Panel guide Nucoda and Phoenix 2018.2

A B

Encoder Panel (Kb) Buon Panel (Bt1) Trackball Panel (Tk) Buon Panel (Bt2) Navigaon Panel (Mf)

Available commands

Not all available acons in Nucoda and Phoenix are currently mapped, but most of the important funcons are

available for mapping. In the CC layer, the Mae and RGBM Curves tools are not currently mapped. All the DVO

Tools have been mapped, for some of the complex tools not all parameters are mapped, especially where “Basic”

sengs are available.

This guide only shows the commands needed for general operaon - the commands for the colour tools should

match their GUI counterparts and will be mapped to Kb, Bt1 and Tk - using dierent banks.

Installaon of the Panels

Installaon of the Element Panels is according to the instrucons included with the panels.

For use with Nucoda or Phoenix, be sure to select the Element Control Panel opon in the installer..

Once installed, please use the sengs tab in the Mapper to select the opon for each panel to switch it’s

own banks only.

User Preferences

When new modes and commands are added they will available in the mapper, but not always mapped.

The user will have the choice of mapping them manually to their exisng modied layout, or choose to use the

updated Defaults, which will of course ot have any custom preferences.

Control Sensivity

Except for menu selecons and the ball and ring for moving shapes, all controls are set to obey the global

sensivity contronls in the Mapper. File/Control Map Sengs... to change the sensivity of RIngs, Balls, Knobs

and the Jog dial, please do this here. You can also set it per control if desired

The default layout aempts put the most commonly used funcons and controls within easy reach of the user at

all mes. It is also designed to keep those controls available at all mes, to minimise menu switching. These are

persistent funcons and controls.

Eects are referred to in the Element Mapper as a Mode - you will see that each mode is mapped separately in the

mapper and the menus on some panels will change for every mode. The MF and Br-1 panels do not change when

modes are switched, these are persistent menus. The Tk, Kb and Bt2 panels have menus that will move down in the

bank order when modes are entered, wit the selected mode command at the top of the bank order.

The panels layouts are editable using the Tangent Mapper ulity and mulple users are managed by changing the

mapping seng in the Tangent Mapper. Changes to the mapper take immediate eect in the Nucoda or Phoenix

applicaon.

In the case where the Fake Key opon is used in the Tangent Mapper, ensure that the mapped hotkeys are updated

in the Mapper if they are changed in the Phoenix or Nucoda applicaon, there is a list of Hotkeys that are mapped at

the end of the document.

The default setup uses mulple banks for each panel. Move through dierent banks by pressing the (B) key on each

panel the (A) buon will sll access the “Alternate” funcons.

The dierence between the “Alternate” funcon and the banks, is that switching to another bank will leave the

panel display on that bank, while the “Alternate” funcon requires the user to hold the (A) buon down and the

make selecons.

The only panel that deviates from the (A) and (B) behaviour is the Trackball Panel (Tk), on this panel, the (B) buon

will step forward through available tools on the current layer. Holding down (A) while pressing (B) will step backwards

through the tools.

The numaric order for the tools can be changed in the TangentOrder.prefs le, in Root/Panel/Tangent. A value of zero

will mean the tool is ignored. The trackball panel (Tk) and navigaon panel (Mf) has dedicated Ball and Ring resets

above the balls and rings.

Tangent Overview

Buon Panel (Bt2)

A B

Mf - Bank 1 of 2 - Available in all modes

Add CC Add FX Add To FX

<-Layer Layer-> Del Layer

Mas Reset Lyr Reset FX Reset

Reset All Undo <-Shapes->

Layer navigaon. Adding and removing layers.

