DH electronics DHMI 10.1 Manual de usuario

DHMI 10.1

Manual

Your Digital Heroes.

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 2/

History

Revision

Date

Description or changes

Name

R01 31.03.2021 Draft MAD

R01

05.07.2021

Final version incl. additional information on the power supply unit used

MAD

R01

05.07.2021

Release

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 3/

Dear customers,

we are passionate about technology - and have been for over 25 years. Our motivation is to be a pioneer for the

digital future with our solutions. In doing so, our explorer nature drives us to realize our vision of the future and

to think outside the box.

We see ourselves as Digital Heroes who work with you to find an individual solution to your problem - and this

product is no exception.

Thank you for choosing us and thus a product that contains innovative solutions down to the smallest detail. To

ensure that you can use our product permanently and without errors, please read this manual carefully and keep

it for future reference.

However, if you ever have a problem, please contact us. We are here for you and will be happy to help you at any

time.

We wish you much pleasure with this product.

Your Digital Heroes Team.

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 4/

Table of contents

1 General product information .................................................................... Fehler! Textmarke nicht definiert.

1.1 Information on the product ..............................................................................................................7

1.2 Scope of delivery ............................................................................................................................7

1.3 Manufacturer and customer service address.................................................................................... 7

2Product description ...............................................................................................................................8

2.1 Overview ........................................................................................................................................9

2.2 Pin assignment ............................................................................................................................ 10

2.3 Technical data .............................................................................................................................. 10

3Safety instructions .............................................................................................................................. 12

3.1 Graphical symbols for safety-related information ........................................................................... 12

3.2 Activities according to user groups ................................................................................................ 12

3.3 Intended use ................................................................................................................................ 12

3.4 User group ................................................................................................................................... 13

3.5 Hazards ....................................................................................................................................... 13

3.6 Special precautions ...................................................................................................................... 13

4Preparing the product for use .............................................................................................................. 13

4.1 Transport and storage .................................................................................................................. 13

4.2 Disposal of goods and packaging material ...................................................................................... 13

4.3 Preparation before installation ...................................................................................................... 14

4.4 Commissioning ............................................................................................................................ 15

5Operation ........................................................................................................................................... 15

5.1 Interfaces .................................................................................................................................... 15

5.1.1 Power supply......................................................................................................................... 16

5.1.2 Industrial conne ctors ............................................................................................................. 16

5.1.3 USB ...................................................................................................................................... 17

5.1.4 Etherne t................................................................................................................................ 17

5.1.5 LEDs ..................................................................................................................................... 17

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 5/

5.1.6 Resistive touchscreen ............................................................................................................ 17

5.2 Frame and installation situation .................................................................................................... 17

5.3 Normal operation ......................................................................................................................... 17

5.4 Malfunction .................................................................................................................................. 17

6Software documenta tio n...................................................................................................................... 18

6.1 Web browser ................................................................................................................................ 18

6.1.1 Views .................................................................................................................................... 18

6.1.2 Operation .............................................................................................................................. 19

6.1.3 Debugging ............................................................................................................................. 19

6.2 Configuration web server .............................................................................................................. 21

6.2.1 Access .................................................................................................................................. 21

6.2.2 Login .................................................................................................................................... 21

6.2.3 Navigation bar ....................................................................................................................... 22

6.2.4 Syste m info ........................................................................................................................... 22

6.2.5 Change password .................................................................................................................. 23

6.2.6 Date Time .............................................................................................................................. 23

6.2.7 Network settings ................................................................................................................... 24

6.2.8 Web browser settings ............................................................................................................ 25

6.2.8.1 Appearance .................................................................................................................... 25

6.2.8.2 Advanced........................................................................................................................ 25

6.2.9 Security................................................................................................................................. 26

6.2.10 Debug ................................................................................................................................... 27

6.2.11 Backup/Restore ..................................................................................................................... 27

6.2.11.1 Config backup ................................................................................................................. 27

6.2.11.2 Config Restore ................................................................................................................ 27

6.2.11.3 Logs backup ................................................................................................................... 28

6.3 SSH access .................................................................................................................................. 28

6.4 DHMI update ................................................................................................................................ 28

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 6/

6.4.1 Update archive ...................................................................................................................... 28

6.4.2 Update process...................................................................................................................... 29

6.4.3 Adoption of system settings during an update .......................................................................... 30

7Maintenance ....................................................................................................................................... 30

8Decommissio ning, dismantling, dispo sal .............................................................................................. 30

9Ordering information........................................................................................................................... 31

10 Customizatio n ................................................................................................................................. 31

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 7/

1 General product information

1.1 Product details

With DHMI 10.1 you have chosen a product from our DHMI product family. The abbreviation HMI stands for Human

Machine Interface. Our DHMIs are equipped with resistive touch displays and our SOM as standard. In addition,

they are available both frameless and with an anodized aluminum frame (except DHMI 4.3 here only frameless).

