Sound Bar User Manual

Operating Introduction

a. Place the Soundbar on flat surfaces. Alternatively, you can wall mount the Soundbar with the screws

provided. This Soundbar can be connected to play sound in three different ways:

1. Connect to your Television Headphone Socket

2. Connect to any Bluetooth enabled device

3. Connect to a USB Drive (stick) loaded with music files

b. Cable and external devices connection arrangements:

LINE IN

DC 12V IN

c. At the right hand side of the Sound Bar are the manual control buttons:

d. Front LED Display showing the different input modes

Line In

Hold down /MODE for Power

On/Standby.

Hold down /MODE for Power

On/Standby.

Press /MODE to change the

mode between: Line In ->

Bluetooth -> USB Drive

Press /MODE to change the

mode between: Line In ->

Bluetooth -> USB Drive

Press/Hold down II / MUTE for

Pause/Play. (USB Drive)

Press/Hold down II / MUTE for

Pause/Play. (USB Drive)

Press/Hold down II / MUTE for

Mute / No Mute. (Line In)

Press/Hold down II / MUTE for

Mute / No Mute. (Line In)

Hold down VOL+ /I for Volume

up.

Hold down VOL+ /I for Volume

up.

Press VOL+ /I for Next USB

Drive Song.

Press VOL+ /I for Next USB

Drive Song.

Hold down VOL- / I for Volume

down.

Hold down VOL- / I for Volume

down.

Press VOL- / I for Previous

Drive Song.

Press VOL- / I for Previous

Drive Song.

USB

LINE IN

DC 12V IN

Bluetooth

USB drive when USB Drive in (no USB drive

will flash Lod and skip to next mode in

seconds)

Front indicator Lights:

Red dot: Soundbar in standby

bt font: Flashing means Bluetooth is waiting to pair with your Bluetooth enabled device.

bt lit and static means a Bluetooth device is paired.

e. Remote control buttons

* EQ (Equalizer) Preset Music tone settings to suit personal taste

While playing music continually press the EQ button to toggle between the

different presets

f. Importance Notice for soundbar mounting on the wall:

1) Wall- mounted installation must be carried out by qualified personnel only.

Incorrect assembly can result in severe personal injury and property damage! (If you intend to

install this product yourself, you must check for installations such as electrical wiring and plumbing,

which may be hidden inside or behind the wall.)

2) It is the installer’s responsibility to verify and confirm that the wall will safely support the total load of

the unit and wall brackets.

3) Additional tools (not included) are required for the installation.

4) Do not overtighten screws.

5) Use an electronic stud finder to check the wall type before drilling and mounting

6) The proposed height on the wall is 1.0~1.5meters

Technical Specification

Power/Amps: Input: AC110~240V, 50/60Hz, Output: DC12V, 2.0A

Power consumption: 18W

Max output power: 20W

Power on / Standby

Mute

Volume up

Volume down

I

Previous (USB drive audio)

I

Next (USB drive audio)

II

Play/Pause(USB drive audio)

Repeat (USB drive audio)

Equalizer selection

Mode

Audio source selection

Display

EQ mode

Eq0

Normal

Eq1

Rock

Eq2

Pop

Eq3

Classic

Eq4

Jazz

Eq5

Country

Working temperature: 0~35o C

Bluetooth version: 5.0

Operating frequency range: 2402-2480Mhz

Soundbar measurement: 60cm x 6cm x 6cm

Bluetooth name: DSB-2010MK2

Packing List

. Sound bar

. Manual

. 3.5mm to 3.5MM audio cable

. Flat head screws (D7.5 * L25mm) x 2

. Remote control with batteries

. Mains Power supply

Please notice - All products are subject to change without any notice. We take

reservations for errors and omissions in the manual.

Electric and electronic equipment contains materials, components and

substances that can be hazardous to your health and the environment, if the

waste material (discarded electric and electronic equipment) is not handled

correctly.

Electric and electronic equipment is marked with the crossed out trash can

symbol, seen above. This symbol signifies that electric and electronic equipment

should not be disposed of with other household waste, but should be disposed of

separately.

All cities have established collection points, where electric and electronic

equipment can either be submitted free of charge at recycling stations and other

collection sites, or be collected from the households. Additional information is

available at the technical department of your city.

Hereby, Inter Sales A/S declares that the radio equipment type DSB-2010MK2 is

in compliance with Directive 2014/53/EU. The full text of the EU declaration of

conformity is available at the following internet address:

www.denver-electronics.com and then click the search ICON on topline of website.

Write modelnumber: DSB-2010MK2.Now enter product page, and red directive is

found under downloads/other downloads

Operating Frequency Range:2402-2480Mhz

Max Output Power: 20W

DENVER ELECTRONICS A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

www.facebook.com/denverelectronics