Reseng Layers and Eects. Undo. Shape select

Mf - Bank 2 of 2 - Press B

Add Dyn Del Dyn Fit

Add Cut Del Cut Zoom 1:1

Set Thumb Exp Still ShowK

Add IO Library Mems View

Timeline commands

Mf - Bank 1 of 1 - Hold A

Head A Mark In Mark Out

Head B Cue Head Loop

Head C Mark Sel Clear I/O

Head D Clear In Clear Out

Playhead navigaon - Marks

<- Play Stop Play >

(A) <- Frame (A) Frame ->

<- Play Play >

(A) <- Last Frame Prev (A) Last Frame current->

Bt2 - Bank 1 of 2

Compare Mem Src Comp Type

Src Sel - Src Display Src Sel +

Cue Event BypassAll Save Note

Loop Recall Append

Comparison - Memory Sources - Comparison Types

Event Cue - Saving and Recalling notes

Bt2 - Bank 2 of 2 - Press B

Add 1 5

Recall 2 6

Append 3 7

Delete 4 8

Quick memories - Select acon on le - choose memory slot

Bt2 - Bank 1 of 1 - Hold A

->InputFX ->Base ->Master

Pan+Scan Router Shapes

Balance BrightCon BrightReg

Hue Curve Keyer Soft Clip

Quick Navigaon between Base, Master and InputFX and Modes

The Jog wheel on the MF panel is mapped

to Jog, the ball is mapped to move shapes

in Xand Y

A B

Buon Panel (Bt2)

These menus are persistent and will always be available

Navigaon (Mf)

These menus are persistent and will always be available

Buon Panel (Bt-1)

Encoder Panel (Kb)

Bt1 - Bank 1 of 2 - Mode specic

Ellipse Rectangle Auto-Bezr

Shape Shp Inver Delete

Vari Soft Invert All ShowK

<-Track <-Reset-> Track->

Access to relevant shape mode commands

Bt1 - Bank 2 of 2 - Press B - available in all modes

Autokey Add KF Del KF

<-KFrame Shapes KFrame ->

Balance BrightReg Hue Curve

Soft Clip Router Pan+Scan

In some modes this menu could move to Bank 3 or 4

This menu allows quick access to Autokey, a

Adding Keyframes, shapes menu and trimming modes.

Bt1 - Bank 1 of 2 - Mode specic

Out Soft In Soft Blur

Opacity Shp Oper Soft Fall

Comb Opty Comb Oper

Flexibilty Tightness TrackType

Access to relevant Shape mode menus

Bt1 - Bank 2 of 2 - Press B - available in all modes

PL Red PL Green PL Blue

Rot Wipe Density Alpha Out

Opacity Src Input BlendMode

Blur Size Sat In Sat Out

In some modes this menu could move to Bank 3 or 4

Sat In and Sat Out, and Printer Lights

Layer blur, Layer Opacity, Inter layer blend modes

Shape mode Shape mode

This example is the Shapes mode - Most modes use only one bank, but there are modes

that use 2 or 3 banks. Use the (B) key on the panel to cycle through the banks to reach

the pesistent menus for these panels. They will be moved to the back of the banks

The encoders must be pressed down to reset the values. Sensivity can be set in the

Tangent mapper applicaon.

Buon Panel (Bt1) Menu example

Mode specic menus, they will update depending on the mode

Knob Panel (Kn) Menu example

Mode specic menus, they will update depending on the mode

Sensivity sengs in Tangent Mapper applicaon

The trackballs and rings are automacally acve when a relevant tool is selected.

Their use is not only limited to colour tools.

In the shape tool, with a selected shape, they are mapped

Le Ball - Shape posion

Le Ring - Soness

Middle Ball - Scale X and Y

Ring - Scale

Right Ball- Not mapped

Right Ring - Rotate

In the Pan & Scan tool you can use the trackballs for posioning, rotaon and scaling.

Le Ball - Pan and Tilt

Le Ring - Scale image

Middle Ball - Scale X and Y

Ring - Rotate

Right Ball- Soness X and Y

Right Ring - Soness

Use the two reset keys to reset the ball and the ring.

Sensivity can be set in the Tangent mapper applicaon or each control

they are not mapped to .global sensivity.

The following seng are available in the general.prefs le

C:\Nucoda\Root\Users\All Users\general.prefs

tangent

{

trackballCoarseSpeed 50.000000

trackballFineSpeed 10.000000

trackRingCoarseSpeed 50.000000

trackRingFineSpeed 10.000000

}

Changing these values will change the amount a colour control will change inside Nucoda

when the ball or wheel is used.

