Denver DVD-7742 Manual de usuario
User Manual
DVD-7742
IMPORTANT
Please read this manual carefully before operating the DVD PLAYER.
Keep this manual handy for further reference.
17
19
Front and rear panel illustration
Front panel
Rear panel
REMOTE SENSOR
OPEN/CLOSE
PLAY/PAUSEY
TRAY DOOR
STOP
STAND BY
1
2
3
4
5
6
7
Scart Output
POWER INDICATOR
MODEL: DENVER DVD-7742
POWER IN:~110V-~230V 50Hz/60Hz 25W
Serial Number:
POWER IN
~110V-~230V
50Hz/60Hz
12 34
56
7
POWER ON/OFF
When use, direct the remote control to the infra-red sensor (within 45 degrees)
Do not put remote control near to the place with high temperature or moisture
Do not put water or any other object on remote control
Do not use new and old batteries or different type batteries together
Please replace batteries when find remote control is out of work or weak sensitivity.
Remote control
FAST BACKWARD
ENTER
123
456
789
0
10 +
VIDEO
N/P
DEFAULT
CLEAR
GOTO
PROG MARK
PBC
TITLE
SETUP
ZOOM
ANGLE
SUB-T
A-B
REPEAT
OSD
MUTE
RETURN
LANGUAGE
STEP
RANDOM
SLOW
VOL
+
-
L/R
MENU
NUMERIC KEYS
OPEN/CLOSE
PCB
STANDBY
VIDEO
RANDOM
RETURN
LANGUAGE
DEFAULT
CLEAR
PROG
FAST FORWARD
MARK
PREVLOUS
NEXT
STOP
PLAY/PAUSE
L/R
OSD
N/P
ANGLE
REPEAT
STEP
TITLE
MENU
SETUP
ENTER
ZOOM
SUB-T
A-B
VOL+
VOL-
MUTE
GOTO
BACKWARD SLOW
FORWARD SLOW
DVD+ TV
Notes :
There are five ways of connecting the player s AV output to the TV set:
Scart cable (set the video type to RGB)
SCART
MODEL: DENVER DVD-7742
POWER IN:~110V-~230V 50Hz/60Hz 25W
Serial Number:
POWER IN
~110V-~230V
50Hz/60Hz
1. Connect the DVD player to your TV and amplifier.
2. Turn on the TV.
3. Set the TV to the AV input connected to the DVD player.
4. Turn down the volume on your amplifier, and then power it on.
5. Set the amplifier to the AV input connected to the DVD player.
Step 2: Press OPEN/CLOSE either
on the front panel or remote control.
The player displays OPEN on
the display. When the tray is open,
please put the disc on the tray with the
label side up. Press OPEN/CLOSE
again to close the disc tray.
Basic operation
Step 3: Press the PLAY button on the
front panel or remote control. The
player will automatically read and
identify the disc, display the type and
total time and begin playback.
Step 1: Press the STAND BY,
and the player will start, LOAD
is illuminated on the display and
the logo is displayed on TV screen.
SETUP
A. Press to Change items
B. Press ENTER to display the submenu
C. Press SETUP to exit the setup menu
In stop mode, press SETUP, and the TV screen will display the setup menu as follows:
Setup Menu
LANGUAGE SETUP
A.Press ENTER to setup
B.Press to return to the setup
menu
Select <Language> in the setup menu, and press ENTER to display the <Language>
submenu:
Press to select
the menu item
Features setup
2. Select < Subtitle>, and press ENTER to display the <Subtitle> submenu:
A. Press to change your selection
B.Press ENTER to confirm
C.Press to return to the setup menu
D.Press SETUP to exit the setup menu
A. Press tochange your selection
B.Press ENTER to confirm
C.Press to returnto the setup menu
D.Press SETUP to exit the setup menu
1. Select < OSD language>, and press ENTER to display the <OSD language> submenu:
Multi
3. Select < Audio>, and press ENTER to display the <Audio>submenu:
A. Press to change your selection
B. Press ENTER to confirm
C.Press to return to the setup menu
D.Press SETUP to exit the setup menu
Note: Menu language vary by disc
A. Press to change your selection
B. Press ENTER to confirm
C.Press to return to the setup menu
D.Press SETUP to exit the setup menu
4.Select <DVD menu>,and press ENTER to display the <DVD menu> submenu:
Features setup
A.PressENTER to setup
B.Press to return to the setup menu
Video setup
Select <Video> in the setup menu, and press
ENTER to display the <Video> submenu:
Press to select
the menu item
A. Press to change your selection
B. Press ENTERto confirm
C.Press to return to the setup menu
D.Press SETUP to exit the setup menu
1. Select <Aspect Ratio>,and press ENTER to display the <Aspect Ratio> submenu:
A. Press to change your selection
B. Press ENTERto confirm
C.Press to returnto the setup menu
D.Press SETUP to exit the setup menu
2. Select <TV System>, and press ENTER to display the <TV System> submenu
Features setup
A. Press to change your selection
B. PressENTER to confirm
C.Press to return to the setup menu
D.Press SETUP to exit the setup menu
3. Select <Video out>, and press ENTER to display the <Video out> submenu
<RGB>---RGB video output
