Digium 800 Series Manual de usuario
800 Series
AEX800/TDM800P
User Manual
601-00008A Rev. C
Digium, Inc. Page 2
© Digium, Inc. 2009
All rights reserved.
No part of this publication may be copied, distributed, transmitted, transcribed, stored in a
retrieval system, or translated into any human or computer language without the prior written
permission of Digium, Inc.
Digium, Inc. has made every effort to ensure that the instructions contained in this document
are adequate and error free. The manufacturer will, if necessary, explain issues which may
not be covered by this documentation. The manufacturer’s liability for any errors in the
documents is limited to the correction of errors and the aforementioned advisory services.
This document has been prepared for use by professional and properly trained personnel,
and the customer assumes full responsibility when using it.
Adobe and Acrobat are registered trademarks, and Acrobat Reader is a trademark of Adobe
Systems Incorporated.
Asterisk, Digium, Switchvox, and AsteriskNOW are registered trademarks and Asterisk
Business Edition, AsteriskGUI, and Asterisk Appliance are trademarks of Digium, Inc.
Any other trademarks mentioned in the document are the property of their respective owners.
Digium, Inc.
445 Jan Davis Drive
Huntsville, AL 35806
United States
Main Number: 1.256.428.6000
Tech Support: 1.256.428.6161
U.S. Toll Free: 1.877.344.4861
Sales: 1.256.428.6262
www.digium.com
www.asterisk.org
www.asterisknow.org
Digium, Inc. Page 3
Safety Certification and Agency Approvals
Safety: US/CSA 60950
IEC 60950
EN 60950
Other:
CE Mark
2002/95/EC Restrictions on Hazardous Substances (RoHS), 2005/747/EC
lead free exemption (Annex C)
Telecom:
FCC Part 68, ANSI/ITA-968-A, Including Amendment A1 and A2
EMC:
FCC Part 15 Class A
EN55022/CISPR22 Class A
EN55025
IEC 61000
Digium, Inc. Page 4
Federal Communications Commission Part 68
This equipment complies with Part 68 of the FCC rules and the
requirements adopted by the ACTA. On the back of the 800 Series printed
circuit board is a label that contains, among other information, a product
identifier in the format US:AAAEQ##TXXXX. If requested, this number
must be provided to the telephone company.
A plug and jack used to connect this equipment to the premises wiring
and telephone network must comply with the applicable FCC Part 68
rules and requirements adopted by the ACTA.
The REN is used to determine the number of devices that may be
connected to a telephone line. Excessive RENs on a telephone line may
result in the devices not ringing in response to an incoming call. In most
but not all areas, the sum of RENs should not exceed five (5.0). To be
certain of the number of devices that may be connected to a line, as
determined by the total RENs, contact the local telephone company. For
products approved after July 23, 2001, the REN is part of the product
identifier that has the format US:AAAEQ##TXXXX. The digits
represented by ## are the REN without a decimal point (e.g., 03 is a REN
of 0.3).
If your 800 Series card causes harm to the telephone network, the
telephone company may notify you in advance that temporary
discontinuance of service may be required. But if advance notice is not
practical, the telephone company will notify you as soon as possible.
Also, you will be advised of your right to file a complaint with the FCC if
you believe it is necessary.
Digium, Inc. Page 5
The telephone company may make changes in its facilities, equipment,
operations or procedures that could affect the operation of the equipment.
If this happens, the telephone company will provide advance notice in
order for you to make necessary modifications to maintain uninterrupted
service.
If you experience problems with your 800 Series card,contact Digium,
Inc. at 1.877.DIGIUM.1 (1.877.344.4861) for repair and/or warranty
information. If the equipment is causing harm to the telephone network,
the telephone company may request that you disconnect the equipment
until the problem is resolved.
Connection to party line service is subject to state tariffs. Contact the state
public utility commission, public service commission, or corporation
commission for information.
Federal Communications Commission Part 15
This device complies with Part 15 of FCC rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Industry Canada
This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulation.
Cet appareil numerique de la class A respecte les exigences du Reglement
sur le Material Brouilleur du Canada.
