NextGen AIO D1150 Display

User Manual

01750348355A

Table of Contents

1 Manufacturer’s declaration and approval................................................................................ 1-1

2 Supplier’s Declaration of Conformity ...................................................................................... 2-1

3 Introduction ................................................................................................................................ 3-1

3.1 From Point-of-Sale to Point-of-Service ..............................................................................3-1

3.2 Features at a glance ..........................................................................................................3-1

3.3 About this manual ..............................................................................................................3-2

4 Display overview........................................................................................................................ 4-1

4.1 D1150.................................................................................................................................4-1

4.2 Touch screen per model ....................................................................................................4-1

5 User interfaces ........................................................................................................................... 5-1

5.1 Front panel .........................................................................................................................5-1

5.2 Connector panel.................................................................................................................5-2

5.3 On-Screen Display (OSD)..................................................................................................5-3

6 Display settings ......................................................................................................................... 6-1

6.1 OSD lock/unlock.................................................................................................................6-1

6.2 RMT enable/disable ...........................................................................................................6-2

6.3 Power button – lock/unlock ................................................................................................6-3

7 Touch technologies ................................................................................................................... 7-1

7.1 Projected Capacitive Touch Screen...................................................................................7-1

7.1.1 General information ............................................................................................ 7-1

7.1.2 Instructions for using the Touch Screen ............................................................. 7-1

7.1.3 Cleaning instructions........................................................................................... 7-1

8 Initial setup ................................................................................................................................. 8-1

8.1 Unpacking and checking the delivery unit..........................................................................8-1

8.2 lnstalling the display to a stand ..........................................................................................8-1

8.2.1 Installing system to the stand (standard) ............................................................ 8-1

8.2.2 Installing system to the stand (with cable covers) .............................................. 8-4

8.3 Connecting the display.......................................................................................................8-8

9 Ergonomic Terminal Workplace ............................................................................................... 9-1

10 Technical data ............................................................................................................................ 10-1

10.1 Dimensions (mm) ...............................................................................................................10-2

10.2 Projected Capacitive Touch Screen...................................................................................10-3

10.3 Supported resolution ..........................................................................................................10-3

01750348355A

1 Manufacturer’s declaration and approval

General authorization

This device complies with the requirements of the directive 2014/30/EC

with regard to “Electromagnetic Compatibility” and 2014/35/EC "Low Volt-

age Directive" and RoHS directive 2011/65/EU.

Therefore, you will find the CE mark on the device or packaging.

FCC-Class A Declaration

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the in-

struction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his expense.

Modifications not authorized by the manufacturer may void users’ authority to operate this device.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference, in-

cluding interference that may cause undesired operation.

CAN ICES-3 (A)/NMB-3 (A)

Tested safety

The Display D1150, Display D1150 /pc-touch has been awarded

the cTUVus symbol.

User information

Repair work on the devices should only be carried out by authorized and

specially trained personnel. Improper repairs will lead to the loss of any

guarantee and liability claims.

Extension boards with electrostatically endangered components can be

identified with this label.

01750348355A

1-1

Manufacturer’s declaration and approval

Safety information

This device conforms to the corresponding safety regulations for information technology devices, includ-

ing electronic office machines for use in the office environment.

• If the device is moved from a cold environment to a warmer room where it is to be operated, conden-

sation could occur. The device must be completely dry before being put into operation. Therefore an

acclimatization time of at least two hours should be accounted for.

• Lay all cables and supply lines so that nobody can tread on them or trip over them.

• Data cables should neither be connected nor removed during electrical storms.

• This equipment is not suitable for use in locations where children are likely to be present.

• Protect the device from vibrations, dust, moisture and heat, and only transport the device in its origi-

nal packaging (to protect it against

impact and blows).

• Take care to ensure that no foreign objects (e.g. paper clips) or liquids can get into the inside of the

device, as this could cause electrical shocks or short circuits.

• In case of emergencies (e.g. damaged housing, liquid or foreign objects getting into the device), the

device should be switched off immediately, the mains plug of the BEETLE or PC should be removed,

and the Diebold Nixdorf customer service should be contacted.

• If the LCD display element is broken and the liquid crystal solution leaks out of the display and onto

your hands, clothing etc., wash your hands or clothing immediately with soap or alcohol, holding

them under running water for at least 15 minutes. If the liquid comes into contact with your eyes,

please consult a doctor immediately.

Generally you should connect IT-devices only to power supply systems with separately guided protective

earth conductor (PE), known as TN-S networks. Do not use PEN conductors! Please also observe the

recommendations of the norm DIN VDE 0100, part 540, Appendix C2, as well as EN50174-2, §5.4.3.

Warranty

Diebold Nixdorf guarantees generally a warranty engagement for 12 months beginning with the date of

delivery. This warranty engagement covers all those damages which occur despite a normal use of the

product.

Damages because of

• improper or insufficient maintenance,

• improper use of the product or unauthorized modifications of the product,

• inadequate location or surroundings

will not be covered by the warranty.

For further information of the stipulation, look at your contract.

All parts of the product which are subject to wear and tear are not included in the warranty engagement.

Please order spare parts at the Diebold Nixdorf customer service.

01750348355A

1-2

Manufacturer’s declaration and approval

Instructions for maintenance

Clean your display regularly with an appropriate surface cleaning product. Make sure that the device is

switched off, connector cables are unplugged and that no moisture is allowed to get into the inside of the

device.