The defaults wil change values by .002

Changing the value from 50.000 to 100.0000 will cause the values to be changed by .004

Trackballs and Rings - Tk

Mf - Bank 1 of 2 - Available in all modes

Add CC Add FX Add To FX

<-Layer Layer-> Del Layer

Mas Reset Lyr Reset FX Reset

Reset All Undo <-Shapes->

Add CC - Add a new colour correcon layer aer the current layer

Add FX - Add selected eect as user FX layer

Add to FX - Add selected eect as input FX layer

<-Layer-> and Layer-> Navigate between Colour and FX layers

Del Layer - Delete current layer

Mas Reset - Reset all layers on the current or selected shots

Lyr Reset - Reset the current colour or fx layer

FX Reset - Reset only the selected colour eect

Reset All - Will reset all layers in shot, including Input FX Layers

Undo

<-Shapes-> Cycle vailable shapes in current layer

Mf - Bank 2 of 2 - Press B - available in all modes

Add Dyn Del Dyn Fit

Add Cut Del Cut Zoom 1:1

Set Thumb Snapshot ShowK

Add IO Library Mems

Add Dyn - go to desired in pont and press - goto out point and press to create dynamic

Del Dyn - posion over dynamic and select to delete dynamic

Fit - Scale to t (Focus sensive - for meline and viewer image)

Scale - Full size scale (Focus sensive - for meline and viewer image)

Set Thumb - Select new image reference for event view

Snapshot - Save sll image of current frame (setup in preferences)

ShowK - Show key image (use to see shape and keyer alpha)

Add IO - Add new layer with inverted mae of previous layer

Library - Mems - Switch between library and mems views

Mf - Bank 1 of 1- Hold A - available in all modes

Head A Mark In Mark Out

Head B Cue Head Loop

Head C Mark Sel Clear I/O

Head D Clear In Clear Out

Select Head A B C D - press cue to move selected playhead to posion of acve head

Mark In / Out to set In and Out points

Mark Sel to set I/O points on current clip

Loop to select playback mode

Clear I/O to clear marks

Clear in and Clear out

Bt2 - Bank 1 of 2 - Available in all modes

Compare Mem Src Comp Type

Src Sel - Src Display Src Sel +

Cue Edit Bypass All Save Note

Loop Recall Append

Compare - Turns on compare mode

Mem Src - Chooses the comparison source from Memories

Comp Type - Selects between the available compare opons

Src Sel + and - Choose a mems source (event, track, note)

Cue to - Cue to selected event in events view (yellow square)

Bypass All - Bypass all eects or correcons on clip

Save note - Save current correcons as a note

Loop - Set playback mode for meline playback

Recall - Recall selected layers to current selected shot

Append - Append selected presets to current note

Bt2 - Bank 2 of 2 - Press B - available in all modes

Add 1 5

Recall 2 6

Append 3 7

Delete 4 8

Add - Press 1 to 8 to store the mem

Recall - Press 1 to 8 to recall the Mem

Append - Press 1 to 8 to append the Mem

Delete - Press 1 to 8 to delete the Mem

Bt-2 - Bank 1 of 1 - Hold A - available in all modes

->InputFX ->Base ->Master

Pan+Scan Router Shapes

Balance BrightCon BrightReg

Hue Curve Keyer Soft Clip

Navigate to the selected layer (Input FX, Base, Master)

Navigate to the selected Mode.

Bt1 - Bank 1 of 2 - mode specic - Shapes

Ellipse Rectangle Auto-Bezr

Shape Invert Delete

Vari Soft Invert All ShowK

<-Track <-Reset-> Track->

Ellipse - create ellipse and go to shape mode

Rectangle - create rectangle and go to shape mode

AutoBez - create auto bezier - use mouse or pen to complete

Shape - Press to select shape or press again to cycle through available shapes

Invert - Invert current shape

Delete - Delete selected shape

Vari So - Turn on variable soness for selected shape

Invert All - Invert all shapes on layer

ShowK - Show alpha for shapes

<- Track - Track selected shape backward

Track->- Track selected shape forward

<-Reset- > - Delete all keyframes

Bt1 - Bank 2 of 2 - Press B - available in all modes

Autokey Add KF Del KF

<-KFrame Shapes KFrame ->

Balance BrightReg Hue Curve

Soft Clip Router Pan+Scan

In some eect modes this menu could move to Bank 3 or 4

Autokey - Turn on Autokey - keyframe is set on parameter change

automacally turn o when mving to a new event

Add KF - add keyframe

Del KF - delete Keyframe at current posion

<- KF - previous keyframe

Shapes - goto shapes mode in current layer

KF-> - next keyframe

Trim - Trim on - press again to cycle to segment and meline modes

Slip - slip mode

Slide - slide mode

SceneEdit - Select scene cuts on meline and press to convert to cuts.

