diLUSSO CSO45SBI Manual de usuario
CSO45SBI
CSO45BBI
CSO45SBI
CSO45BBI
V1
Contents
Page 1
Page 2
Page 3
Page 4
Oven Accessories --------------------------------------------------------------------------------------------------- Pag e 4
Page 4
Page 5
Page 5
Page 6
Page 7
Page 7
Program Cooking -------------------------------------------------------------------------------------------------- Pa ge 8
Page 9
Page 10
Page 11
Page 12
Page 14
Page 16
V0
1
●
●
●
●
●
●
V1
●
●
●
●
●
●
●
●
2
●
●
●
●
●
●
V1
Diagram 1
23mm
450mm
560mm
457mm
458mm
18mm
597mm
70m m
480mm Min.
550mm
545mm
13mm
23mm
3
Product
Model Number
Voltage (AC) (220 - 240)V
Frequency 50Hz
2200W
45 Litres
Diagram 4
Diagram 3
Diagram 2
220-240V~
N
L
●
●
●
●
V1
CSO45SBI, CSO45BBI
Accessories
Control Panel
Increase /Decrease
When connect to power the power button will light up.
Press for 3 sec to turn on the control panel.
,
Functions
Power
START /
PAUSE
Time
Temperature
Press the button for 3 sec to lock/unlock the door.
The button will light up when the door is locked.
Press the functions button to choose cooking function.
Press the time button to set the local time, cooking time etc.
Press the temperature button to set the cooking temperature.
Press +/- to adjust the time and temperature.
Press and hold " " to empty the water reservoir.
Press to start or pause cooking.
The oven door will automatically lock once cooking starts.
Child-Lock
(2pcs) (*Place directly on the
4
V1
A - Oven Vent
B - Top Heating Element
C - Grill
D - Door-Lock
E - Oven Lamp
F - Door Switch
G - Water Reservoir Inlet
H - Water Reservoir Outlet
I - Water Heating Element
J - Hinge Slot
K - Control Panel Display
L - Fan Forced Heating
M - Gutter
Stainless Steel Tray Bottom Rack
Half Grill
Fan Forced
Delay Start Time
Local Time
Cooking Finished
Time Display
Control Panel Display
5V1
Adding Water
●
●
Steam Cooking
Press“ ”toturnonyouroven.
Then press “ ” to select the steam function “ ” and press “ ” to start.
Press“ ”toturnonyouroven.
Then press “ ” to select the steam function “ ”.
Press “ ” once and the “ ” symbol starts to flash, then adjust to the
desired cooking time by pressing “ + ” or “ - ”.
Press “ ” once and the Temperature Display “ ” starts to flash, then
adjust to the required cooking temperature by pressing “ ” or “ ”
Press “ ” to start.
(Range, 5min - 10hours).
(Range from 35°C - 100°C)
+-
6
●
●
●
●
●
●
●
●
●
V1
●
Canceling
Press“ ”toturnonyouroven.
Then press “ ” to select the required grilling or baking function.
To adjust the default temperature press “ ”once and then press “ ” or “ ”.
To adjust the default cooking duration press “ ” once and the “ ”
symbol starts to flash, then press “ ” or “ ”.
Press “ ” to start.
+-
+-
Full Grill
+ Fan
Full Grill
Half Grill
Half Grill
+ Fan
200 C°
225 C°
35 C -
200 C
°
°
35 C - 225 C°°
20 min
30 min
5 min - 10 hours
Press“ ”toturnonyouroven.
Then press “ ” to select the required combination function.
To adjust the steam or grilling temperature press “ ” until the
corresponding function symbol starts to flash and then press “ ” or “ ”.
To adjust the steam or grilling duration press “ ” until the “ ” symbol
and the corresponding function symbol starts to flash and then
press “ ” or “ ”.
Press “ ” to start.
+-
+-
followed by grilling.
7
●●
●
●
●
●
●●
●
●
●
●
V1