Please observe the maintenance and cleaning instructions for each of the components. These instruc-

tions can be found in their respective chapters.

Recycling

Environmental protection does not begin when time comes to dispose of the display; it begins with the

manufacturer. The compact display is manufactured without the use of CFCs and CCHS and is pro-

duced mainly from reusable components and materials.

The processed plastics can, for the most part, be recycled. Even the precious metals can be recovered,

thus saving energy and costly raw materials. Please do not stick labels onto plastic case parts. This

would help us to re-use components and material.

You can protect our environment by switching on your display only when it is actually needed. If possi-

ble, even avoid the stand-by-mode as this wastes energy, too. Also switch your display off when you

take a longer break or finish your work.

There are still some parts that are not reusable. Diebold Nixdorf guarantees the environmentally safe

disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001 and ISO 14001.

So don’t simply throw your device on the scrap heap when it has served its time, but take advantage of

the environmentally smart, up-to-date recycling methods.

Please contact your competent branch or the Recycling Center Paderborn (for European countries) for

information on how to return and re-use devices and disposable materials under the following mail ad-

dress:

Email: [email protected]

We look forward to your mail.

01750348355A

1-3

2 Supplier’s Declaration of Conformity

Product Description: LCD Monitor

Model: Display D1150, Display D1150 /pc-touch

Party issuing Supplier’s Declaration of Conformity

Diebold Nixdorf Singapore PTE. LTD.

30A Kallang Place, #04-01

Singapore 339213

Phone: +65 6747 3828

Responsible Party – U.S. Contact Information

Diebold Nixdorf

5995 Mayfair Road

N. Canton, OH 44720 / USA

Phone: +1 330 490 5049

FCC Compliance Statement (for products subject to Part 15)

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference re-

ceived, including interference that may cause undesired operation.

01750348355A

2-1

3 Introduction

3.1

3.1 From Point-of-Sale to Point-of-Service

With the D1150 you are using an ergonomically and customer-friendly cashier's workplace.

Equipped with a sleek modern bezel free design and robust aluminum housing, the D1150 features pro-

jected capacitive touch technology. There is also a non-touch version available.

The D1150 features the unique Diebold Nixdorf PanelLink2™ interface. This allows for operation of the

displays via a single cable solution. In addition, the screen also offers standard interfaces such as DVI-D

and USB-C DP. Instead of using a standard power supply with 12V DC jack, a PoweredUSB cable can

be used. The display can be applied in all trade market segments like specialist retailers, department

stores, self-service stores, petrol stations or in restaurants. There is indeed a great deal of scope for im-

plementing the display.

They can be used, for example, as:

• a point-of-sale terminal

• an ordering terminal

• an information terminal

• a desk terminal.

The low-energy and flicker-free color monitor of the D1150 is a LCD in TFT-technology (Thin Film Tran-

sistor).

Therefore, it is well suited for multimedia applications as it offers brilliant color representation, an excel-

lent contrast ratio and a high display speed.

3.2

3.2 Features at a glance

• Low footprint

• Autoscaling of the screen

• Flicker-free

• Very good contrast ratio, adjustable loudness, sharpness, width, phase, color temperature and bright-

ness via OSD menu

• LCD TFT technology

• Digital and Analog interface

• Simple installation via plug & play feature

• Mounting VESA 100 standard

• Integrated loudspeaker

• USB interface for external devices.

01750348355A

3-1

Introduction

3.3

3.3 About this manual

This manual informs you about everything you might need to know for the installation (software and

hardware), the operation and the maintenance of your D1150.

Same parts of this book require familiarity and experience in working with operating systems and instal-

lation and configuration procedures.

NOTE

Notes in the manual are marked by this symbol.

WARNING

This symbol is used for warnings.

01750348355A

3-2

4 Display overview

4.1

4.1 D1150

The LCD TFT Panel Display is a 15-inch flat panel display which is absolutely flicker-free. lt is designed

for a resolution of max. 1024x768 pixels. Application programs should use this resolution.

4.2

4.2 Touch screen per model

Model Screen Size Touch Screen

Display D1150 /pc-touch 15” Projected Capacitive Touch

Display D1150 15” No Touch, Protective Glass

01750348355A

4-1

5 User interfaces

5.1

5.1 Front panel

Scrolling for -/+

Activity LED Menu Power button /

Status LED

Via the menu you can set the brightness, contrast and color.

Scrolling

The arrows serve for scrolling forwards or backwards in the menu items.

LED

Behavior of Activity LED Behavior of Status LED Operating Condition

Off LED off Power off

Green White, full brightness Power on

Off White, full brightness, blinking at 1Hz Standby / No video input

Amber White, partial brightness (dimmed) Soft-Off

ON/OFF button

With this button you can switch the display on or off.

NOTE

If the display is manually switched off, it will not wake up automatically when the system

boots.

When the D1150 is connected via PLINK2™ interface to a BEETLE system, the button also switches the

system on or off, provided that the system supports the feature. See section Display Settings / RMT en-

able/disable for details.

01750348355A

5-1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de DIEBOLD NIXDORF

DIEBOLD NIXDORF

DIEBOLD NIXDORF BA82 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF D1156 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF BA90 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF D2156 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF D2150 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF K-two Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF NextGen AIO D1104 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF NextGen AIO D1101 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF BA63GU-2 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF D1104 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF NextGen AIO D2080 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF D1064 Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF BA91W Manual de usuario

DIEBOLD NIXDORF

DIEBOLD NIXDORF NextGen AIO D1150 Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