Trim- Frame oset for trim/slip and slide

Trim+ Frame oset for trim/slip and slide

Bt1 - Bank 1 of 2 - mode specic -Shapes

Outer Sft Inner Sft Blur Size

Shp Opty Shp Oper Soft Fall

Comb Opty Comb Oper

Flexibilty Tightness TrackType

Outer S - Set outer soness on shape

Inner S - Set inner soness

Blur size - Set blur size

Shp Opty - Set shape opacity

Shp Oper - Boolean operaon for selected shape

So Fall - Change soness fall o for selected shape

Comb Opty - set opacity for all shapes on layer

Comb Oper - Boolean operaon for all shapes

Flexibility - Set exibility for Deform tracker

Tightness - Set ghtness for Deform tracker

Tracktype - Select Deform or Transform

Bt1 - Bank 2 of 2 - Press B - available in all modes

PL Red PL Green PL Blue

Wipe Rot PLDensity Alpha Out

Opacity Src Input BlendMode

Blur Size Sat In Sat Out

In some eect modes this menu could move to Bank 3 or 4

R G B Printer light controls

WipeRot - Compare mode wipe rotaon

Printer Lghts density control

Alpha out - Set to this layer to export current layer alpha or composing

Opacity - set layer opacity

Src Input - select layer source

BlendMode - Set layer blend mode

Blur - Set layer blur

Sat in - Saturaon tool

Sat out - Satuaon tool in HSL

Bt1 - Bank 1 of 2

Enable ShowK Graphs On

Hue Sat Lightness

Red Green Blue

Hue Sat Value

Enable - Enable and diable the keyer - use the picker on the GUI to pick key

ShowK - Show the Alpha channel for the slelcted

Graphs On - Graph for I-Keyer

Hue Sat Lightness - Enable or disable - remove the eect form key result

Red Green Blue - Enable or disable - remove the eect form key result

Hue Sat Value - Enable or disable - remove the eect form key result

Bt1 - Bank 2 of 2 - Press B - available in all modes

Autokey Add KF Del KF

<-KFrame Shapes KFrame ->

Balance BrightReg Hue Curve

Soft Clip Router Pan+Scan

In some eect modes this menu could move to Bank 3 or 4

Autokey - Turn on Autokey - keyframe is set on parameter change

automacally turn o when mving to a new event

Add KF - add keyframe

Del KF - delete Keyframe at current posion

<- KF - previous keyframe

Shapes - goto shapes mode in current layer

KF-> - next keyframe

Trim - Trim on - press again to cycle to segment and meline modes

Slip - slip mode

Slide - slide mode

SceneEdit - Select scene cuts on meline and press to convert to cuts.

Trim- Frame oset for trim/slip and slide

Trim+ Frame oset for trim/slip and slide

Buon Panel (Bt1) - Keyer Mode

The keyer the largest menu with 5 banks - each keyer type has it's

own bank and you have to switch to the required bank manually.

