Denon HEOS 1 Manual de usuario
.
WIIRELESS SPEAKER
BATTERY AND BLUETOOTH FOR HEOS 1
Owner’s Manual
HEOS 1
HEOS 1 Go Pack (Sold Separately)
.
Contents Setup Use Troubleshooting Status LED Appendix
1
INTRODUCTION 5
BEFORE YOU BEGIN 6
System Requirements 6
Network Requirements 6
Controller Requirements 7
Getting To Know Your Speaker 8
Getting To Know Your Battery (Sold Separately) 9
Front panel 10
Controls 11
Back panel 12
Placing Your HEOS device 14
Wall or Ceiling Mounting 14
Powering Your Speaker 15
Getting the HEOS App 15
SETTING UP YOUR FIRST HEOS SPEAKER 16
ADDING MORE HEOS DEVICES 17
Adding Wired Speakers 17
Adding Wireless HEOS devices 17
USING YOUR HEOS DEVICE 18
Selecting a Room/Speaker 18
Listening to Radio 19
Playing music stored on your mobile device 19
Playing music from your networked PC or NAS 20
Playing music from the AUX input 21
Playing music from a USB device 22
HEOS account 23
What is a HEOS account? 23
Why do I need a HEOS account? 23
Signing up for a HEOS account 23
Changing Your HEOS account 23
Playing from Streaming Music Services 24
Adding a Music Service 24
Changing Music Service Settings 24
Listening To The Same Music In Multiple Rooms 25
Grouping Rooms 25
Ungrouping Rooms 26
Grouping All Rooms (Party Mode) 27
Ungrouping All Rooms 28
Stereo Pairing 29
Creating a Stereo Pair 29
Changing the Name of a Stereo Pair 31
Adjusting the Balance 31
Swapping Left and Right Channels in a Stereo Pair 32
Removing a Stereo Pair 32
Using the Now Playing Queue 33
Play Now 33
Play Now & Replace Queue 33
Play Next 33
Add to End of Queue 33
Repeat and Shuffle Playback 33
Rearranging the Now Playing Queue 34
Deleting Songs from the Play Queue 34
Deleting All Songs from the Play Queue 35
Saving Playlists 35
Contents Setup Use Troubleshooting Status LED Appendix
Contents
2
MAKING SPEAKER ADJUSTMENTS 36
Changing the Name of a Speaker 36
Changing the Wireless Network Connection 36
Changing the Speaker’s Equalizer 37
Adjusting the Audio Quality 37
Adjusting the Status Light Brightness 37
Advanced Speaker Settings 38
Network Settings 38
About Wireless Power Saving 38
Firmware Upgrade 39
About 39
UPDATING YOUR SYSTEM 40
ADVANCED FEATURES 41
Submit Diagnostics 41
Sharing Music from your Mobile Device 42
Resetting Your Controller App 42
Power Modes 42
Network Standby 42
Deep Standby 42
Off 42
SETTING UP HEOS 1 Go Pack 43
Connecting the battery 43
Charging the battery 44
Connecting the Bluetooth adapter 44
Pairing the HEOS 1 with your devices 45
CLOSE SPLASHGUARD 46
TURNING OFF THE BATTERY 46
BASIC TROUBLESHOOTING 47
My speaker won’t connect to my network using the audio cable 47
I get a message “Device was not found” 47
The front LED of HEOS 1 flashes repeatedly 48
Cannot pair a Bluetooth mobile device with the speaker 48
Cannot hear Bluetooth music 49
Cannot attach battery 49
Music cuts out or delays sometimes 50
I hear a delay when using the AUX Input with my TV 50
Connecting to a WPS Network 51
Resetting Your Speaker 51
Restoring the Speaker to Factory Defaults 52
Contact Denon 53
Contents Setup Use Troubleshooting Status LED Appendix
3
Status LED Table 54
Battery indicator of HEOS 1 Go Pack 61
When connected to the AC charger/power supply (charging) 61
When running on battery power 61
Supported File Types and Codecs 62
SPECIFICATIONS 63
Speaker Specifications 63
HEOS 1 63
INFORMATION 65
Trademarks 65
License 66
License Information for the Software Used in the Unit 66
Contents Setup Use Troubleshooting Status LED Appendix
4
Thank you for purchasing this HEOS product. To ensure proper operation, please read this owner’s manual carefully before using the product.
