Revillusion®25"Electric Log Set
Model RLG25 (6909760159)
Owner’s Manual
IMPORTANT SAFETY INFORMATION: Read this manual rst before attempting
to install or use the Revillusion® Log Set. Always comply with the warnings and
safety instructions contained in this manual to prevent personal injury or property
damage.
To view the full line of Dimplex products,
visit www.dimplex.com
2 www.dimplex.com
Table of Contents
SAVE THESE INSTRUCTIONS
Conventions used in this manual:
!NOTE: Procedures and techniques that are considered important enough to
emphasize.
CAUTION: Procedures and techniques which, if not carefully followed, will result in
damage to the equipment.
WARNING: Procedures and techniques which, if not carefully followed, will expose
the user to the risk of re, serious injury, or death.
Welcome ............................................................3
IMPORTANT INSTRUCTIONS .......................4
Installation .........................................................6
Operation ...........................................................9
Maintenance .................................................... 11
Warranty ..........................................................12
Technical Support ............................................14
3
Welcome
Thank you for purchasing a Revillusion® Log Set by Dimplex. Please use our
convenient online registration page to record your model and serial numbers for
future reference at:
www.dimplex.com/register
CAUTION: Read all instructions and warnings carefully before starting installation.
Failure to follow these instructions may result in a possible electric shock or re hazard
and will void the warranty.
Serial Number
Model Number
MOD
MODEL / CAT NO
SERIAL NO
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-346-7539
In order to better serve you, please have your model and serial numbers
ready or register your product online before calling (see above).
4 www.dimplex.com
Basic Precautions
When using any electrical appliance,
basic precautions should always be
followed to reduce the risk of fire,
electric shock, and injury to persons.
These precautions include:
① Read all instructions before using
the log set.
DANGER: High temperatures may
be generated under certain abnormal
conditions. Do not partially or fully
cover or obstruct the front of the log
set.
② Extreme caution is necessary
when any heater is used by or near
children or invalids and whenever
the unit is left operating and
unattended.
③ Always unplug the log set when it is
not in use.
④ Do not operate the log set with
a damaged cord or plug or after
the log set malfunctions, has
been dropped, or damaged in any
manner. Contact Technical Service
at 1-888-346-7539.
⑤ Do not use this log set outdoors.
⑥ This log set is not intended for use
in bathrooms, laundry areas, and
similar indoor locations. Never
locate the log set where it may
fall into a bathtub or other water
container.
IMPORTANT INSTRUCTIONS
⑦ Do not run power cord under
carpeting. Do not cover cord with
throw rugs, runners, or similar
coverings. Do not route cord under
furniture or appliances. Arrange
cord away from traffic area and
where it will not be tripped over.
⑧ To disconnect the log set, turn the
control to Off, then remove plug
from outlet.
⑨ Connect the power cord to a
properly grounded outlet only.
⑩ Do not insert or allow foreign
objects to enter any ventilation or
exhaust opening as this may cause
an electric shock or fire, or damage
the log set. To prevent a possible
fire, do not block air intakes or
exhaust in any manner. Do not use
on soft surfaces, like a bed, where
openings may become blocked.
⑪ This log set has hot and arcing or
sparking parts inside. Do not use
it in areas where gasoline, paint,
or flammable liquids are used or
stored.
⑫ Use this log set only as described
in this manual. Any other use not
recommended by the manufacturer
may cause fire, electric shock, or
injury to persons.
⑬ Always plug the log set directly
into a wall outlet/receptacle. Never
use with an extension cord or
relocatable power tap (outlet/power
strip).
⑭ Do not burn wood or other materials
on the log set.
5
Special Precautions
WARNING: Remote control contains a
small battery. Keep away from children.
If swallowed, seek medical attention
immediately.
WARNING: Do not install battery
backwards, charge, put in re or mix
with used or other battery types as it
may explode or leak causing injury.
CAUTION: Do not open the unit. There
is a risk of electric shock. There are no
user-serviceable parts inside.
CAUTION: Always use a qualied
technician or service agency to repair
this unit.
