Digitronic Digital-Analog-Converter

AutomationsanlagenGmbH CamCon DAC16

Foryourattention

Thisinstruction manualrelatesto the CamCon DAC16 from28.11.1997. The companyDigitronic

Automationsanlagen GmbH reservesthe right to makechangeswhichpresent an improvement ofthe

qualityorfunctionalityofthe devicewithout priornotice. The instruction manualwascreated with great

care, although itmaynot be error-proof.Wewouldbe gratefulforanycommunication relating to any

errors you mayhave found.

UP-date

You can alsoobtainthisinstruction manualon the Internet at http://www.digitronic.com inthe latest

version asPDFfile.

Qualifiedpersonnel

Thisdevicemayonlybe started and operated byqualified staff.Byqualified wemean personnelwho

areentitled to handle, to earth and to labledevices,systemsand powercircuitsinaccordancewith the

technologysafetystandards.

Liability

(1)The supplierisliablefordamagescaused byhimselforbythe ownerofthe rightsup to the sumof

the salesprice. He isnot liableforloss ofprofits,forfeited savings,intermediate and successive

damages.

(2)The abovementioned limitsto liabilitydo not applyto insuranceofnamed characteristics and

damageswhich were caused deliberatelyorthrough negligence.

Protection

The CamCon DAC16 and thisinstruction manualareprotected bycopyright. All rightsarereserved.

Neitherthe CamCon DAC16, northisdocument maybe copied asawholeorpartially,photocopied,

reproduced, translated ortransferred to electronicmediaofanykind orinto machine readableformat

without priorwritten permission bythe companyDigitronicAutomationsanlagen GmbH.

Note: Wehaveexamined the devicesofthe CamCon seriesforyear2000 compatibilityand

have not found anyadverse effectson anyfunctions.

Note: CamCon isaregistered trademarkofthe companyFirmaDigitronic

Automationsanlagen GmbH.

Note: The devicesofthe CamCon seriescomplywith the standardsforelectromagnetic

compatibility:EN 55011, EN 55022, EN 55024 Part 2, EN 50082 Part 2, ENV50140,

VDE0843 Part 2, VDE0843 Part 4, VDE0871, VDE0875 Part 3 ("N"),

VDE0875 Part 11, VDE0877 Part 2, IEC 801 Part 3, IEC 801 Part 2, IEC 801 Part 4,

IEC 801 Part 5.

DigitronicAutomationsanlagen GmbH

AufderLangwies1

D-65510 Hünstetten -Wallbach

Tel. (+49)6126/9453-0 Fax. (+49)6126/9453-42

Internet: http://www.digitronic.com

E-Mail: mail@digitronic.com

Edition: Aug. 04 Page: 2

2 rue René Laennec 51500 Taissy France

Fax: 03 26 85 19 08, Tel : 03 26 82 49 29

E-mail:[email protected]

Site web : www.hvssystem.com

Digitronic Digital-Analog-Converter

AutomationsanlagenGmbH CamCon DAC16

Table of contents

1. Introduction..........................................................................................................................................3

2. Assembling ..........................................................................................................................................4

3. StatusLED´s........................................................................................................................................4

4. Dimensions..........................................................................................................................................4

5. Electricalconnections..........................................................................................................................5

5.1. Terminalallocation............................................................................................................................5

5.1.1. Terminalallocation ofthe supplyvoltage.......................................................................................5

5.1.2. Terminalallocation ofthe analog input 1.......................................................................................5

5.1.3. Terminalallocation ofthe analog input 2.......................................................................................5

5.2. Externalinterface..............................................................................................................................5

5.2.1. Pin allocation ofthe externalinterface IN......................................................................................5

5.2.2. Pin allocation ofthe externalinterface OUT..................................................................................5

5.2.3. Externalinterface with a wiring distance of0.5 up to 300m...........................................................6

6. The analog outputs..............................................................................................................................6

6.1. Signallevelofthe analog outputs.....................................................................................................6

7. Commisioning......................................................................................................................................6

8. Technicaldata......................................................................................................................................7

1. Introduction

The digital-analog -converterCamCon DAC16 isused asan anlog output expansion forelectronic

camswitchesofthe CamCon series.Theyareableto put out e.g. the speed, positiopn orvaluesfor

Camsviatheirexternalinterface. Ifusing aaCamCon DAC16 converterinstead ofan ordinaryoutput

module(e.g. DC91I/OorDC16I/O),the parallelbinarysignalget converted into analog signals.Every

CamCon DAC16 modulehastwo16Bitanalog outputsthat can provide current-aswell asvoltage

signals.Inputsarenot avaiable. Byserialswitching ofseveralCamCon DAC16 modules,itispossible

to expand the numberofmodulesto amaximumof13. Thisprovidese.g. foraCamCon DC16 up to

26 analog Cam-outputs.

