Denon DCD-100 Manual de usuario

DCD-100

COMPACT DISC PLAYER

Owner’s Manual

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Accessories 4

Inserting the batteries 5

Operating range of the remote control unit 5

Features 6

High quality 6

High performance 6

Part names and functions 7

Front panel 7

Display 9

Rear panel 10

Remote control unit 11

Connections

Connecting a digital device 16

Connecting an analog device 17

Connecting the power cord 18

Playback

Basic operation 20

Turning the power on 20

Switching the power to standby 20

Switching the display’s brightness 21

Playing CDs 22

Playing tracks in a specific order (Program playback) 24

Playing DATA CDs (MP3 and WMA files) 25

Playing files 26

Settings

Auto Standby 28

Auto Play 29

Sleep timer function 29

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Tips

Tips 31

Troubleshooting 32

Appendix

Playable media 36

Discs 36

Files 36

Playback order of music files 37

About discs and files 38

Cautions on using media 39

Loading Discs 39

Cautions on Loading Discs 39

How to handle media 40

Cleaning discs 40

Explanation of terms 41

Specifications 42

Index 45

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Quick Start Guide Safety Instructions Cautions on Using Batteries Power cord

Remote control unit

(RC-1215)

R03/AAA batteries Coaxial digital cable

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

Batteries

3Put the rear cover back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

Approx. 7 m

30° 30°

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Features

High quality

0A new style of CD player with Denon's trademark quality,

containing a high-precision 32-bit D/A converter

The D/A converter is a key element of sound quality, so this product

contains our 32 bit/384 kHz D/A converter, renowned for its high degree

of precision, to bring you the best sound quality possible.

0This unit can be combined with the DRA-100, a network receiver

with a high-quality class-D amplifier, to achieve high-quality

reproduction of even the finest signals.

In addition to a high-quality class-D amplifier, the DRA-100 network

receiver contains Advanced AL32 Processing, a unique analog

waveform recreation technology from Denon. Combine it with this unit to

enjoy sound with an intricacy and power far greater than you’d expect

from a device of its size.

High performance

0This new design is the optimal match for our DRA-100 network

receiver

0Slot-in CD mechanism with smooth and steady operation.

0Supports MP3 and WMA file playback

This unit can play back MP3 and WMA files recorded on CD-R and CD-

RW discs.

The high-visibility organic EL display can show information such as the

track name and artist name when playing back MP3s and WMAs.

0The auto standby function reduces power consumption

0This unit comes with a system remote control that can also

operate the DRA-100

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Part names and functions

Front panel

qry

e tw

uioQ

For details, see the next page.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

qrt y

uioQ

APower operation button (X)

This turns the power on/to standby. (v p. 20)

The power status is indicated as follows.

0Power on: Display lit

0Standby: Display off

BProtection circuit indicator

This blinks when the protection circuit has operated. (v p. 32)

CDisplay

This displays various pieces of information. (v p. 9)

DCD slot (v p. 39)

ERemote control sensor

This receives signals from the remote control unit. (v p. 5)

FCD Eject button (5)

Ejects the disc.

GPlay/pause button (1 / 3)

Plays the track/Pauses the track.

HStop button (2)

Stops playback.

IReverse-skip button (8)

Returns to the start of the currently playing track.

JForward-skip button (9)

Plays the next track.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Display

Display sample

Track 05

Track

02:15

song tle

10/12

01:53

12 tracks

Total

52:34

Description of icon

P: random

z: repeat all

u: repeat 1

v: track

t: folder

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Rear panel

OUT

COAXIAL

IR CONTROL ANALOG

OUTOUT

DIGITAL

q w e r

AAC inlet (AC IN)

Used to connect the supplied power cord. (v p. 18)

BIR CONTROL connectors

Used to connect Denon network audio players with an IR controller.

CDIGITAL OUT connector (COAXIAL)

Used to connect an amplifier equipped with digital audio input

connector. (v p. 16)

DANALOG OUT connectors

Used to connect an amplifier equipped with analog audio input

connectors. (v p. 17)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index