IMPORTANT INSTRUCTIONS
FCC Compliance
CAUTION: This unit has been tested
and found to comply with the limits
for Class B digital device, pursuant to
part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This unit
generates, uses and can radiate
radio frequency energy and, if not
installed and used in accordance with
the instructions, may cause harmful
interference to radio or television
reception, which can be determined
by turning the unit OFF and ON, the
user is encouraged to try to correct
the interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the unit
and the receiver.
• Connect the unit into an outlet on a
circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This unit complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This unit may not cause
harmful interference, and (2) this unit must
accept any interference received, including
interference that may cause undesired
operation.
FCC CAUTION: Any changes or
modications not expressly approved
by the party responsible for compliance
could void the user’s authority to
operate this equipment.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICEABLE PARTS INSIDE
6 www.dimplex.com
Installation
The Revillusion® Log Set offers an alternative to wood or gas fireplaces. It can
give your existing fireplace new life or transform a cabinet or media center of your
own into a stunning focal point.
Specifications
Electrical
Volts: 120 V, 60 Hz
Amps: 12.5 A
Watts: 1500 W
Wiring: Plug-In
Bulb Type: LED
Approvals
Dimensions
Width: 25.6" (635 mm)
Height: 19.0" (483 mm)
Depth: 13.0" (330 mm)
Weight: 12 lbs (5.4 kg)
Operating Temperature Range:
-4o to 104o F (-20oto 40o C)
NOTE: A 15 Amp, 120 Volt circuit
is required. A dedicated circuit is
preferred, but not essential in all cases.
A dedicated circuit will be required if,
after installation, the circuit breaker
trips or the fuse blows on a regular
basis when the heater is operating.
Additional appliances on the same
circuit may exceed the current rating of
the circuit breaker.
WARNING: Electrical outlet wiring
must comply with local building codes
and other applicable regulations to
reduce the risk of re, electric shock, or
injury to persons.
!
Placement
1. The Revillusion log set does not
require venting. For optimal viewing,
it is recommended to install the unit
in an opening with the following
minimum dimensions:
A. 26" (660 mm) wide,
B. 22" (559 mm) high
C. 15" (381 mm) deep.
2. Make sure there is clearance for air
circulation beneath the unit.
3. If installing in an existing fireplace
opening, seal all drafts and vents
with a non-fibrous insulation
material to prevent any chimney
debris from falling onto the unit. Do
not install into an existing fireplace
opening that is prone to dampness.
A
B
C
7
Installation
Assembly
1. Place the log set into position.
a. Lift the log set by holding the
sides of the heater box for
stability. Do not lift by gripping
the logs or the grate front legs.
b. If installing the unit in a carpeted
area, place a one-piece, solid,
flat surface under the unit. Make
sure that both of the grate feet
rest securely on this surface.
CAUTION: Each of the Realogs™
contain LEDs that pulse and glow.
Handle the log set carefully. They
are fragile and can crack or break if
dropped.
2. Place the ember mat in front and
below the grate.
3. Connect the wires from the ember
mat to the connector on the right
side of the grate box.
4. Install the Mirage™ Flame Panel by
inserting the bottom edge into the
tabs between the back log and grate
log assemblies.
The painted side should be at the
back and the smooth side to the
front.
Position the screen so that the
cutout in the middle aligns with
the center tab. Start on one end
to insert the screen in all the way
across. When in place, the screen
should be centered and slightly
curved.
5. Plug the unit directly into a wall
outlet.
8 www.dimplex.com
Grounding Instructions
This product must be grounded. If it
should malfunction or break down,
grounding provides a path of least
resistance for electric current to reduce
the risk of electric shock. This product
is equipped with a cord having an
equipment-grounding conductor and a
grounding plug.
The plug must be plugged into an
appropri ate outlet that is properly
installed and grounded in accordance
with all local codes and ordinances.
DANGER: Improper connec tion of
the equipment-grounding conductor
can result in a risk of electric shock.
Check with a qualied electrician or
serviceman if you are in doubt as
to whether the product is properly
grounded. Do not modify the plug
provided with the product – if it will
not t the outlet, have a proper outlet
installed by a qualied electrician.
