Denver 119101030030 Manual de usuario

USER MANUAL

www.denver-electronics.com

Before connecting, operating or adjusting this product, please read this user’s manual

carefully and completely.

ENGLISH

PFF-1011Black

the

reset3

3. Micro SD

Connect to USB device or a computer to transfer data.

2. USB

Connect DCadapter to power device.

1. POWER

Load

external

micro

memory

cards

here.

Press to turn the screen on or off, or long press about seconds to access the menu.

1 2 3

User Manual

Version: 1.0.0

Contents

Getting started..................................................................................................................................... 3

frameo app........................................................................................................................................3

frameo quick setup...............................................................................................................................3

Start using frameo................................................................................................................................ 3

Navigating your frameo........................................................................................................................4

Settings.................................................................................................................................................4

My frame.......................................................................................................................................... 4

Manage photos.................................................................................................................................5

My Friends........................................................................................................................................ 5

Display and slideshow...................................................................................................................... 6

Wi-Fi..................................................................................................................................................6

Backup and Restore..........................................................................................................................6

About................................................................................................................................................ 6

Privacy...................................................................................................................................................7

Warranty, Compliance, Support and Safety information.....................................................................7

Getting started

Thank you for purchasing your very own frameo.

First, to set up your frame follow the ‘Quick start guide’ included in the package.

If you are new to using frameo then start by following the frameo quick setup on page 3 or follow

the on screen guide when powering it on for the first time.

Once you have set up your frameo, start connecting it to your friends and family.

frameo app

To send photos to your frame, use the frameo app for iOS or Android

Find the frameo app on:

Google play by searching for “frameo”

App Store by searching for frameo

frameo quick setup

When starting your frame for the first time, you will need to setup the frame.

ALL SETTINGS CAN BE CHANGED THROUGH THE SETTINGS MENU AFTERWARDS.

First you start by selecting a language. This will be the language used throughout frameo.

Connect your frame to the internet by connecting it to a Wi-Fi.

IF A NEWER VERSION OF THE FRAMEO SOFTWARE IS AVAILABLE,THEN YOU WILL BE PROMPTED WITH AN UPDATE

DIALOG. IT IS RECOMMENDED TO UPDATE YOUR FRAME IMMEDIATELY IF PROMPTED.

Enter your name, and the location where you have placed your frame e.g. “Living room”,

“Kitchen” or “Office”.

Start using frameo

Start by connecting with your friends and family by providing them with a unique code from your

frame.

If you want to be able to send photos to the frame yourself, start by downloading the app for iOS

or Android on App Store or Google Play. Then use the code to connect your frame and app as

described below.

Connecting a new friend:

Make sure that your friend has downloaded and installed the frameo app

Click the add friend icon on your frame . A dialog will appear showing a unique code

which is valid for 24 hours.

Now share this code in whatever fashion you prefer e.g. SMS, E-Mail, IM, phone call, to

your friend.

ONCE YOUR FRIENDS HAVE ADDED THE CODE IN THEIR FRAMEO APP,THEY WILL AUTOMATICALLY APPEAR ON YOUR

FRAME AND BE ABLE TO SEND YOU PHOTOS.

Navigating your frameo

You interact with your frame through its touchscreen.

Swipe left or right to go through your photos.

To access the menu bar, simply tap once on the screen, this will show the menu.

In the menu bar you will find quick access to the add friends dialog and the settings menu

Settings

Through settings, you can personalize your frame to your needs.

My frame

Frame name:

Changes the name of your frame. This is also the name the connected friends and family will see in

their list of connected frames.

Frame location:

Changes the location of your frame. This is the location displayed on your friends'and family's list

of connected frames which can help to distinguish frames from each other.

Set language:

Sets the language throughout your frame.

Sleep mode:

frameo offers a sleep mode which turns off the screen to reduce power consumption while you

e.g. are sleeping. Its default setting is to turn off the screen at 23:00 and turn on the screen again

at 07:00.

To change this just set the sleep mode start/end time.

YOUR FRAME IS NOT POWERED DOWN OR IN STANDBY,SO YOU WILL STILL BE ABLE TO RECEIVE PHOTOS DURING

SLEEP MODE.

