Dimplex DWF5252B Manual de usuario
Owner’s Manual
Model
DWF5252B
7214480100R00
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
To view the full line of Dimplex products, please visit
www.dimplex.com
2 www.dimplex.com
Table of Contents
Always use a qualied technician
or service agency to repair
this replace.
!NOTE: Procedures and
techniques that are considered
important enough to
emphasize.
CAUTION: Procedures and
techniques which, if not
carefully followed, will result in
damage to the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
Welcome & Congratulations .................3
IMPORTANT INSTRUCTIONS ............... 4
Quick Reference Guide .....................6
Fireplace Installation ......................7
Operation ...............................11
Maintenance ............................14
Warranty ...............................15
Technical Support ........................17
3
Welcome & Congratulations
Thank you and congratulations for purchasing an electric replace from
Dimplex. Please use our convenient online registration page to record
your model and serial numbers for future reference at
www.dimplex.com/register
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
In order to better serve you, please have your model and serial number
ready or register your product online before calling (See above)
Rating Label with Model
Number and Serial Number
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in
a possible electric shock, re hazard and will void the warranty.
4 www.dimplex.com
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
① Read all instructions before us-
ing the electric replace.
② This replace is hot when in
use. To avoid burns, do not let
bare skin touch hot surfaces.
The trim around the heater outlet
becomes hot during heater opera-
tion.
③ Extreme caution is neces-
sary when any heater is used by
or near children or invalids and
whenever the unit is left operating
and unattended.
④ Always unplug the fireplace
when not in use.
⑤ Young children should be
supervised to ensure that they do
not play with the appliance.
⑥ The appliance is not intended
for use by young children or
inrmed persons without supervi-
sion.
⑦ If the supply cord is damaged,
it must be replaced by the manu-
facturer, or its service agent, or a
qualied person in order to avoid
a hazard.
⑧ Do not operate any unit with
a damaged cord or plug, or if the
heater has malfunctioned, or if
IMPORTANT INSTRUCTIONS
the electric replace has been
dropped or damaged in any man-
ner, contact Dimplex Technical
Service at
1-888-346-7539.
⑨Do not use outdoors.
⑩ This fireplace is not intended
for use in bathrooms, laundry ar-
eas and similar indoor locations.
Never locate heater where it may
fall into a bathtub or other water
container.
⑪ High temperature, keep electri-
cal cords, drapery, and other
furnishings at least 3 feet (0.9m)
from the front of the heater and
away from the side and rear.
⑫ Do not run the cord under
carpeting. Do not cover cord with
throw rugs, runners, or the like.
Arrange cord away from traf-
c area and where it will not be
tripped over.
⑬ Do not locate the unit directly
below a xed electrical conve-
nience outlet.
⑭ To disconnect the replace,
turn the controls off, then remove
the plug from the outlet.
⑮ Do not insert or allow foreign
objects to enter any ventilation
or exhaust opening as this may
cause an electric shock or re, or
damage to the heater.
⑯ Do not block air intake or
5
SAVE THESE INSTRUCTIONS
exhaust in any manner. Do not
use on soft surfaces, like a bed,
where openings may become
blocked.
⑰ All electrical heaters have
hot and arcing or sparking parts
inside. Do not use in areas where
gasoline, paint, or ammable liq-
uids are used or stored or where
the unit will be exposed to am-
mable vapors.
⑱ Do not modify the electric
replace. Use it only as described
in this manual. Any other use not
recommended by the manufactur-
er may cause re, electric shock
or injury to persons.
⑲ Avoid the use of an extension
cord. Extension cords may over-
heat and cause a risk of re. This
heater is not intended for use with
an extension cord. Plug the cord
directly into an appropriate wall
receptacle.
⑳ Do not burn wood or other ma-
terials in the electric replace.
㉑ Do not strike the replace
glass.
㉒ Always use a certied electri-
cian should new circuits or outlets
be required.
㉓ Always use properly grounded,
fused and polarized outlets.
㉔ Disconnect all power supply
before performing any cleaning,
maintenance or relocation of the
unit.
㉕ When transporting or stor-
ing the unit and cord, keep in a
dry place, free from excessive
vibration and store so as to avoid
damage.
WARNING: Remote control
contains a small battery. Keep
away from children. If swallowed,
seek medical attention immedi-
ately.
WARNING: Do not install bat-
tery backwards, charge, put in re
or mix with used or other battery
types - may explode or leak caus-
ing injury.
!NOTE: Changes or modica-
tions not expressly approved by
the party responsible for compli-
ance could void user's authority to
operate the equipment.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE
IMPORTANT INSTRUCTIONS
6 www.dimplex.com
52.0”1320
mm
22.5”
572
mm
37.0”941
mm
6.1”
154
mm
5.8”
147
mm
18.2”464
mm
5.8”
148
mm
Quick Reference Guide
Figure 1
1. Before using the fireplace
verify the circuit breakers for
the unit on?
2. If you have any technical
questions or concerns
regarding the operation of
your electric fireplace, or
require service, contact
customer service.
3. The heater may emit a slight,
harmless odor when first
used. This odor is a normal
condition caused by the initial
heating of internal heater
parts.
4. For dimensions of your
replace, refer to Figure 1.
7
!NOTE: A 15 Amp, 120 Volt cir-
cuit is required. A dedicated circuit
is preferred but not essential in all
cases. A dedicated circuit will be
required if, after installation, the
circuit breaker trips or the fuse
blows on a regular basis when the
heater is operating. Additional ap-
pliances on the same circuit may
exceed the current rating of the
circuit breaker.
WARNING: Ensure the power
cord is not installed so that it
is pinched or against a sharp
edge and ensure that the pow-
er cord is stored or secured to
avoid tripping or snagging to
reduce the risk of re, electric
shock or injury to persons.
