Denver SW-154 Manual de usuario

Smart Bracelet

User Manual

SW-154

facebook.com/Denver.eu

1.This product is not a toy. Keep it out of reach of children.

2.Warning: This product includes lithium polymer battery.

3.Keep product out of the reach of children and pets to avoid chewing and swallowing.

4.Product operating and storage temperature is from 0 degree Celsius to 40 degree Celsius.

Under and over this temperature might affect the function.

5.Never open the product. Repairs or service should only be performed by qualified personnel.

6.Do not use for water depth below 1 meters!

7.Please remove the Smart watch from arm in case of any leakage or excessive heat from the product

to avoid burns or rash.

8.Using other accessories than the ones delivered with the product can cause abnormal functionality.

Please read the safety instructions carefully before using the product for the first

time and keep the instructions for future reference.

Safety information

IMPORTANT! BPM-Heart Rate-Blood Oxygen app measurements are

not intended for medical use, including self diagnosis or consultation with

a doctor, and are only designed for general fitness and wellness purposes.

This is not a medical diagnostic device.

ENG-1

1. Compatible System of Phone and BLE Version:

Android 4.2 and above iOS 8.0 and above BT4.0

2. User Preparation

Please make sure the device is fully charged before using for the first time.

3. “Fit pro” APP Download

Scan the QR Code

Download the APP from the

4. Bracelet Connection

First, long press the touch button to turn on the bracelet, and make sure the Bluetooth on

your phone is on; Second, open the APP; tap the Function List on the top

ENG-2

“Fit pro”

APP STORE / GOOGLE PLAY STORE

CHARGING INSTRUCTION

USB

PLUG

It is easiest by

pulling sideways

Strap ans case separatlyUSB Charging port is placed

behind the top strap

Please insert it into USB port

to charge & pay attention

to the USB plug direction

left corner; tap the APP icon and “Search”; choose the right bracelet MAC number. Finally

once “Bluetooth pairing request” pops up, tap “Pair” to connect.

5. Bracelet Operation

6. Function Instruction

Home Display: show Time, Date,

Battery Level, etc;

Pedometor: 24 hours recording on the

bracelet; clear bracelet data at 24:00; view

history in the APP.

ENG-3

When the bracelet is successfully connected with the phone, the

bracelet will synchronize the phone’s time and date. And the APP

will synchronize the bracelet’s sports data, heart rate monitoring

data, blood pressure data, etc. Short press the bracelet touch

button to switch the functions, long press the touch button for

entering the functions. To switch the watch off, enter the “OFF”

menu and hold down the touch button for 3 seconds. To turn the

watch on, press the touch button for 3 seconds.

Exercise: counts your daily exercise time;

clear data at 24:00; view history in the APP.

Heart Rate Monitor: automatically measures

the heart rate when the function is turned on,

and the heart rate data will be saved in the

APP.

SPO2Test: automatically measures the SPO2

rate when the function is turned on, and the

SPO2rate data will be saved in the APP.

Blood Pressure:

automatically measures blood pressure when

the function is turned on, and the blood

pressure data will be saved in the APP.

Smart Clock: find “Smart Clock” in the APP and set the time. Tap the time, you can set

the repeat mode, and tap Complete to save the settings. The bracelet will vibrate when

the set time is reached.

ENG-4

ENG-5

Sleep Monitor: automatically records your sleep status and analyzes your deep sleep

and light sleep hours. The data will be saved in the APP.

Sedentary Reminder: open the function in the APP and set the time duration. The

bracelet will vibrate when the set time is reached.

Reminder for Drinking: open the function in the APP and set the time duration. The

bracelet will vibrate when the set time is reached

Anti-lost-: open the function in the APP. The bracelet will vibrate when the phone is

taken away

Message Reminder: open the function in the APP. The bracelet will vibrate when the

phone receives a new message (SMS, QQ Facebook, Twitter, Whatsapp, Wechat).

·Weather: It could show the weather info of current and tomorrow on the weather page.

Weather info is synced after connecting with the APP, it will not be updated after a long

Disconnection.

·Music: After Connecting the smart watch, you can remote Control the music player on

your phone.

