SPECIFICATION SHEET

SKU : 4870PE5512OC

August 10, 2011 - 2:16 pm

ENG APVD - LK 2008-05-19

MRKTG APVD - LL 2008-06-16

SKU 4870PE5512OC

PRODUCT DIAMOND AMD ATI Radeon™ HD 4870 512MB GDDR5 XOC Black Edition Video Card

PRODUCT SHORT DESCRIPTION INTERFACE PCI Express x16

GPU HD 4870

CORE CLOCK 795 MHZ

MEMORY CLOCK 1100 MHz

MEMORY CONFIGURATION 16M x 32

MEMORY TYPE GDDR5

MEMORY BANDWIDTH 160 GB/Sec

MEMORY SIZE 512MB

MEMORY CONTROLLER INTERFACE 256-bit

PORTS 2 Dual-Link DVI,Video Out [S-Video, Composite, HDTV]

DUAL LINK DVI Hydravision 4

PRODUCT DETAILED DESCRIPTION ATI Radeon™ HD 4800 Series

The ATI Radeon HD 4800 Series GPUs bring the power of graphics “supercomputing? to gamers, setting a new standard

for visual computing. Redefine the way you play and take HD gaming to the extreme with best-in-class performance. The

new TeraScale graphics engine delivers an immersive, cinematic gaming experience. Add this GPU to your PC and watch

Blu-ray movies and play HD content with incredible visual fidelity.* Do it all with break-through efficiency that doesn’t

compromise performance.

Redefine HD Gaming The ATI Radeon HD 4800 Series GPUs deliver a cinematic gaming experience with unprecedented

performance. The powerful new TeraScale graphics will propel you deep into your gameplay with seamless frame rates

and high resolutions. Enhanced anti-aliasing (AA) and anisotropic filtering create

striking graphics with unparalleled realism so you can max out the settings of the most demanding next-generation games

or revitalize your favorite titles. Play today while preparing for tomorrow with tessellation, support for DirectX® 10.1 and

scalable ATI CrossFireX™ technology.

Go Beyond HD Video

Add an ATI Radeon HD 4800 Series GPU to your PC and watch the latest Blu-ray and HD movies play with incredible

fidelity –upscale to nearly twice the display resolution of HD content.* Take full advantage of Blu-ray

functionality with dual-stream, picture in picture (PIP) capabilities. Sophisticated new features within ATI Avivo™ HD

technology provide a truly responsive experience.

Support for the latest audio visual interconnects ensures you can take advantage of the latest display technology.

Break-throughEfficiency Like its predecessors, the ATI Radeon HD 4800 Series GPUs offer optimal performance and

break-through efficiency with platform-independent intelligent power management. Regardless of platform, ATI

PowerPlay™ delivers the power needed to blaze through even the most intense games while intuitively conserving energy

at idle or when demand is low.

PRODUCT FEATURES ●GPU: Radeon™ HD4870

●Bus Type: PCI-Express

●Core Clock: 795 MHZ

●Memory Size: 512MB

●Memory Configuration: 16Mx32 GDDR5

●Memory Interface: 256-Bit

●Memory Speed: 1100 MHz

●Two Dual Link DVI + HDTV-Out (HDMI support VIA Adapter)

SYSTEM REQUIREMENT EXTERNAL POWER REQUIREMENT 2 x 6-pin

CPU Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or

higher

CPU SPEED 2.0 Ghz or faster

MEMORY 1024MB

HARD DISK 400MB

SYSTEM BUS PCI Express x16

SLOT DOUBLE

CHASSIS ATX

MONITOR Digital flat-panel (DFP) displays or DVI-I Compatilbe or

digital CRT display or High-resolution VGA monitor

INTERNET ACCESS NO

USB NO

CD DVD YES

POWER SUPPLY 450 Watt or greater power supply with 75 Watt 2 x 6-pin PCI

Express® power connector recommended.

OPERATING SYSTEM WINXP WINXP64 WINVISTA32 WINVISTA64 MCE WIN2003

FORM FACTOR Standard Profile Full-Height

DIMENSIONS [PRODUCT] : 11.75 X 9.5 X 3 [RETAIL BOX] : 11.75 X 9.5 X 3 [S BUILDER] : 11.75 X 7.25 X 2

WEIGHT [PRODUCT WEIGHT] : 2.75 LBS [PRODUCT WITH CONTENT WEIGHT] : 3.55 LBS

UPC RETAIL PACKAGE UPC : 757448006292

PACKAGE CONTENT

●DIAMOND VIPER HD 4870 OVER CLOCKED PCIE

512MB GDDR5 VIDEO CARD

●QUICK START GUIDE

●INSTALL CD

●S-VIDEO CABLE

●CROSSFIRE BRIDGE INTERCONNECT

●DIAMOND WARRANTY CARD

●2 DVI-TO-VGA ADAPTERS

●COMPONENT HDTV ADAPTER

●DVI-TO-HDMI ADAPTER

PRODUCT WEBPAGE http://www.diamondmm.com/4870PE5512OC.php

PRODUCT NOTES California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth

defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if

heating the solder.

The information presented in this document is for information purposes only. The information contained herein is subject to change and may be rendered inaccurate for many reasons, including, but not limited to product and specification

changes, new model and/or product releases, product differences between differing manufacturers, software changes, BIOS flashes, firmware upgrades, or the like. Diamond Multimedia assumes no obligation to update or otherwise correct or

revise this information. Diamond Multimedia makes no representations or warranties with respect to the contents hereof and assumes no responsibility for any inaccuracies, errors or omissions that may appear in this information. However,

Diamond Multimedia reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Diamond Multimedia to notify any person of such revisions or changes. Please see your Diamond

Multimedia sales representative for any questions regarding this product information.

Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.

AMD,ATI, Graphics by ATI, Graphics by AMD, and Radeon are trademarks of Advanced Micro Devices, Inc.

All other trademarks are property of their respective owners.

Diamond Multimedia

20740 Plummer St. Chatsworth, CA 91311

Tel: (818) 534-1414 Fax: (818) 773-9619

http://www.diamondmm.com
