Dimplex CASTILLO CS3540 Guía de inicio rápido
PARTS AND SERVICE MANUAL
FOR
CASTILLO AND ZAMORA
Models CS3540/CS3550
1
TABLE OF CONTENTS
OPERATION PAGE 2
PARTS DRAWING PAGE 3
PARTS LIST PAGE 4
WIRING DIAGRAM PAGE 5
LIGHT BULB REPLACEMENT PAGE 6
FLAME MOTOR/FLAME ROD REPLACEMENT PAGE 7
HEATER ON/OFF SWITCH REPLACEMENT PAGE 8
HEATER ASSEMBLY REPLACEMENT PAGE 9
POWER CORD REPLACEMENT PAGE 10
2
CS3540, CS3550
OPERATION
Three switches provide a choice of heat settings (FIG. 1). A switch is in the ON position
when the side with the markings on (i.e. I, I, or II) is pushed in.
Switch 1 (I) Controls the electricity supply to the heater and flame effect.
Note: This switch must be in the ON (I) position for heater to operate with or without
heat.
Switch 2 (I) Provides 600 W heat output.
Switch 3 (II) Provides 1200 W heat output with switch 2.
RESETTING THE TEMPERATURE CUTOFF SWITCH
Should the heater overheat, an automatic cut out will turn the heater off and it will not
come back on without being reset. It can be reset by switching the MAIN ON/OFF
SWITCH to OFF and waiting 5 minutes before switching the unit back on.
CAUTION
If you need to continuously reset the heater, unplug the unit and call Dimplex North
America Limited at 1-800-668-6663.
3
DFB6016
11
5
2
4
1
12
3
6
7
10
4
CS3540, CS3550
REPLACEMENT PARTS
FIREBOX, 30” – Dimplex
CATALOGUE NO. CS3540, CS3550
PART NO. 000000000
REPLACEMENT PART
1. FLICKER MOTOR 2000210200RP
2. WIRE ASSY LAMPHOLDER SOCKET 4200120800RP
3. ON/OFF SWITCH 2800070700RP
4. CORD SET 4100040500RP
5. MIRROR 5900300400RP
6. LOW HEAT SWITCH 2800070900RP
7. HIGH HEAT SWITCH 2800071000RP
8. COAL STONES 1400000100RP
9. WHITE ROCK 1400010100RP
10.SURROUND, BLACK 0478090159RP
11.SURROUND, SILVER 0478090153RP
12.HEATER ASSEMBLY 1200W, 980RPM 2200490900RP
5
WIRING DIAGRAM
N L
L N
BULBS
MAIN ON/OFF SWITCH
HEATER ASSEMBLY
FLAMEMOTOR
TERMINAL BLOCK
LOW HEAT SWITCH
HIGH HEAT SWITCH
POWER CORD
6
CS3540/CS3550
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
Light bulbs need to be replaced when you notice a dark section of the flame. There are
two bulbs under the log set which generate the flames and embers located under the
emberbed.
It is a good idea to replace all of the light bulbs at one time if they are close to the end of
their rated life. Group replacement will reduce the number of times you need to open
the unit to replace the light bulbs.
BULB REPLACEMENT
1. Remove the coal/pebbles and place in a container.
2. Remove the front panel from the fireplace by lifting it up and out from the slots on the
fireplace.
3. Remove the rotisserie by carefully sliding the rubber connecter off the motor shaft.
4. Remove the defective bulb by unscrewing it as shown below.
LIGHT BULB REQUIREMENTS
Quantity of 2 clear chandelier or candelabra bulbs with an E-12 (small) socket base,
60 watt rating.
7
CS3540/CS3550
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE FLAME MOTOR/FLAME ROD
1. Remove the coal/pebbles and place in a container.
2. Remove the front panel from the fireplace by lifting it up and out from the slots on
the fireplace
3. Remove the reflector rod from the flame motor by pulling the end of the rod to the
left and carefully remove flame rod from rubber sleeve.
4. Remove the 2 screws securing the flame motor to the flame motor bracket
5. Remove the lower mirror bracket by remove the 2 mounting screws.
6. Slide the mirror down and lift out to access the terminal block.
7. Disconnect the flame motor wires from the terminal block, noting their original
locations.
8. Discard the old flicker motor.
9. Reassemble in the reverse order.
8
CS3540/CS3550
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE MAIN ON/OFF, LOW HEAT AND HIGH HEAT SWITCHES
1. Remove the coal/pebbles and place in a container.
2. Remove the front panel from the fireplace by lifting it up and out from the slots on
the fireplace
3. Remove the 9 retaining screws on the rear of the fireplace and remove the outer trim
4. Remove the heater assembly cover by removing the 4 screws on the top and front of
the cover.
5. Locate the defective switch mounted to the heater assembly cover and disconnect
the wiring clips and connections noting their original locations.
6. Depress the retainer clips on the rear of the switch and push the switch out of the
heater assembly cover.
7. Properly orientate the new switch and connect all of the wiring clips and
connections.
8. Reassemble in the reverse order as above
9
CS3540/CS3550
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE HEATER ASSEMBLY
1. Remove the coal/pebbles and place in a container.
2. Remove the front panel from the fireplace by lifting it up and out from the slots on the
fireplace
3. Remove the 9 retaining screws on the rear of the fireplace and remove the outer trim
4. Remove the heater assembly cover by removing the 4 screws on the top and front of
the cover.
5. Remove the 4 mounting screws holding the heater assembly to the heater assembly
cover.
6. Disconnect wiring connections and connect to replacement heater assembly noting their
original locations.
7. Reassemble in the reverse order as above.
