Denon DP-450USB Manual de usuario

DP-450USB

TURNTABLE

Owner’s Manual

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

Accessories 4

Features 5

Part names and functions 7

Front panel 7

Rear panel 10

Preparations

Assembly 12

Mounting the turntable 13

Mounting the counterweight 14

Mounting the head shell with cartridge 14

Attaching the dust cover 15

Using the dust cover as a record stand 15

Adjustments 17

Adjusting the stylus pressure 17

Adjusting anti-skating 19

Connections

Connecting devices that do not have a phono input 21

Connecting devices that have a phono input 22

Connecting the AC adapter 23

Playback and recording

Record playback 26

Stopping playback 28

Using the automatic stop function 29

Recording to a USB memory device 30

Recording to a USB memory device 31

Installing the “MusiCut for DENON” digital file editing software 32

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

Tips

Contents 33

Troubleshooting 34

Power does not turn on/Power is turned off 35

The turntable does not spin 35

No sound comes out 36

Audio skips, scratches or is distorted 36

Howling is produced 37

The tone arm stops moving halfway 37

Audio cannot be recorded to the USB memory device 38

Cannot install “MusiCut for DENON” onto the computer 38

Appendix

Replacing the stylus 39

Specifications 40

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

PUSH

Quick Start Guide Safety Instructions AC adapter AC adapter plugs

(5 pieces)

Dust cover Dust cover stand Turntable Turntable sheet

45 rpm adaptor Head shell with cartridge Counterweight Audio cable

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

Features

0Converting analog audio from records to digital formats and

saving to a USB memory device

Analog audio can be converted to a digital format (44.1 kHz/192 kbps

MP3 or 44.1 kHz/16 bit WAV) and saved to a USB memory device. This

audio can then be played back on any device that supports playback

from a USB memory device.

0Digital files saved to a USB memory device can be split up, song

information acquired and file names edited using the supported

“MusiCutTM for DENON” software (MP3 only)

Space in between songs (silence) can be searched for manually or

detected automatically to split up the file, track numbers can be

assigned to each song and song information can be acquired from the

Gracenote audio database. For access, download software from our

website for use on your computer.

0Modern design

Much like the PMA-60, DRA-100 and other devices in our Denon

Design Series, all unnecessary decoration has been eliminated for an

updated minimalistic design.

0The automatic arm lifter function automatically raises the tone

arm at the end of record playback

0Stabilizing rotation control improves rotation precision

A sensor has been installed that measures the RPM to maintain a

precise rotation speed.

0An MM cartridge is pre-attached to the headshell to enable

immediate use without assembly

0Equipped with an equalizer switch to turn the built-in phono

equalizer on and off

The phono equalizer is built in to enable direct connection, even if the

amplifier or mini component system does not have phono input. Use the

switch to turn the equalizer off to enable connection to amplifiers with a

phono input.

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

0Equipped with a function to switch RPM between 33 1/3, 45 and

Change record playback speed between 33 1/3, 45 and 78 RPM as

needed. This means that both 7 inch and 12 inch record playback in all

RPM formats is supported.

0Equipped with a dust cover that can be used as a record stand

The included dust cover can also be set up for use as a record stand.

Use it to display the sleeves of your records.

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

Part names and functions

Front panel

3.5

0.5

qe rwytu

oiQ1Q3

Q0 Q2 Q4

For details, see the next page.

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

3.5

0.5

qe rwytu

APower/rpm switch knob

Turn the power on and off and change the RPM as needed during

record playback. (v p. 26)

BTurntable

Attached by mounting on the center spindle on the main unit. The belt

is equipped underneath. (v p. 13)

CTurntable sheet

Mounted on top of the turntable. (v p. 13)

DCenter spindle

Place the turntable and records so that it comes out through the center.

ETone arm

0The counterweight is mounted on the back. (v p. 14)

0The head shell with cartridge is attached to the tip. (v p. 14)

FCounterweight

Attached to the back of the tone arm to adjust stylus pressure.

0“Mounting the counterweight” (v p. 14)

0“Adjusting the stylus pressure” (v p. 17)

GAnti-skating dial

Adjusts anti-skating. (v p. 19)

HUSB indicator

The following indicate the USB recording status. (v p. 31)

0White light on: A USB memory device is inserted in the USB port

0White light flashing: Recording to a USB memory device

IUSB port (T)

Used to insert USB memory devices. (v p. 30)

0The device can convert audio played back from analog sources to digital

formats (MP3 or WAV) and save to a USB memory device. Saved audio files

cannot be played back from a USB memory device.

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

3.5

0.5

1Q3

2Q4

JREC MP3/WAV indicators

Lights in blue after the REC MP3/WAV buttons is pressed to indicate

that the device is currently recording audio to USB. (v p. 31)

KREC MP3/WAV buttons

Used to select the digital audio format (MP3 or WAV) when recording to

USB. Also used to start and stop audio recording. (v p. 31)

LHead shell with cartridge

Attached to the tip of the tone arm. (v p. 14)

MArmrest

Rest the tone arm here when it is not in use for record playback.

NLifter lever

Raises and lowers the tone arm. Lowering the lever slowly lowers the

tone arm to place the stylus without damaging it or the record to be

played.

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel

Rear panel

qewtr

AEQUALIZER ON/OFF switch

This switches the built-in equalizer on and off. Switch as needed

depending on whether the connected amplifier or mini component

system are equipped with phono input or not.

0“Connecting devices that do not have a phono input” (v p. 21)

0“Connecting devices that have a phono input” (v p. 22)

BPHONO OUT connectors

For connecting devices with external audio or phono inputs.

0“Connecting devices that do not have a phono input” (v p. 21)

0“Connecting devices that have a phono input” (v p. 22)

CSIGNAL GND terminal

Use the grounding wire on the supplied audio cable, even when

connecting this device to amplifiers with grounded connections.

(v p. 22)

DAUTO STOP ON/OFF button

Automatically raises the tone arm and stops the turntable at the end of

a record when this function is on during record playback. (v p. 29)

EAC adapter input connector

For connecting the included AC adapter. (v p. 23)

Contents Preparations Connections

Playback and recording

Tips Appendix

Front panel Rear panel
