1. DESCRIPTION AND OPERATION
1.1. Application
The test set is designed for testing parameters of a regenerative self-contained
breathing apparatus (hereinafter referred to as BA), self-contained panoramic masks,
and resuscitators.
The test set must be used in units that operate or service BA.
The CheckUp is used to conduct the following:
• testing oxygen breathing apparatuses whose parameters meet the requirements
of relevant regulations: EN 145, ДСТУ EN 145, ДСТУ 3856, ГОСТ Р 12.4.253,
ГОСТ Р 53256 or equivalent (P-30 and its modifications, P-70, BG-4 etc.);
• testing the panoramic masks that meet the requirements of relevant regulations:
EN 136, ДСТУ EN 136, ГОСТ Р 12.4.189, ГОСТ Р 53257or similar;
• testing the parameters of GS-10 resuscitator;
• testing the individual components of BA.
The test set is used for testing of the following:
• leaktight of the BA breathing system by positive and negative pressure;
• leaktight of the breathing system of the GS-10 apparatus at positive pressure;
• leaktight of panoramic masks under negative pressure;
• continuous oxygen supply by the BA pressure regulator;
• emergency oxygen supply by the BA bypass valve;
• operation pressure for the BA relief valve;
• lung demand valve open pressure check;
• performance of the lung demand valve check;
• minimum and maximum inspiratory pressures of GS-10 apparatus;
• inhalation and exhalation time of GS-10 apparatus;
• time of action of the GS-10 in AVL mode;
• vacuum pressure of inhalation device of GS-10 apparatus;
• GS-10 inhalation device preformance check.
NOTE!
When using the regulatory documents specified in this manual, you should be guided
by the current version of the publication of the standard. In case of cancellation of
the standard specified in this manual, the standard issued for replacement should be
followed.