Manage photos

Show/hide photos:

Select which photos to show/hide by tapping the particular photos you wish to show/hide. Hidden

photos will NOT be deleted from your frame, you can always select them to be shown again.

Use to select or deselect all

Delete photos:

Select photos that you want to permanently delete from your frame by tapping the photo.

Use to select or deselect all and to delete the selected photos.

Import photos:

Allows you to import photos from an external SD card.

BEFORE YOU TRY TO IMPORT PHOTOS FROM A SD CARD

MAKE SURE YOU HAVE A SD CARD WITH

PHOTOS ON INSERTED INTO YOUR FRAME.

Start by selecting the photos that you want to import onto your frame.

Once selected tap the import button to start the import process.

IT IS CURRENTLY NOT POSSIBLE TO ADD A CAPTION OR DEFINE THE MOST IMPORTANT PART OF THE PHOTO WHEN

USING THE IMPORT FUNCTION. ALTERNATIVELY ADD YOURSELF TO YOUR FRIEND LIST AND SEND THEM USING THE

APP.

My Friends

This list contains all the people that are allowed to send photos to your frame.

Remove person

To remove a person from this list, thereby removing their permission to send you photos, tap the

delete icon . You will then be asked to confirm the removal and if you would like to remove all

photos received from this person.

Add person

To allow a new person to send you photos, simply tap the add friend button and share the

presented code in whatever way you prefer.

Display and slideshow

Timer

Define the duration a photo should be displayed.

Show caption

Sets whether or not to display the captions that your friends have sent with the photo. Check to

display captions. Uncheck to hide captions.

Brightness level

Adjust the brightness level of the screen.

Wi-Fi

Set which Wi-Fi the frame should be connected to.

Backup and Restore

Backup frame to SD card

Tap to make a backup of your photos, friends and settings. The time of latest successful backup

will be displayed.

ANY EXISTING BACKUP ON THE SD CARD WILL BE OVERRIDDEN!

Automatic backup

If checked, your frame will automatically take a backup within 30 hours of you receiving new

photos or making changes on your frame.

REQUIRES THAT YOU HAVE INSERTED A WRITEABLE SD CARD INTO THE FRAME.

Restore from backup

BEFORE YOU ATTEMPT TO RESTORE YOUR FRAME,START BY CONFIRMING THAT YOUR BACKUP IS UP-TO-DATE.

To restore from a backup, you most first reset the frame. It is important to note that you cannot

restore to a new Frameo frame

Reset frame

Removes all data from your frame. This will permanently remove all your photos,

friends/connections and settings.

About

Check for update

Check if an update is available for your frame.

Share anonymous analytics data

Sharing anonymous analytics data helps us tremendously with improving the frameo software. We

understand if you do not wish to share this data with us. Set checked if you wish to help us

improve frameo. Set unchecked to deny the sharing of anonymous analytics data.

Guide

Opens the quick start guide, that was shown when you first started the frame.

Privacy

For more information regarding privacy, please visit privacy.frameo.net

Warranty, Compliance, Support and Safety information

For more information regarding warranty, hardware compliances, support and safety please refer

to the material included in the package.

following internet address: http://www.denver-electronics.com/denver-pff-1011black/

Hereby, Inter Sales A/S declares that the radio equipment type PFF-1011 is in compliance

Electric and electronic equipment contains materials, components and substances that can be

hazardous to yourhealth and the environment, if the waste material (discarded electric and

electronic equipment) is nothandled correctly.

Electric and electronic equipment is marked with the crossed out trash can symbol, seen below.

This symbol signifies that electric and electronic equipment should not be disposed of with other

household waste, but should be disposed of separately.

All cities have established collection points, where electricand electronic equipment can either be

submitted free of charge at recycling stationsand other collection sites, or be collected from the

households. Additional information is available at the technical department of your city.

with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the

Imported by:

DENVER ELECTRONICS A/S

Omega 5A, Soeften

DK-8382Hinnerup

Denmark

acebook.com/denverelectronics