Construction and electrical
outlet wiring must comply
with local building codes and
other applicable regulations to
reduce the risk of re, electric
shock and injury to persons.
Do not attempt to wire your
own new outlets or circuits. To
reduce the risk of re, electric
shock or injury to persons,
always use a licensed electri-
cian.
WARNING: The supplied
mounting bracket is designed
Fireplace Installation
for use with Dimplex wall
mounted replaces only. Im-
proper use, or use for purpos-
es other than intended, may
cause damage or injury.
Instructions
WARNING: Failure to install
the replace as instructed
below may result in damage
to the equipment and or may
expose the user to the risk of
re, serious injury, illness or
death.
WARNING: The replace
requires the wall mounting
bracket screws to be installed
into a minimum of two wall
studs (Figure 2).
Tools Required
• #2 Phillips screwdriver
• Pencil
• Slot screwdriver
• Bubble level (supplied)
• Drill, and drill bits as required
Approximate time: 30 minutes
for installation
1. Select an appropriate location
to mount the unit on a wall,
above an electrical outlet.
Access to the electrical outlet
must be maintained. Ensure
8 www.dimplex.com
Fireplace Installation
the installation meets the
national and state/provincial
electrical codes.
!NOTE: It is recommended
that the bottom of the unit not be
mounted higher than 1020mm
(40") from the Fireplace Installa-
tion ground to maintain an opti-
mized viewing angle of the ame.
CAUTION: Ensure that the top
of the unit is at least 610mm
(24") from the ceiling or any
object (i.e. Electrical recep-
tacles) that may obstruct or be
susceptible the ow or tem-
perature of air out of the unit.
CAUTION: High temperature,
keep electrical cords, drapery,
and other furnishings at least
3 feet (0.9m) from the front of
the heater and away from the
side and rear.
2. The wall-mounting bracket
must be mounted to at least
2 wall studs. Studs should be
accessed through 2 wall-
bracket holes in one of the
following combinations: A&F,
B&D, or C&E (Figure 2).
!NOTE: Wall anchors must
be installed in the appropriate
wall locations to fasten the wall
bracket through the remaining
holes (Figure 3). For example, if
you plan to secure the bracket to
studs through holes A&D, install
anchors centered on holes B & C.
3. Hold the wall-mounting
bracket on the wall and mark
the location of 1 of the mount-
ing holes.
4. Place the bubble level onto
the top of the wall-mounting
bracket.
5. Adjust the wall-mounting
bracket so the bubble on the
Figure 2
Figure 3
40"
(102 cm)
Recommended
24"
(61 cm)
MINIMUM
32"
(81.3 cm)
MINIMUM
9
!NOTE: At least two of the
mounting screws must be in-
stalled into a wall stud.
11. Mount the unit on the wall,
so that the tabs on the wall
bracket have been inserted
into the slots on the back of
the rebox, as shown. (Figure
5)
12. Carefully pour and evenly
distribute the supplied acrylic
rock media in the Media tray
of the rebox (Figure 6).
13. Hang the front glass as-
sembly on the mounts of the
rebox and secure the glass
onto the unit by installing the
retaining screws (Figure 7).
14. Excess electrical cord can be
inserted back into the bottom
of the unit, into the cord stor-
age area.
level is centered between the
two black lines.
6. Mark 3 other mounting screw
locations, on the wall, ensur-
ing that the wall bracket stays
level.
7. Install the supplied wall an-
chors on the drywall marked
locations by placing a #2
Phillips screwdriver into the
recess of the anchor.
8. Press the anchor into the wall
in the desired marked posi-
tion while turning the anchor
clockwise until it is ush with
the wall.
9. Insert the wall anchor screws
through the wall bracket and
thread into the wall anchors.
Tighten the screw (Figure 4).
10. Install the remaining screws
through the bracket and into
the wall studs as required.
Fireplace Installation
Figure 5
Wall anchor
Screw
Wall
bracket
Figure 4
10 www.dimplex.com
Fireplace Installation
Media Tray
Front Glass
Assembly
Figure 7
Figure 6
Glass Retaining
Screw
Tabla de contenidos
Idiomas:
Otros manuales de Chimenea de interior de Dimplex
Dimplex
Dimplex Albany Optimyst ABN15-RGB-EU Manual de instrucciones
Dimplex
Dimplex DWF3651B Manual de usuario
Dimplex
Dimplex CDN20-AU Manual de usuario
Dimplex
Dimplex Optiflame Toluca Deluxe TLC20LX Manual de instrucciones
Dimplex
Dimplex DFB4047 Guía de inicio rápido
Dimplex
Dimplex OLF46-AM Manual de usuario
Dimplex
Dimplex RBF Manual de usuario
Dimplex
Dimplex Optimyst DFI400LH Manual de usuario
Dimplex
Dimplex GDS28L8-1941WE Manual de usuario
Dimplex
Dimplex ELGAR EGR20 Manual de usuario
Dimplex
Dimplex EXBURY EBY15 Manual de usuario
Dimplex
Dimplex NAVARRA NAV15P PEBBLE Manual del propietario
Dimplex
Dimplex SP16 Manual de usuario
Dimplex
Dimplex DF2305 Manual de usuario
Dimplex
Dimplex EF3003-230 Manual de usuario
Dimplex
Dimplex Cavendish CSH20 Manual de usuario
Dimplex
Dimplex PRISM BLF5051-AU Manual de usuario
Dimplex
Dimplex Pro Series Manual de usuario
Dimplex
Dimplex BLF50 Manual de usuario
Dimplex
Dimplex SWM4220 Manual de usuario