Edition: Aug. 04 Page: 3

2 rue René Laennec 51500 Taissy France

Fax: 03 26 85 19 08, Tel : 03 26 82 49 29

E-mail:[email protected]

Site web : www.hvssystem.com

Digitronic Digital-Analog-Converter

AutomationsanlagenGmbH CamCon DAC16

2. Assembling

The D/AconverterDAC16 issnapped onto an "EN-carrier-rail" inthe switchchest. Toprotectthe

modulefromoverheating, itisnecessaryto leaveagap ofat least10mm between the devices.The

grounding clampsareto be connected on the shortestpossiblewaywith the centralgrounding point of

the assembling plate. The CamCon DC16'sexternalinterfaceisconnected with the ten polemaleplug

"ext.Int.IN" of the CamCon DAC16 I/Omoduleusing the enclosed 10 poleflatwirecable. Everyfurther

CamCon DAC16 moduleisconnected using the enclosed 10 poleflatwirecableto the ten polemale

plug "ext.Int.IN" ofthe CamCon DAC16 I/Omodule. Ifinaddition to the CamCon DAC16 modulea

CamCon DC16/IOmodule isused, the DAC16 module hasto be switched to the end ofthisrow.

The voltage supplyhasto be connected to everyDAC16 module. It hasavoltage of24VDC +/-20%.

The data-linesofthe CamCon DAC16 modulesareconnected to eachotherviaopticalcouplers and

thereforepotentiallyfree. The wiring ofthe analog outputshasto be done using shielded cables,the

shield hasto be laid to the grounding plug on one side. All wiring hasto be done in cold state.

3. StatusLED´s

The D/AconverterDAC16 hastwo statusLEDs:

LED yellow:supplyvoltage ispresent.

LED Red: indicates,that no data exchange viaaCamCon DC16 takesplaceat the moment.

Possiblescausesare: The cablelength adjusted at the CamCon outrunsthe maximum

length of300 meters,the CamCon DC50, 90 orDC115 isswitched off,i.e. the data

exchange isinterrupted (broken wire).

4. Dimensions

Edition: Aug. 04 Page: 4

2 rue René Laennec 51500 Taissy France

Fax: 03 26 85 19 08, Tel : 03 26 82 49 29

E-mail:[email protected]

Site web : www.hvssystem.com

Digitronic Digital-Analog-Converter

AutomationsanlagenGmbH CamCon DAC16

5. Electrical connections

.5.1. Terminal allocation

5.1.1. Terminal allocation of thesupplyvoltage

Terminal 7: 0Vsupplyvoltage

Terminal 8: 0Vsupplyvoltage

Terminal 9: +24VDC supplyvoltage

Terminal10: +24VDC supplyvoltage

5.1.2. Terminal allocation of theanalog input 1

Terminal 1: GND reference potential(0V)

Terminal 2: voltage output +/-10Volt maximum10mA.

Terminal 3: current output 0-20mA, 4-20mAor0-24mA.

beiRL maximum550Ω

5.1.3. Terminal allocation of theanalog input 2

Terminal 4: GND reference potential(0V).

Terminal 5: voltage output+/-10Volt maximum10mA.

Terminal 6: current output 0-20mA, 4-20mAor0-24mA.

at RL maximum550Ω

Note:Terminal1, 4, 7 and 8 are connected to each other.

5.2. External interface

Viathe externalinterfacethe data exchange with the CamCon camswitchtakesplace. The CamCon

DAC16 Modulehastwo10 polemaleplugs,called "ext.Int.IN" and "ext.Int.OUT" connection. Viathe

ext.Int.OUTthe data exchange with afurtherCamCon module(e.g. CamCon DAC16, CamCon

DC16I/OorCamCon DC91I/Oi.e. DC92/I).The data exchange isrealised viaopticalcouplers and

thereforethe connection remainsfree of potentials.Bythiswayof switching aBUSsystem fordifferent

applicationscan be established. Forthe connection ofthe DAC16 module with the CamCon DC16 a 10

pole flatwire cable isenclosed.

DAC16 DC16 5.2.1. Pinallocation of theexternal interface IN

Pin 1,10: not used

Pin 4,7: ground (0V)

Pin 2: RxD-

Pin 3: RxD+

Pin 5: CLK-

Pin 6: CLK+

Pin 8: TxD-

Pin 9: TxD+

5.2.2. Pinallocation of theexternal interface OUT

Pin 1,4,7,10: not used

Pin 2: TxD-

Pin 3: TxD+

Pin 5: CLK-

Pin 6: CLK+

Pin 8: RxD-

Pin 9: RxD+

Edition: Aug. 04 Page: 5

2 rue René Laennec 51500 Taissy France

Fax: 03 26 85 19 08, Tel : 03 26 82 49 29

E-mail:[email protected]

Site web : www.hvssystem.com

Digitronic Digital-Analog-Converter

AutomationsanlagenGmbH CamCon DAC16

5.2.3. External interface withawiring distance of 0.5up to300m

The maximumwiring distanceofthe externalinterfaceis300 meters.Forthispurposea6poledata

cablewith conductors wired aspairs isrequired aswell asan adaptercablefrom10 poleflatwireto 9

pole D-Sub-plug. Thiscable'sshielding hasto be laid to the grounding plugson both sides.