Kn - Bank 4 of 6 - Press B - HSV Values

Hue High Sat High Val High

HHighSoft SHighSoft VHighSoft

HLowSoft LLowSoft SLowSoft

<-Hue-> <-Light-> <-Sat->

Hue High / Sat High / Val High - Adjust high value for Hue Sat Value

HHighSo / SHighSo / VHighSo - Adjust soness param for high values

HLowSo / SLowSo / VlowSo - Adjust soness param for low values

<-Hue-> <-Sat-> <-Value-> - Rotate values

Kn - Bank 4 of 6 - Press B - I-Keyer

Def Soft Scale GraphOpc

FilterTyp MedianSiz

KInFilter MedianStr

Def So - Default Soness

Scale - Scale soness

GraphOpc - Ovelay graph opacity

FilterTyp - FIlter type for the Pre-Key foilter

MedianSiz - Media lter Size

KInFilter - Key in lter value

MedianStr - Media lter strength

Kn - Bank 6 of 6 Press B - Default menu page

PL Red PL Green PL Blue

Rot Wipe Density Alpha Out

Opacity Src Input BlendMode

Blur Size Sat In Sat Out

Sat In and Sat Out, and Printer Lights

Layer blur, Layer Opacity, Inter layer blend modes

Kn - Bank 1 of 6 - Keyer main page

Keyer FilterTyp MedianSiz

KInFilter MedianStr

DespecSiz Grow Mode BlurMode

Despecle Grow Softness

Keyer - Pick keyer to use HLS, RGB, HSV or Ikeyer

FilterTyp - FIlter type for the Pre-Key lter

KInFilter - Key in lter value

MedianStr - Media lter strength

DespecSiz - Despecle lter Size

Grow - Grow mae

Soness - Soen mae

Kn - Bank 2 of 6 - Press B - HLS Values

Hue High Light Hi Sat High

HHighSoft LHighSoft AHighSoft

HLowSoft LLowSoft SLowSoft

<-Hue-> <-Light-> <-Sat->

HueHigh / LightHi Sat / Hi - Adjust high value for Hue Lightness Sat

HHighSo / LHighSo / AHighSo - Adjust soness param for high values

HLowSo / LlowSo / SlowSo - Adjust soness param for low values

<-Hue-> <Light-> <-Sat-> - Rotate values

Kn - Bank 3 of 6 - Press B - RGB Values

Red High Green Hi Blue Hi

RHighSoft GHighSoft BHighSoft

RLowSoft RLowSoft RLow Soft

<-Red-> <-Green-> <-Blue->

Red High / Green Hi / Blue Hi - Adjust high values for Red Green and Blue

RHighSo / GHighSo / BHighSo - Adjust soness param for high values

BLowSo / BlowSo / BlowSo - Adjust soness param for low values

<-Red-> <Green-> <-Blue-> - Rotate values

Knob Panel (Kn) - Keyer Knob Panel (Kn) - Keyer

www.digitalvision.tv

Digital Vision (UK)

110 Wapping High Street

Wapping

London

E1W 2NE

United Kingdom

Tel +44(0)20 7734 8282

Fax+44(0)20 7734 8282

Digital Vision Development AB

Sankt Eriksgatan 48 C

112 34

Stockholm

Sweden

Tel:+46 (0)8 546 18200

Fax:+46 (0)8 546 18209

Digital Vision (US)

6464 Sunset Blvd.

Suite 830

Hollywood

CA 90028

USA

Tel:+1 818 769 8111

Fax:+1 818 769 1888

Manuales populares de Panel de control de otras marcas

RDZ

RDZ PC-HRX Manual de usuario

STG-BEIKIRCH

STG-BEIKIRCH MZ3 Manual técnico

Efka

Efka Variocontrol V810 Manual de usuario

Cebora

Cebora 208-10 Manual de usuario

AMX

AMX AutoPatch CP-15 Manual de usuario

Satel

Satel CA-6 KLED-S Manual de usuario

Evolution

Evolution IQ plus 800 Manual de usuario

Fagor

Fagor 8040 TCO CNC Manual de usuario

Trane

Trane ComfortLink II XL950 Control Manual de usuario

AKO

AKO PROCool AKO-17635-2 Manual de usuario

ABB

ABB 6136/30M-101 Manual de usuario

Telikou

Telikou BK-603 Belt Pack Manual de usuario

Mapei

Mapei Mapeheat Thermo Touch Manual de usuario

Bosch

Bosch D9412GV4 Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries SC-SL4-AE2/1 Manual de usuario

Sminn

Sminn BOX L VF1L EI Manual de usuario

Balboa

Balboa TP600 Manual de usuario

Nice

Nice HSCU1 Especificaciones técnicas

Digital Vision element Manual de usuario

Manuales populares de Panel de control de otras marcas