This product is for use on a nominal
120-volt circuit and has a grounding
plug that looks like the plug in the
following figure. Make sure that the
product is connected to an outlet
having the same con figuration as the
plug. No adapter should be used with
this product.
Installation
9
Manual Control
The manual controls for the Revillusion
are located on the right-front leg of the
log grate.
Power
Press to turn the flame effect on
and activate the previous heat
setting (Off, Low, or High). Press
again to put the unit in standby
mode.
Heat
• Heat On
Press to set the heat to Low
(indicated by 1 short beep).
Press again to set the heat
to High (indicated by 2 short
beeps).
• Heat Off
Press to turn heat Off (indicated
by 1 long beep).
NOTE: After the heater is
switched o, the fan will continue on
for 60 seconds before turning o.
The log LEDs remain On when the
heater is ON and the ame eect is
O.
Color Themes
Press multiple times to change
the LED lights from: flame base
yellow, flame base blue, flame
!
Operation
base yellow with yellow 360
LEDs, flame base blue with 360
LEDs. (Feature is active only
when the flame effect is On.)
Brightness
Press multiple times to toggle
the log set LEDs through its four
brightness settings.
Remote Control
The replace is supplied with a multi-
function remote control.
The remote control has a range of
approximately 30ft (9m). To operate
correctly, the remote control must be
pointed toward the front of the unit.
Power
Press to activate the current
standby state (On/Off).
• Standby State On
Press to turn everything Off.
Press again to active the
previous flame effect state.
• Standby State Off
Press to activate the previous
flame effect state.
10 www.dimplex.com
- If the flame effect was On, the
previous heat setting will be
activated (High, Low, or Off).
- If the flame effect was Off, the
previous heat setting will be
activated (High or Low).
Press again to turn everything
O.
Flame
Press to light the back log, grate
log, and ember mat, and start the
flame effect.
Heat
Heat On
Press to set the heat to Low
(indicated by 1 short beep).
Press again to set the heat
to High (indicated by 2 short
beeps).
• Heat Off
Press to turn heat Off (indicated
by 1 long beep).
NOTE: After the heater is
switched o, the fan will continue on
for 60 seconds before turning o.
The log LEDs remain On when the
heater is ON and the ame eect is
O.
!
Operation
360oLight
Press multiple times to change
the LEDs on the sides and back
of the unit from natural yellow
flickering to yellow solid to white
flickering to white solid to Off.
(Feature is active only when the
flame effect is On.)
Brightness
Press multiple times to toggle
the log set LEDs through its four
brightness settings.
Color Themes
Press multiple times to change
the flame base colors from
Yellow to Blue to Off. (Feature is
active only when the flame effect
is On.)
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Idiomas:
Otros manuales de Chimenea de interior de Dimplex
Dimplex
Dimplex Cavendish CSH20 Manual de usuario
Dimplex
Dimplex CDFI500-PRO Manual de usuario
Dimplex
Dimplex DF2608 Manual de usuario
Dimplex
Dimplex DF3033ST Manual de usuario
Dimplex
Dimplex RBF30-AU Manual de usuario
Dimplex
Dimplex BLF74 Manual de usuario
Dimplex
Dimplex Barletta Manual de usuario
Dimplex
Dimplex 23" Insert Fireplace DFPI2311 Guía de inicio rápido
Dimplex
Dimplex Valencia Manual de usuario
Dimplex
Dimplex 6911540100 Manual de usuario
Dimplex
Dimplex ENG56-400 Manual de usuario
Dimplex
Dimplex Shaftsbury SHA20 Manual de usuario
Dimplex
Dimplex GDS28L8-1802W Manual de usuario
Dimplex
Dimplex DF2500L Manual de usuario
Dimplex
Dimplex MULTIFIRE DF3015 Guía de inicio rápido
Dimplex
Dimplex DF2603 Manual de usuario
Dimplex
Dimplex Ravello RVO20 Manual de usuario
Dimplex
Dimplex TOLUCA DELUXE-EU Manual de usuario
Dimplex
Dimplex EF3003 Guía de inicio rápido
Dimplex
Dimplex Optiflame Electric Fireplace Manual de usuario
