DEWESOFT DS-CAL Manual de usuario



DS-CAL

SOFTWARE USER MANUAL

DS-CAL V20-1



1

DS-CAL
SOFTWARE USER MANUAL


Table of contents
Table of contents 2
About this document 5
1. Legend 5
Introduction 6
1. Calibration system equipment support 6
1.1. Multifunction calibrator support 6
1.2.Digital multimeter support 7
2. Basic principle 7
3. Scope of supply 8
3.1. DS-CAL-BOX 8
4. Optional accessory packages 9
4.1. CHG-CAL-ADAPTER 9
4.2. KRYPTON-TC-CAL-SET 9
4.3. DSI-CAL-SET 10
4.4. DSI-5A-CAL-CABLE 10
Calibration system equipment configuration 11
1. Digital multimeter setup 11
2. Agilent 34401A 11
3. Multifunction calibrator setup 12
3.1. FLUKE 57XX setup 12
3.2. FLUKE 55XX setup 13
Connecting the calibration system together 14
1. Digital multimeter 14
2. Multifunction calibrator 15
3. DS-CAL test board 16
3.1. DS-CAL1 v1 test board 17
3.2. DS-CAL1 v3 test board 17
3.3. DS-CAL2 test board 18
Software and driver installation 19
1. Installation of the USB-to-serial adapter driver 19
2. Installation of DSCalibrator software 19
Configuring the DSCalibrator software 21
1. General settings 21
2. Users 21
3. External devices 21
4.Database 23
5. Tolerance 24
6. Custom fields 25
Using the DSCalibrator software 27
DS-CAL V20-1 2/67 

DS-CAL
SOFTWARE USER MANUAL


1. Adjustment 27
2. Calibration check 28
3. Adjust and Check 29
4. Calibration procedure 29
5. Special considerations 29
5.1. Omission of tests 30
5.2. Different module grounding setting 30
5.3. Dewesoft UUT without CAN port 31
Connecting the UUT 32
1. Sirius USB 32
2. Sirius EtherCAT 33
3. Sirius Mini 35
4. Sirius modules 35
4.1. Sirius ACC and HS-ACC 36
4.2. Sirius CHG and HS-CHG 36
4.3. Sirius HV and HS-HV 37
4.4. Sirius LV and HS-LV 38
4.5. Sirius MULTI 39
4.6. Sirius STG and STGM 39
4. 7. Sirius HD-ACC 41
4.8. Sirius HD-LV 41
4.9. Sirius HD-STGS 42
4.10. Sirius AO 43
5. DEWE43 44
Table 17: DEWE43 UUT connection description 45
6. Krypton 45
6.1. Krypton 8xTH, 16xTH 46
6.2. Krypton 4xLV, 8xLV 48
6.3. Krypton STG 48
6.4. Krypton RTD 48
7. DSI adapters 49
7.1. DSI-ACC, DSI-ACC-0.16Hz, DSI-ACC-20mA 51
7.2. DSI-V-200 51
7.3. DSI-CHG-50 51
7.4. DSI-TH-K, DSI-TH-T, DSI-TH-J, DSI-TH-C 52
7.5. DSI-RTD 53
7.6. DSI-5A 54
Appendix A: Connectors of the DS-CAL test board 56
1. CAN connector 56
2. Sync connector 57
3. PPS connector 57
4. Power supply connector 58
5. GND connector 58
DS-CAL V20-1 3/67 

DS-CAL
SOFTWARE USER MANUAL


11. Appendix B: Glossary and abbreviations 59
12. Warranty information 61
12.1. Calibration 61
12.2. Support 61
12.3. Service/repair 61
12.4. Restricted Rights 61
12.5. Printing History 62
12.6. Copyright 62
12.7. Trademarks 62
13. Safety instructions 63
13.1. Safety symbols in the manual 63
13.2. General Safety Instructions 63
13.2.1. Environmental Considerations 63
13.2.2. Product End-of-Life Handling 63
13.2.3. System and Components Recycling 63
13.2.4. General safety and hazard warnings for all Dewesoft systems 64
14. Documentation version history 67



 
DS-CAL V20-1 4/67 

DS-CAL

SOFTWARE USER MANUAL



2. About this document



2.1. Legend



The following symbols and formats will be used throughout the document.



Important

It gives you important information about the subject.

Please read carefully!



Hint

It gives you a hint or provides additional information about a subject.



Example

Gives you an example of a specific subject.



 

DS-CAL V20-1 5/67 

DS-CAL

SOFTWARE USER MANUAL



3. Introduction



The DS-CAL test board is a calibration device and DSCalibrator is the software used for calibration and

testing of DEWESoft UUT. The calibration system consists of:

● A computer or PC (running DSCalibrator software)

●Multifunction calibrator

●Digital multimeter

●DS-CAL test board

●UUT

●Proper set of cables according to the UUT



In order for a correct operation of your calibration system the procedures described in this manual must

be followed. If you should encounter any problems during the installation and use please feel free to

contact our support team.



3.1. Calibration system equipment support



Please read this chapter carefully! It contains important information about calibration system

equipment support and usage.

