Denon DNP-F109 Manual de usuario
DNP-F109
NETWORK AUDIO PLAYER
Getting Started
SVENSKA ESpAñol FrANçAiSNEDErlANDS itAliANo DEutSch ENGliSh
РУССКИЙ
POLSKI
Erste Schritte / Mise en route / Guida introduttiva / Antes de empezar / Aan de slag / Att komma igång / Начало работы / Skrócona instrukcja obsługi
1
ENGliSh DEutSch FrANçAiS itAliANo ESpAñol NEDErlANDS SVENSKA
Welcome
Thank you for choosing a DENON network audio player. This
guide provides step-by-step instructions for setting up your
network audio player.
If you have setup problems:
If you need additional help in solving problems, contact
DENON customer service in your area.
See the address sheet included in the box.
2
ENGliShDEutSchFrANçAiSitAliANoESpAñolNEDErlANDSSVENSKA
Before You Begin
What’s In the Box
Coaxial digital
cable
Network audio player
Remote control unit (With battery) System cable
Safety
Instructions
Getting
Started
Owner’s
manual
Service
network list
Required for F109 system connections
DRA-F109
Receiver Speaker systems Speaker cables
Required for Network connections
Modem Router
(or Wi-Fi router)
Network cable
(For Wired connection only)
These drawings are for illustrative purposes only and may not represent
the actual product(s).
3
ENGliSh DEutSch FrANçAiS itAliANo ESpAñol NEDErlANDS SVENSKA
Setup Steps
There are eight steps to the setup process.
1Before using the remote control unit
2Connect to the amplifier
3Selecting to your home network
4Quick Setup (Auto Scan)
5Quick Setup (WPS)
6Quick Setup (Wired)
7Listen to Internet Radio
8Enjoying music using Apple AirPlay
1Before using the
remote control unit
Insulating sheet
4
ENGliShDEutSchFrANçAiSitAliANoESpAñolNEDErlANDSSVENSKA
Wi-Fi connection
Auto Scan v4
Use this connection method
when using an ordinary Wi-Fi
router.
WPS v5
Use this connection
method when using a
Wi-Fi router that supports
the WPS function.
WPS
Wired connection
Wired v6
Use this connection
method when using a
network cable.
2
Connect to the amplifier
DRA-F109
Refer to the DRA-F109 owner’s manual to connect the power cord.
System
cable
Coaxial digital
cable
3Selecting to your home
network
DNP-F109
When the DNP-F109 and DRA-F109 are connected using the system
cable , the DNP-F109 can be controlled using the remote control unit
included with the DRA-F109.
5
ENGliSh DEutSch FrANçAiS itAliANo ESpAñol NEDErlANDS SVENSKA
4Quick Setup (Auto Scan)
Power on.
Select language.
English
[Select Language]
:enter:select
Select “Auto Scan”.
Auto Scan
[Wi-Fi Setup Method]
:enter :back
Select your network.
5AB6789C1D23(...
[Select Network]
:enter :back
100%
If your network name is not listed, select “Scan Again”.
1
2
3
Select “Password” and enter
your network password
using the number keys on the
remote control unit.
abcd1234
[Enter Wi-Fi Password]
:move:select
Select Network Control.
On
[Network Control]
Press ENTER to use the D...
•Select ON to control DNP-F109 from your smartphone, use Apple AirPlay®and
maintain constant network access.
Power consumption during standby power will be slightly higher.
•Select OFF to reduce power consumption during standby.
You can not turn on DNP-F109 or use Apple AirPlay from your smartphone until
DNP-F109 is powered on manually and then connects to your network.
Setup is complete.
Setup Complete!
4
5
6
7
6
ENGliShDEutSchFrANçAiSitAliANoESpAñolNEDErlANDSSVENSKA
5Quick Setup (WPS)
Power on.
Select language.
English
[Select Language]
:enter:select
Select “WPS (Wi-Fi- Protected
Setup)”.
WPS (Wi-Fi Protect
[Wi-Fi Setup Method]
:enter :back
Press the WPS button on
your Wi-Fi router.
WPS
1
2
3
Select “Push Button”.
Push Button
[WPS Setup Method]
:enter :back
Select Network Control.
On
[Network Control]
Press ENTER to use the D...
•Select ON to control DNP-F109 from your smartphone, use Apple AirPlay®and
maintain constant network access.
Power consumption during standby power will be slightly higher.
•Select OFF to reduce power consumption during standby.
You can not turn on DNP-F109 or use Apple AirPlay from your smartphone until
DNP-F109 is powered on manually and then connects to your network.
Setup is complete.
Setup Complete!
5
6
47
7
ENGliSh DEutSch FrANçAiS itAliANo ESpAñol NEDErlANDS SVENSKA
6Quick Setup (Wired)
Connect a Network Cable between the DNP-F109
and your router.
Power on.
Select language.
English
[Select Language]
:enter:select
1
2
3
Select Network Control.
On
[Network Control]
Press ENTER to use the D...
•Select ON to control DNP-F109 from your smartphone, use Apple AirPlay®and
maintain constant network access.
Power consumption during standby power will be slightly higher.
•Select OFF to reduce power consumption during standby.
You can not turn on DNP-F109 or use Apple AirPlay from your smartphone until
DNP-F109 is powered on manually and then connects to your network.
Setup is complete.
Setup Complete!
5
4
8
ENGliShDEutSchFrANçAiSitAliANoESpAñolNEDErlANDSSVENSKA
7Listen to Internet Radio
2
1
233
Press INTERNET RADIO.
Select the item, then press
ENTER.
Repeat step 2to select the
station, then press 1/3.
1
2
DRA-F109
3
DNP-F109
9
ENGliSh DEutSch FrANçAiS itAliANo ESpAñol NEDErlANDS SVENSKA
Tap the AirPlay Icon from
within any music app
that supports AirPlay.
Select the “DNP-F109”
from the AirPlay Device list.
1
2
8Enjoying music using Apple AirPlay
9:41
1:51 -2:22
AM
DENON DNP-F109
iPhone
Cancel
DENON DNP-F109
2
9:41
1:51 -2:22
AM
1
Note:
Make sure your iOS device is on the same
network as the DNP-F109.