6. Theanalog outputs

The CamCon DAC16 hastwo 16 Bit analog outputs. Theyprovide either0 -20mA,4-20mA,0 -24mA

or,asan option, +/-10Voltsignals.The maximum output current at +/-10 Voltis10mA(not shortcircuit

proof). The load-resistance undercurrent-output must not outrun 550Ω. The outputsarenot potentially

free towardsthe voltage supply.the wiring ofthe analog outputshasto be done using shielded cables

and the cable'sshielding hasto be laid to the grounding plugson one side.

6.1. Signal level of theanalog outputs

The CamCon DAC16 moduleoffers 4possibilitiesofsignaloutput forboth analog outputs.Theseare:

0 -20mA, 4 -20mA, 0 -24mAoroptionaly+/-10Volt.

The adjusted signallevelsarefactory-provided marked byacross at

the stickerlabelon the left side ofthe case.

OUT2

OUT1

Ifyou want to change the signallevel,the devicehasto

be opened. The casecan be opened inthe middle

using ascrewdriver.Onthe solding side ofthe largest

printed circuitboardtwosolding bridgesforevery

analog output, i.e. the analog output 1(OUT1)and 2

(OUT2),arelocated, whicharenamed J1to J4inthe

drawing to the right. J1and J2areused to adjustthe

signallevelforoutput 1and J3and J4to adjustthe

output levelforoutput 2.

The drawing to the right shows

whichsolding bridgeshaveto be

opened orclosed, to get the

desired signallevel.

Note:

Forthe +/-10Voltvoltage output an daditiona

lsmall wrapped printed circuit board isrequired.

7. Commisioning

Beforethe firstcommisioning, checkthe device'swiring carefully.See alsochapter5. Electrical

connectionson page 5. Forconfiguration and calibration ofthe analog outputspleaseregardinthe

camswitchesmanualthe chapter"unitconfiguration",sub-chapter"anolog outputs"and inthe chapter

"systemconfiguration"sub-chapter"specialoutputs".

Edition: Aug. 04 Page: 6

2 rue René Laennec 51500 Taissy France

Fax: 03 26 85 19 08, Tel : 03 26 82 49 29

E-mail:[email protected]

Site web : www.hvssystem.com

Digitronic Digital-Analog-Converter

AutomationsanlagenGmbH CamCon DAC16

8. Technical data

Display ................................................................2 StatusLED´s forsupplyvoltage and errormessages

Numberofoutputs ..............................................two 16 Bit analog outputs.

Type ofoutput.....................................................Poweroroptionallyvoltage.

Current output.....................................................optionally0 -20mA, 4 -20mAor0 -24mA

at RL maximum550Ω.

Voltage output.....................................................+/-10Volt up to 10mA(not short circuit proof)

Resolution...........................................................16Bit.

Maximumresponse time with full levellift............approximately3ms.

Length ofthe connection cable

between CamConDC16 and CamCon DAC16...maximum300m.

Supplyvoltage.....................................................24VDC ±20 %

Powerconsumption ............................................approximately60mAwithout load.

Connectionsfor:

Voltage supplyand outputs ................................via plug-in screwclampsIP20

Assembling .........................................................comfortablesnap-on assembling, carrierrail according

to EN50 022, maybe set inrowswith 10mm gap for

aircirculation

Disassembling.....................................................bypulling backthe snap-bars.

Dimensions.........................................................See chapter4. Dimensionson page 4.

Protection............................................................Case correspondsto IP20.

Working temperature..........................................0°C ... +50°C

Weight.................................................................approximately150g

Edition: Aug. 04 Page: 7

2 rue René Laennec 51500 Taissy France

Fax: 03 26 85 19 08, Tel : 03 26 82 49 29

E-mail:[email protected]

Site web : www.hvssystem.com

Tabla de contenidos

Otros manuales de Convertidor de medios de Digitronic

Digitronic

Digitronic AWA/2X12B Manual de usuario

Manuales populares de Convertidor de medios de otras marcas

SoundTraxx

SoundTraxx Blunami BLU-2200 Manual de usuario

SPROLINK

SPROLINK VA1 Manual de usuario

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manual de usuario

Nikon

Nikon AF-S TC-20E III Manual de usuario

Axis

Axis AXIS Q7406 Manual de usuario

Omega

Omega TAC80B-J Manual de usuario

Zoom

Zoom Thunderbolt TAC-2R Manual de usuario

OST

OST iConverter 10/100M Manual de usuario

Vertiv

Vertiv Netsure Manual de usuario

birddog

birddog MINI Manual de usuario

Roland

Roland GI-10 Manual de usuario

Wallenstein

Wallenstein WX310 Manual de usuario

Pace

Pace MSS 200-1 Manual de usuario

Solar Converters

Solar Converters EQ 12/24-50 Manual de usuario

CYP

CYP EL-7400V Manual de usuario

TIE

TIE MIDI 1i1o Manual de usuario

DCS

DCS Vivaldi Upsampler Manual de usuario

Westermo

Westermo MCW-211 SERIES Manual de usuario