Shake the Bracelet to Take Photos: open the function in the APP. Enter into the camera

by tapping “Shake the Bracelet to Take Photos” in the Function List. (Make sure the

mobile phone setting is enabled: Allow the APP to take photos and save the photos)

Find Bracelet: Tap “Find Bracelet” in the Function List in the APP and the bracelet will

vibrate.

*The company reserves the right to make changes to the contents of the

specifications without notice.

Call Reminder: Open the function in the APP, the bracelet will vibrate during incoming

call.

Restore Factory Settings: The data of the smart watch will be cleared after restore.

Please notice - All products are subject to change without any notice. We take reservations for errors

and omissions in the manual.

Electric and electronic equipment and included batteries contains materials, components and

substances that can be hazardous to your health and the environment, if the waste material

(discarded electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can symbol,

seen above. This symbol signifies that electric and electronic equipment and batteries should not be

disposed of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the appropriate and designated

facility. In this manner you make sure that the batteries are recycled in accordance with legislature

and will not harm the environment.

All cities have established collection points, where electric and electronic equipment and batteries

can either be submitted free of charge at recycling stations and other collection sites, or be collected

from the households. Additional information is available at the technical department of your city.

Hereby, A/S declares that the radio equipment type SW-15 is in compliance with

Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following

internet address: and then click the search ICON on topline of website.

ENG-6

Denver

denver.eu

Write model number: SW-15 Now enter product page, and RED directive is found under

downloads/other downloads.

Operating Frequency Range: 2412-2484 MHZ

Max Output Power: 0.555W

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

ENG-7

facebook.com/Denver.eu

Denver A/S

1.Dieses Produkt ist kein Spielzeug. Bewahren Sie das Produkt außerhalb der Reichweite von Kindern auf.

2.Warnung: Dieses Produkt enthält einen Lithium-Polymer-Akku.

3.Bewahren Sie das Produkt außerhalb der Reichweite von Kindern und Haustieren auf, um ein

Verschlucken von Kleinteilen zu vermeiden.

4.Die Betriebs- und Lagertemperatur des Produkts liegt zwischen 0 und +40 °C. Eine Unter- oder

Überschreitung dieser Temperatur kann die Funktion beeinträchtigen.

5.Öffnen Sie das Produkt nicht. Das Berühren der Elektronik kann zu einem Stromschlag führen.

Reparatur- und Wartungsarbeiten dürfen nur von qualifiziertem Personal durchgeführt werden.

6.Nicht für Wassertiefen von mehr als 1 m verwenden!

7.Nehmen Sie die Smartwatch im Fall einer Undichtigkeit oder übermäßiger Hitzeentwicklung des

Produkts ab, um Verbrennungen oder Ausschlag zu vermeiden.

8.Die Verwendung von anderem als dem mitgelieferten Zubehör kann zu anormalen Funktionen führen.

Bitte lesen Sie die Sicherheitshinweise vor der ersten Verwendung des Produkts

aufmerksam durch und bewahren Sie die Anleitung zum späteren Nachschlagen auf.

Sicherheitshinweise

GER-1

WICHTIG! BPM - Herzfrequenz - Blut Die Messungen der Sauerstoff-App

sind nicht für den medizinischen Gebrauch bestimmt, auch nicht für die

Selbstdiagnose oder die Konsultation mit einem Arzt; sie sind nur für

allgemeine Fitness- und Wellness-Zwecke gedacht.

Dies ist kein medizinisches Diagnosegerät.

1. Kompatibel mit Handys und Versionen:

Android 4.2 und höher iOS 8.0 und höher BT4.0

2. Vorbereitung durch Benutzer

Achten Sie darauf, dass das Gerät vor Erstgebrauch vollständig aufgeladen ist.

3. „ “-App herunterladen

Scannen Sie den QR-Code.

Laden Sie die „Fit pro“-App aus dem

4. Armband verbinden

Halten Sie zunächst die Taste gedrückt, um das Armband einzuschalten und vergewissern

Sie sich, dass die Bluetooth-Funktion auf Ihrem Handy eingeschaltet ist. Öffnen Sie die

GER-2

Fit pro

APP STORE / GOOGLE PLAY STORE

CHARGING INSTRUCTION

USB

PLUG

It is easiest by

pulling sideways

Strap ans case separatlyUSB Charging port is placed

behind the top strap

Please insert it into USB port

to charge & pay attention

to the USB plug direction