3.1.1. Multifunction calibrator support

The following multifunction calibrator models are supported:

●Fluke 5500A

●Fluke 5502E

●Fluke 5520A

●Fluke 5700A

●Fluke 5720A

●Fluke 5730A



Feature

FLUKE 55XX series

FLUKE 57XX series

DSI thermocouple calibration

(for example DSI-TH-K)

Supported

NOT POSSIBLE*

Krypton 8xTH / 16xTH

Supported

NOT POSSIBLE*

Extended filter tests on Sirius HS

modules

NOT POSSIBLE**

Supported

Current clamp calibration

Supported

NOT POSSIBLE***

Table 3: Multifunction calibrator calibration feature support matrix



DS-CAL V20-1 6/67 

DS-CAL

SOFTWARE USER MANUAL



* - Thermocouple output is not available by the multifunction calibrator.

** - Extended frequency range for AC voltage is not supported by the multifunction calibrator.

*** - Supported AC / DC current output capabilities are too low.

3.1.2.Digital multimeter support

The following digital multimeter models are supported:

●Keysight 34465A

●Agilent 34410A

●Agilent 34401A



3.2. Basic principle

The multifunction calibrator is used for generating signals which are measured by the DEWESoft UUT.

The DSCalibrator software (in cooperation with DEWESoft) records these measurements and also

makes adjustments to the calibration factors stored in the UUT. The DS-CAL test board is used for

distributing the signals to and from the UUT and is controlled by the DSCalibrator software over the CAN

or USB interface. The digital multimeter is used for measuring output voltage or current (for example

the excitation voltage)



DS-CAL V20-1 7/67 

DS-CAL

SOFTWARE USER MANUAL



3.3. Scope of supply

3.3.1. DS-CAL-BOX

Qty

Type

Usage

1x

DS-CAL-BOX

DS-CAL test board.

1x

DC Power supply 60W 12V including power

cord

Power supply for DS-CAL test board.

1x

USB‑A to USB‑B‑mini cable, 1.8m

Used for connecting DS-CAL test board to

the PC.

1x

Installation USB stick

Contains the software, drivers and the

manuals.

2x

USB‑to‑serial converter including RS232

cable, 1m (D9f-D9f‑1M‑RS232)

Used for connecting the PC, multifunction

calibrator and the digital multimeter

together.

1x

CAN Y‑cable, 1.2m (D9F‑2D9F‑1.2m)

Used for connecting the CAN port(s)

between UUT and the DS-CAL test board.

1x

PPS cable, 2m (L1B4M‑BNC‑2m)

Used for a precise PPS time source signal.

Connects to the DS-CAL test board.

2x

Sync cable, 3m (L00B4m‑L00B4m‑3m)

Used for connecting the Sync ports between

the UUT and the DS-CAL test board.

1x

Banana cable, 2m (CABLE‑GND) with

crocodile clip

Used for connecting GND between the UUT

and the DS-CAL test board.

12x

Safety test lead 4mm, red with gold‑plated

contacts, 1m

4x used for multifunction calibrator and

digital multimeter connection with the

DS-CAL test board.

11x

Safety test lead 4mm, black with gold‑plated

contacts, 1m

3x used for multifunction calibrator and

digital multimeter connection with the

DS-CAL test board.

8x

BNC‑to‑BNC cable, 0.5m

Used for connecting BNC UUT inputs and

DS-CAL test board.

8x

BNC‑to‑BNC cable, 1.2m

Used for connecting BNC UUT analog

DS-CAL V20-1 8/67 

DS-CAL

SOFTWARE USER MANUAL



outputs and DS-CAL test board.

8x

MULTI cable, 0.4m (D15m‑D15m‑0.4m)

Used for connecting MULTI UUT inputs and

DS-CAL test board.

8x

DSUB9 cable, 0.4m (D9m‑D9m‑0.4m)

Used for connecting all DSUB9 UUT inputs

and DS-CAL test board.

8x

Counter cable, 0.4m (L1B7m‑L1B7m‑0.4m)

Used for connecting UUT counter inputs and

DS-CAL test board.



Table 4: Scope of supply for DS-CAL-BOX package



Illustration 2: CHG-CAL adapter accessory package

3.4. Optional accessory packages

3.4.1. CHG-CAL-ADAPTER

Accessory package CHG-CAL-ADAPTER is required for calibration of SIRIUS-CHG and SIRIUS-HS-CHG

modules and for DSI-CHG-50 adapter. CHG-CAL adapter is shown on the Illustration 2.

3.4.2. KRYPTON-TC-CAL-SET

Accessory package KRYPTON-TC-CAL-SET is required for calibration of Krypton 8xTH / 16xTH

instruments.

DS-CAL V20-1 9/67 

DS-CAL

SOFTWARE USER MANUAL



Illustration 4: DSI-5A-CAL-CABLE accessory package

3.4.3. DSI-CAL-SET



Accessory package DSI-CAL-SET is required for calibration of DSI adapters. Contents of the package are

shown on the Illustration 3.

3.4.4. DSI-5A-CAL-CABLE

Accessory package DSI-5A-CAL-CABLE is required for calibration of DSI-5A adapters. Contents of the

package are shown on the Illustration 4.



 

DS-CAL V20-1 10/67 
