Digital Doc IRIS Guía del usuario
USB 2.0 Intraoral Camera
Camera
Installer
Congratulations on your
purchase of the IRIS camera.
This manual will guide you
step by step through
the installation and setup
of your new camera.
Manual
MA0023 REV C
Digital Doc LLC
lly
Powered by
Table of Contents
1. Safety Instructions
2. Cautions
3. Important Safeguards
4. System Requirements / Compatible Software
5. START HERE Installing the Iris Camera Driver
6. Installer Setup 1
7. Installer Setup 2
8. Installer Setup 3
9. Installer Setup Finish
10. Connecting the Camera
11. Connecting the Camera 2
12. The Iris Handpiece functions and Mirror
13. The Iris Handpiece Focus and Camera Controls
14. The Iris Handpiece Sheaths
15. Iris camera Accessories
16. Trouble Shooting
17. Warranty, Tech Support & Repair Procedures
Safety Instructions
This symbol alerts the user that important literature concerning the
operations and maintenance of this unit have been included. Therefore, it
should be read carefully in order to avoid any problems.
!
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER. NO USER-SERVICEABLE PARTS
INSIDE. REFER MAINTENANCE TO QUALIFIED SERVICE
PERSONNEL
WARNING
TO PREVENT FIRE OR ELECTRICAL SHOCK,
DO NOT EXPOSE THIS DEVICE TO EXCESSIVE
MOISTURE
CAUTION
CHANGES OR MODIFICATIONS NOT EXPRESSLYAPPROVED
BY THE MANUFACTURER COULD VOID THE WARRANTY
MODE OF OPERATION: CONTINUOUS OPERATION ALTHOUGH THE
UNIT WILL GO INTO STANDBYAFTER 20 MIN. OF NON-USE
1
Type BF
Equipment
WARNING
THIS DEVICE IS NOT SUITABLE FOR USE IN THE
PRESENCE OF A FLAMMABLE ANESTHETIC MIXTURE
WITH AIR OR WITH OXYGEN OR NITROUS OXIDE
WATER INGRESS
PROTECTION:
ORDINARY EQUIPMENT
ATMOSPHERIC PRESSURE RANGE: 700-1060 hPa
ENVIRONMENTAL OPERATING SPECIFICATIONS
Temperature Range
Operating: 10 C to 40 C (50 F to 104 F)
Storage: -40 C to 70 C (-40 F to 158 F)
Relative Humidity
Operating: 30% to 75% (non-condensing)
Storage: 10% to 100% (non-condensing)
Cautions
Federal law restricts this device to sale by or on the order of a
Licensed Dental practitioner.
Cautions on Safety
Be careful not to damage the USB cable. Be sure to hold the plug when
disconnecting the cable.
Do not place a container with water or liquid, or any small metallic objects on
this unit. If water, liquid, or any metallic object enters this unit, disconnect the USB cable
immediately and contact Digital Doc.
If smoke, abnormal sound or smell occurs, disconnect the USB cable and contact
Digital Doc.
When the unit is not in use for a long time, disconnect the USB cable.
Do not apply impacts to this unit
Cautions on Installation
Do not install this unit in a poorly ventilated place, a dusty place, an unstable place,
or where soot or steam occurs.
Do not use this unit in high temperatures (higher than 40 degrees C) or at
temperatures ( lower than 0 degrees C)
Do not use in surgical theaters in hospitals where safety requirements are different
from a standard dental clinic.
Cautions on Cleaning
Disconnect the USB cable before cleaning.
Do not wipe the surface using benzene, Dicide, thinner, or gluderaldihyde.As this may
degrade the lens, or damage the handpiece material.
Lightly wipe off dirt on the cover and or lens with a soft cloth (i.e. flannel, 2x2, etc.)
It is recommended the unit be turned OFF after 10 Minutes of use to prevent increase of
temperature at L.E.D. head.
It is required that this device is plugged into a computer that complies with
IEC60601. Medical grade computer.