Digium, Inc. Page 6
Introduction to 800 Series Documentation
This manual contains product information for the 800 Series card. Be sure
to refer to any supplementary documents or release notes that were
shipped with your equipment. The manual is organized in the following
manner:
Chapter/
Appendix Title Description
1Overview Identifies the card and type of modules you received
with your 800 Series card. This chapter covers
applications and uses of the 800 Series card in the
real world.
2Card Installation Provides instructions for installing the card in your
PC, acquiring correct drivers, and checking device
compatibility.
3Configuration Provides examples for configuring dial plan options.
4FXS and FXO
Explained Describes the FXO (Foreign Exchange Office) and
FXS (Foreign Exchange Station) modules and their
significance.
5Troubleshooting Explains resolutions to common problems and
frequently asked questions pertaining to card
installation and usage.
APin Assignments Lists the connectors and pin assignments.
BSpecifications Details card specifications.
CGlossary and
Acronyms A list of terms and acronyms used throughout this
manual.
Digium, Inc. Page 7
Symbol Definitions
Caution statements indicate a condition where damageto the unit or
its configuration could occur if operational procedures are not
followed. To reduce the risk of damage or injury, follow all steps or
procedures as instructed.
The ESD symbol indicates electrostatic sensitive devices. Observe
precautions for handling devices. Wear a properly grounded
electrostatic discharge (ESD) wrist strap while handling the device.
The Electrical Hazard Symbol indicates a possibility of electrical
shock when operating this unit in certain situations. To reduce the
risk of damage or injury, follow all steps or procedures as
instructed.
Digium, Inc. Page 8
Important Safety Instructions
User Cautions
Warning
This card must be used with the PC lid screwed down.
Telecommunications network voltages exist inside the PC!
The PC must be shut down and telecommunications line connection
shall be removed before opening the PC.
Electrical Shock.
To reduce the risk of injury, damageto the unit or your equipment, do
not attempt to touch the modules while they are powered. The case
should be securely closed before power is applied to the unit.
Alarm Dialing Equipment.
If your home has specially wired alarm equipment connected to the
telephone line, ensure the installation of the 800 Series does not
disable your alarm equipment. If you have questions, consult your
telephone company or a qualified installer.
Servicing.
Do not attempt to service this card unless specifically instructed to do
so. Do not attempt to remove the card from your equipment while
power is present. Refer servicing to qualified service personnel.
Water and Moisture.
Do not spill liquids on this unit. Do not operate this equipment in a
wet environment.
Heat.
Do not operate or store this product near heat sources such as
radiators, air ducts, areas subject to direct, intense sunlight, or other
products that produce heat.
Caution.
To reduce the risk of fire, use only No. 26 AWG or larger
telecommunication wiring for network connections.
Digium, Inc. Page 9
Save these instructions for future reference.
Caution.
This card is not intended for home use. It must be used in restricted
access locations and installed in UL Listed I.T.E. only.
Static Electricity.
To reduce the risk of damaging the unit or your equipment, do not
attempt to open the enclosure or gain access to areas where you are
not instructed to do so. Refer servicing to qualified service personnel.
Service Personnel Cautions
Warning.
This card must be used with the PC lid screwed down.
Telecommunications network voltages exist inside the PC!
The PC must be shut down and telecommunications line connection
shall be removed before opening the PC.
Electrical Shock.
To reduce the risk of injury, damageto the unit or your equipment, do
not attempt to touch the modules while they are powered. The case
should be securely closed before power is applied to the unit.
Servicing.
Disconnect telecommunications network cable before opening the
cover or removing the card from the motherboard.
Labeling.
For safety reasons, only connect equipment with a
Telecommunications Compliance label. This includes customer
equipment previously labelled Permitted or Certified.
Caution.
Only connect regulatory equipment (approved for use in your specific
country) to the telecommunications network voltage circuit ports.
User Cautions
Digium, Inc. Page 10
Caution.
This card is not intended for home use. It must be used in restricted
access locations and installed in UL Listed I.T.E. only.
Service Personnel Cautions