NOTE
THIS DOCUMENT CONTAINS INFORMATION THAT IS SUBJECT TO CHANGE WITHOUT NOTICE.
For latest information, please visit HEOSbyDenon.com
INTRODUCTION
The HEOS speaker is part of the HEOS wireless multi-room sound system that enables you to enjoy your favorite music anywhere and everywhere
around your home. By utilizing your existing home network and the HEOS app on your iOS or Android™ device, you can explore, browse, and play music
from your own music library or from many online streaming music services.
0True multi-room audio - play different songs in different rooms or the same song in every room
0Utilizes your existing home wireless network for quick and easy setup
0Industry leading microsecond audio synchronization between HEOS device
0Legendary Denon audio quality
If you are in a hurry, you can be enjoying great sounding music in no time by following the steps outlined in the HEOS Quick Start Guide (packaged with
your HEOS device).
.
HEOS 1 QUICK START GUIDE HEOS 1 Go Pack QUICK START GUIDE
Please continue reading this Owner’s Manual for more detailed information about the features and benefits of your HEOS Speaker.
Contents Setup Use Troubleshooting Status LED Appendix
5
BEFORE YOU BEGIN
NOTE
If you have already installed at least one HEOS device, please skip to the section “ADDING MORE HEOS DEVICES” below (v p. 17).
System Requirements
Before you begin installing your first HEOS speaker, please make sure you understand and meet a few basic requirements.
oNetwork Requirements
Wireless Router - In order to use your HEOS music system, you should have a working wireless (Wi-Fi) network in your home. If you do not have a
wireless network, please contact your local Denon dealer or electronics retailer to assist you with purchasing and installing a wireless network in your
home.
.
The HEOS Extend Wireless Range Extender (sold separately) is available as an accessory, should
you need to setup a new wireless network or extend the range of your existing network. Please
contact Denon for more information about the Wireless Extender.
High Speed Internet Connection - HEOS accesses the Internet to stream music to your home from many popular online music services. HEOS is
also designed to provide you with software updates, which are delivered via your home Internet connection. DSL, Cable, and Fiber services will
provide the best experience and reliability. You may experience performance issues with slower Internet connections like satellite based services.
Contents Setup Use Troubleshooting Status LED Appendix
6
oController Requirements
You can control your HEOS wireless multi-room sound system using the free HEOS app on any iOS or Android mobile device that meets these
minimum requirements:
.
iOS Minimum Requirements
0iOS version 5.0 or later
0iPhone® 3GS or newer
0iPad®
0iPod touch® (3rd generation) or newer
.
Android Minimum Requirements
0Android OS version 2.3 or later
0All resolutions
Contents Setup Use Troubleshooting Status LED Appendix
7
Getting To Know Your Speaker
Unpack your speaker from the box and verify that the following items are included:
.
Quick Start Guide Safety Information Sheets Warranty
(North America model only) Extended Protection Plan
(North America model only)
Audio/Setup cable Ethernet cable
(North America model only)
(European model only)
HEOS 1
Power supply
NOTE
Please use the power supply and power cord included in the box for your device.
Contents Setup Use Troubleshooting Status LED Appendix
8
Getting To Know Your Battery (Sold Separately)
Unpack your battery from the box and verify that the following items are included:
.
Rechargeable battery Bluetooth USB adapter
and Splashguard
Quick Start Guide Safety Information Sheets Warranty
(North America model only)
Extended Protection Plan
(North America model only)
Contents Setup Use Troubleshooting Status LED Appendix
9
oFront panel
.
q q
w
w
HEOS 1 HEOS 1 + Go Pack
ASpeakers
BStatus LED
Please refer to the “Status LED Table” for LED color and state meaning “Status LED Table” (v p. 54).
Contents Setup Use Troubleshooting Status LED Appendix
10