2
Important Safeguards
Installation
Read and follow Instructions- All of the safety and operating instructions
should be read before the intraoral camera is operated. Follow operating
and usage instructions.
Retain instructions - The safety and operating instructions should be retained
for future reference
Heed warnings - Comply with all warnings on the camera and in the
operating instructions
This camera should be operated only from the type of power source indicated.
USB 2.0
Attachments - Do not use attachments unless recommended by the camera
manufacturer.
Do not use this camera near water.
CAUTION
MAINTAIN ELECTRICAL SAFETY. POWER LINE OPERATED
EQUIPMENT OR ACCESSORIES CONNECTED TO THIS UNIT
SHOULD NOT HAVE BEEN MODIFIED SO AS TO DEFEAT
THE SAFETY FEATURES. THIS WILL HELP TO AVOID ANY
POTENTIAL HAZARD FROM ELECTRICAL SHOCK OR FIRE.
IF IN DOUBT, CONTACT QUALIFIED SERVICE PERSONNEL.
3
System Requirements and Software
Compatibility
4
Computer system requirements
Refer to the minimum requirements of your imaging software
2
1 GB of RAM minimum 2 GB or above recommended
USB 2.0 interface with high power port
CD-ROM or DVD drive
Imaging Software
Internet connectivity recommended
Windows XP Professional or above with a minimum of Service Pack 2
Ghz Pentium 4 processor
Mogo
OMS Vision
Patient Gallery
Patterson Imaging
Romexis
Schick CDR
Sidexis
TDO
VixWin Platinum
VixWin Pro
Tiger View
Tracker
Visora
XDR Digital Radiography
Visix
Kodak Digital Imaging
IRIS Compatible Imaging Software
AbelDent
Adstra
Aptery
Cadi
Capture-Link
CIEOS
Cleardent
DBS Win
Dental Vision
DentiMax
Dentrix Image 4.5
Dent-X Pro Image
Dexis
Dimaxis Pro
Dolphin
Eaglesoft
Easy Image
Genesis
Image FX
Image XL
Image DDS
OEM Versions of Apteryx
CliniView
Dentimax
Image DDS
Lightyear
One View
SUNI Medical Imaging
XL Dent
X-Ray Vision
Installing the IRIS
Camera Driver
5
START HERE
Step 1: The first step in the
installation is to determine if you
are using a 32 or 64bit operating
system.
1 Select Start from the left or top
of your task bar. 2 RIGHT click onComputer
and select Properties
3
This page will show either 32-bit or 64-bit
under system type.
You will also find system requirement
information on this page for available
RAM and processor type as well as speed.
This information will be used to confirm system requirements.
Computer information
32-bit
64-bit
4 Record your operating system,
processor type, and RAM
below for use in future steps
Processor type
RAM
Installer Setup 1
6
!
DO NOT connect the camera
until you have completed
the driver installation
Step 2: Insert the driver disc from
the side panel of this manual
into your CD drive. Step 3: Browse to your CD
ROM drive and Choose either the
32-bit (X86)
or
64-bit (X64)
driver file and double click to open.
Refer to the previous page if you
do not know the version of your
operating system.
64-bit
32-bit
Step 4:
If the User Account
Control screen appears
choose
Step 5:
Choose Next from the
welcome screen
7
Installer Setup 2
Step 6:
Accept the terms in the
License Agreement
and then choose Next
Step 7:
Confirm the location to
install the driver
and then choose Next
Only change this location if you
are an advanced user
Step 8:
Select the Software you will be
using to view images from the
camera and then choose next.
If your Software is not listed
please contact Digital Doc
1.800.518.1102
Select your
Software here
Step 9:
Choose Install after
confirming your Software
selection
1.800.518.1102
8
Step 10:
Choose Next once the
Status bar has filled
and the drivers have
transferred
Installer Setup 3
DO NOT close any command / DOS
screens during the installation
!
If at any point during the installation a “Windows Security” prompt
appears, select Continue Anyway (Win XP) or Install (Win 7)
!
