usuario

Avalon

Avalon B-VENT Manual de usuario

Nordpeis

Nordpeis Vega Manual de usuario

Exquisit

Exquisit EKC601-5 Manual de operación

Stanley

Stanley Oisin Oil MK II Manual del propietario

Thermocet

Thermocet Brookfield S/CC Manual de usuario

HASE

HASE delhi Manual de usuario

Vermont Castings

Vermont Castings Intrepid 2 Manual de usuario

Italiana Camini

Italiana Camini CLASSICA Guía de inicio rápido

Avalon

Avalon Vashon Avanti DVS FS Manual de usuario

Spartherm

Spartherm ambiente a1 Manual de usuario

Warmlite

Warmlite WL46040 Manual de usuario

Regency

Regency Ultimate U39E Series Guía de inicio rápido