To ensure long-lasting, error-free use, these instructions must be read carefully before use and be available for

future reference. Further useful information, documents and software can be found at www.dh-electronics.com.

Product name

DHMI

10.1

Product revision

R01

Product variant

DH Standard

Manufacturer

DH electronics GmbH

1.2 Scope of delivery

The following list provides an overview of the components included in the scope of delivery.

Manual

DHMI 10.1

1.3 Manufacturer and customer service address

We make every effort to provide you with all the necessary information about our products. However, if you are

unable to resolve a situation on your own with the help of the user manual and documents on the website, we will

be happy to help you. Please feel free to contact one of our employees.

About our website: https://www.dh-electronics.com/kontakt-support

By Email: support@dh-electronics.com

By phone: +49 8662 4882 0

By mail: DH electronics GmbH, Am Anger 8, 83346 Bergen, Germany

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 8/

2Product description

The DHMI 10.1 is a compact touch panel computer that has already proven itself in harsh industrial environments.

Thanks to resistive 4-wire touch, operation is possible at any time even under difficult conditions, for example

with gloves or in damp conditions. We use high-performance and at the same time energy-saving DHCOM mod-

ules from our DHSOM product family as the computer core, giving you the greatest possible flexibility in the choice

of computer module. In the following we present the advantages of our touch panel computers compared to com-

petitive products:

DH Modular system

Thanks to our family concept based on a modular system, you can configure your HMI entirely according to

your wishes and requirements. To do this, use existing components that have been proven in practice and

combine them as you wish to obtain the optimum solution for your application. Our modular principle gives

you maximum flexibility and allows you to develop the right solution for you quickly and cost-effectively. In

addition to the frame design, you can also determine the choice of computer module and interfaces yourself

during customized development.

Everything from one source

DH electronics is characterized by combined know-how in the fields of software and hardware. Our experi-

ence in both areas enables us to develop completely thought-out, high-performance complete devices,

which we realize completely ourselves from the idea to the implementation. As our customer, you will al-

ways have a competent contact person at hand for all matters, who will take care of your request as quickly

as possible.

Fast and cost-effective development

Thanks to the use of our proven computer modules from the DHSOM product range, we can offer you a quickly

available solution at favorable conditions. Computing power, interfaces, operating system and much more

can thus be individually adapted to your needs.

Cost-saving solution thanks to innovative 5-cent cooling system

Our innovative cooling solution eliminates the need for conventional heat sinks, saving space and cost. In-

stead, heat is dissipated from the processor through thermal vias into the inner copper layers of the PCB over

a 5-cent copper area using a gap pad. There, the heat is distributed evenly over the carrier board and is

dissipated by it to the environment primarily by convection and thermal radiation. The even heat distribution

protects the remaining components from overheating.

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 9/

2.1 Overview

Figure 1- Front DHMI 10.1

Figure 2– Rear DHMI 10.1

Manual DHMI 10.1

DH electronics GmbH

R01 USM_DHMI 10.1 Page 10/

2.2 Pin assignment

In the following figure, the connections are shown once again in enlarged form and labeled. Detailed information

about the interfaces can be found in chapter 5.1.

Note

The assignment of the RJ45 sockets corresponds to the Ethernet standard.

The assignment of the USB sockets corresponds to the USB 2.0 standard.

2.3 Technical data

The following table gives an overview of the technical data of the Touch Panel Computer.

CPU DETAILS

CPU Name

NXP i.MX6 Solo

(standard version, other CPUs are also possible)

CPU

Type

ARM Cortex®

-A9

CPU Clock

Up to 800 MHz

MEMORY

DDR3 RAM

1024 MB

eMMC Flash

4 GB

E2Prom

128 byte

Micro SD Socket

Available on module

Real Time Clock (RTC)

Available on

module
