Denon DHT-C210 Manual de usuario
About manuals 4
About descriptions of this manual 4
Accessories 5
Inserting the batteries 6
Operating range of the remote control unit 6
Part names and functions 7
Sound bar 7
Remote control unit 11
Connections
Positioning 13
Positioning the sound bar in front of a TV 13
Hanging the sound bar on a wall 14
Connecting a TV 16
TV equipped with an HDMI connector and compatible with the
eARC (Enhanced Audio Return Channel) or ARC (Audio Return
Channel) 17
TV equipped with an HDMI connector and incompatible with the
eARC or ARC / TV equipped with an optical digital connector 18
TV equipped with an HDMI connector and incompatible with the
eARC or ARC / TV equipped with an analog connector 19
Connecting an external subwoofer 20
Connecting a playback device 21
Connecting an HDMI device 21
Connecting the power cords 22
Playback
Playing TV, movies and music 23
Adjusting the volume 24
Adjusting the subwoofer volume 24
Turning off the sound temporarily 24
Playing music on a Bluetooth device 25
Pairing a Bluetooth device for the first time 25
Pairing with other Bluetooth devices 26
Playing music with a paired Bluetooth device 26
Settings
Settings 27
Selecting a sound mode 27
Automatically setting to standby (Auto standby function) 28
Reducing the standby power consumption (Deep standby
function) 28
Switching the standby linking via HDMI control function on or off 29
Automatically turning on the power according to the playback of
the playback device (Auto on control function) 29
Operating this unit using the remote control of a TV 31
Contents Connections Playback Settings Tips Appendix
2
Tips
Troubleshooting 33
Power does not turn on / Power is turned off 34
Operations cannot be performed through the remote control unit 35
Trouble teaching this unit remote control commands 35
No sound comes out 36
Bluetooth playback does not work 37
The HDMI control function does not work 37
Audio can be heard coming from the TV’s speakers 37
Resetting factory settings 38
Appendix
About HDMI 39
Trademark information 40
Specifications 41
Contents Connections Playback Settings Tips Appendix
3
Thank you for purchasing this Denon product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
About manuals
The following manuals are included on this unit.
0Safety Instructions (supplied)/Cautions on Using Batteries (supplied)：Describes careful considerations that you should note in order to use this unit
correctly and safety. Please read carefully before using this unit.
0Quick Start Guide (supplied)：Describes the basics about how to use this unit. Please read when you use this unit for the first time.
0Owner’s Manual (this manual)：Describes details about how to use this unit. Also, describes troubleshooting.
About descriptions of this manual
0DHT-C210 is described as this unit in this manual.
0In this manual, when you can operate either the sound bar or remote control, the operations for remote control are mainly described.
0The symbols used in this manual have the following meanings.
Information such as the precautions on the use and the function restrictions.
Information such as supplementary notes that are useful for you to know.
0Contents of this unit may be updated without notice.
Contents Connections Playback Settings Tips Appendix
4
Accessories
Check that the following parts are supplied with the product.
Warranty
Wall mount spacers Remote control unit
(RC-1251)
Optical digital cable
HDMI cable (4K)Power cord
Wall mount template
Quick Start Guide Safety Instructions Cautions on Using Batteries
2× R03/AAA batteries
Contents Connections Playback Settings Tips Appendix
5
Inserting the batteries
1Slide the rear cover off the remote control unit in the
arrow direction.
2Insert two batteries correctly into the battery
compartment as indicated.
Batteries
3Put the rear cover back on.
NOTE
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
30°
30°
Approx. 23 ft/7 m
Contents Connections Playback Settings Tips Appendix
6
Part names and functions
Sound bar
oTop panel
eq
rw
APower operation button (c)
Turns the sound bar power on/off (standby). (v p. 23)
BInput source button (d)
This selects the input source. (v p. 23)
Switches the input source each time the button is pressed.
CBluetooth button (g)
0Switches the input source to “Bluetooth”. (v p. 25)
0Used to pair with Bluetooth devices. (v p. 25)
DVolume buttons (+, –)
These adjusts the volume level. (v p. 24)
Contents Connections Playback Settings Tips Appendix
7
oStatus LED
TV (HDMI eARC/ARC)
TV (OPTICAL)
AUX
Input
source
Off (Standby)
On
Power
Bluetooth
Dolby Atmos＊
Audio format
[Ex.] Input source:
TV (HDMI eARC/ARC)
Dolby
(other than Atmos)
Unsupported
audio format
PCM
(or No Signal)
USB
Pure mode
Sound mode
[Ex.] Input source:
TV (HDMI eARC/ARC)
Blink
once
HDMI
Movie mode
Music mode
Night mode
Blink
once
Blink
twice
Blink
three times
Dialog
enhancer
low
Blink
once
Blink
twice
Blink
three times
Dialog
enhancer
medium
Dialog
enhancer
high
zWhen pure mode is set for the sound mode, Dolby Atmos playback is not supported on this unit. If a Dolby Atmos signal is input when in pure mode, the status LED displays
the signal input as Dolby (other than Atmos).
Contents Connections Playback Settings Tips Appendix
9
oRear panel
qq
wertyui
AWall hook hole
Used to mount the sound bar on a wall. (v p. 14)
BAC inlet
Used to connect the power cord. (v p. 22)
CUSB port
USB playback is available. (v p. 23)
DAnalog audio input connector (AUX IN)
Use a commercially available 3.5 mm stereo audio cable to connect a
TV with an AUX audio output connector. (v p. 19)
EOptical digital input connector (OPTICAL IN)
Use the included optical digital cable to connect a TV with an optical
digital terminal. (v p. 18)
FHDMI IN connector
Used to connect to the HDMI equipment with an HDMI cable.
(v p. 21)
GHDMI connector (TV (HDMI eARC/ARC))
Use the included HDMI cable to connect an eARC or ARC function-
compatible TV. (v p. 17)
HSubwoofer output connector (SUBWOOFER OUT)
Use a commercially available subwoofer cable to connect a subwoofer
with a built-in amplifier. (v p. 20)
Contents Connections Playback Settings Tips Appendix
10
