Digital Equipment LG plus Series Manual

plus

Series

Text and Graphics Printer

TM Operator’s Guide

Order Number: EK–LGPLE–OG, Rev. A

Digital Equipment Corporation





FCC Notice

This equipment has been tested and found to comply with the limits of a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide a reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio

communications.

Operation of this equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to correct the interference at

his own expense.

Any changes or modifications not expressly approved by the manufacturer could

void the user’s authority to operate the equipment.

Installing this equipment in an FCC Level B product results in an FCC Level A

Composite System as defined in the FCC Rules and Regulations.

Canadian Department of Communications compliance statement:

This equipment does not exceed Class A limits per radio noise emissions for

digital apparatus as set out in the Radio Interference Regulation of the Canadian

Department of Communications. Operation in a residential area may cause

unacceptable interference to radio and TV reception requiring the owner or

operator to take whatever steps are necessary to correct the interference.

Avis de conformite aux normes du ministere des

Communications du Canada:

Cet equipment ne depasse pas les limites de Classe A d’emission de bruits

radioelectriques pour les appareils numerriques tells que perscrites par le

Reglement sur le brouillage radioelectriques etabli par le ministere des

Communications du Canada. L’exploitation faite en milieu residentiel peut

entrainer le brouillage des receptions radio et tele, ce qui obligerait le proprietaire

ou l’operateur a prendre les dispositions necessarires pour en eliminer les cause.

notices

European Directive.

This product is in conformity with the protection requirements of the EC Council

Directive 89/336/EEC on the approximation of the Laws of the Member States

relating to electromagnetic compatibility.

Digital Equipment Corporation makes no representations that the use of its

products in the manner described in this publication will not infringe on existing or

future patent rights, nor do the descriptions contained in this publication imply the

granting of licenses to make, use, or sell equipment or software in accordance

with the description.

Possession, use, or copying of the software described in this publication is

authorized only pursuant to a valid written license from Digital or an authorized

sublicensor.

Digital Equipment Corporation 1995. Printed in U.S.A.

Trademarks and Service Marks

The following are trademarks of Digital Equipment Corporation: DEClaser,

DECnet, DECserver, OpenVMS, PrintServer, ThinWire, ULTRIX, VAX, and the

DIGITAL logo.

PostScriptTM is a trademark of Adobe Systems Incorporated, which may be

registered in certain jurisdictions. AppleTalk, LocalTalk, LaserWriter, and

Macintosh are registered trademarks of Apple Computer, Inc. Microsoft, MS,

MS–DOS, and Windows NT are registered trademarks of Microsoft Corporation.

Centronics is a trademark of Centronics Data Computer Corporation. IBM is a

registered trademark and IBM PC/AT is a trademark of International Business

Machines Corporation.

All other trademarks and registered trademarks are the property of their

respective holders.

About this Operator's Guide

Digital wants you to feel comfortable

using the LG

plus

Series Printer and this

guide. This book has been designed to

meet the needs of all users, from

beginners to those experienced with line

matrix printers.

Follow the directions in this guide along

with those in your

Setup Guide

in order to

avoid injury to you and damage to the

printer.

This guide is divided into three sections:

Basic Operating Procedures — gives an

overview of the control panel and provides

procedures for loading paper and ribbon.

Configuration — provides procedures for

using the control panel to save, modify, and

delete configurations.

Troubleshooting — gives instructions

for clearing paper jams, cleaning

components, and troubleshooting.

plus

Series Printer

about this operator's guide

Conventions

Warnings, Cautions, and Notes

Warnings provide information about

conditions that could harm you or damage

the printer.

Cautions provide information about

conditions that could damage the printer.

Notes provide supplemental information

that could affect printer operation or use.

Message Display

These boxes show display messages as

they appear on the printer.





OFFLINE

CONFIG. CONTROL



Table of Contents

BASIC OPERATING PROCEDURES

Powering On the Printer 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using the Control Panel 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Loading Paper 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setting Top-of-Form 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Reloading Paper 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Unloading Paper 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Replacing the Ribbon 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Canceling a Print Job 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CONFIGURATION

Configurations and Parameters 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Saving Configurations 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Printing Configurations 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Loading Configurations 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Deleting Configurations 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

The Power–Up Configuration 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TROUBLESHOOTING

Clearing Paper Jams 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cleaning the Printer 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Solving Print Quality Problems 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Fault Messages 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .



ii Table of Contents

BASIC OPERATING PROCEDURES

1Operator’s Guide

♦Powering on the Printer 2

♦Using the Control Panel 4

♦Loading Paper 19

♦Setting Top-of-Form 23

♦Reloading Paper 26

♦Unloading Paper 30

♦Replacing the Ribbon 32

♦Canceling a Print Job 36

Powering On the Printer

2Operator’s Guide

warning

Before powering on the printer, make sure

it is plugged into the appropriate power

source.

Refer to the “Select a Site” section in

Chapter 2 of the Setup Guide for

information on proper power sources.

The power switch is located at the

top left side of the cabinet.

Push the On (|) switch to power on

the printer. Push the Off (O) switch

to power off the printer.

Off On
