Delta PMT-4V350W1A Series Manual de instrucciones

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

PMT

Highlights & Features

– AC input range selectable by switch

– Full Aluminium casing for light weight and corrosion resistant

handling

– Built-in automatic fan speed control circuit

– Wide operating temperature range from -20°C to +70°C and

cold start at -40°C

– MTBF > 700,000 hrs. as per Telcordia SR-332

– Short Circuit / Overvoltage / Overload / Over Temperature

Protections

Safety Standards

CB Certified for worldwide use

Model Number: PMT-4V350W1A☐

Unit Weight: 0.81 kg

Dimensions (L x W x D): 215 x 115 x 50 mm

General Description

The new PMT series of panel mount power supplies is the latest offering from one of the world’s largest power supply manufacturers

and solution providers - Delta. PMT-4V350W1A☐ offers a nominal output voltage of 4.2V with a wide operating temperature range

from -20°C to +70°C and can withstand shock and vibration (in accordance to IEC 60068-2-27 and IEC 60068-2-6 respectively). In

addition to features like overvoltage and overload protections, Delta’s PMT series of panel mount power supplies is unlike many other

brands in the same price level. The PMT series is designed for cost competitive markets without compromising the quality of the

components and product specifications. The series of products has an expected life time of 10 years and will have no output power de-

rating from 100Vac to 132Vac & 180Vac to 264Vac.

Model Information

PMT Panel Mount Power Supply

Model

Number

Input Voltage Range Output

oltage

Output Curr

ent

PMT-4V350W1A☐ 90-132Vac, 180-264Vac

(Selectable by Switch)

4.2Vdc 60.0A

Model Numbering

CC Code**

PM T –4V

350W

□

Panel Mount Product Type

T – Enclosed

Output Voltage

Output Power

(350W series

model)

Single Phase No PFC

Series

Connector Type

M – Terminal Block

N – Front Face*

Blank – Without

connector cover

A –

With connector

cover

*Options

**For Terminal Block

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

Specifications

Input Ratings / Characteristics

Nominal Input Voltage 100-120Vac, 200-240Vac (Selectable by Switch)

Input Voltage Range 90-132Vac, 180-264Vac (Selectable by Switch)

Nominal Input Frequency 50-60Hz

Input Frequency Range 47-63Hz

Input Current < 7.00A @ 115Vac, < 4.00A @ 230Vac

Efficiency at 100% Load > 75.0% @ 230Vac

Max Inrush Current (Cold Start) < 40A @ 115Vac, < 60A @ 230Vac

Leakage Current < 3.5mA @ 240Vac

Output Ratings / Characteristics

Nominal Output Voltage 4.2Vdc

Output Voltage Tolerance ± 3% (initial set point tolerance from factory)

Output Voltage Adjustment Range 3.78-4.70Vdc

Output Current 60.0A

Output Power 252W

Line Regulation ± 0.5% typ.

Load Regulation ± 2.5% typ.

PARD (20MHz) < 150mVpp

Rise Time < 50ms @ nominal input (100% load)

Start-up Time < 1000ms @ nominal input (100% load)

Hold-up Time > 16ms @ 115Vac, > 20ms @ 230Vac

Dynamic Response (Overshoot & Undershoot O/P Voltage) ± 1000mVpp @ 10-50% load and 50-100% load

Start-up with Capacitive Loads 8,000µF Max

Mechanical

Case Chassis Aluminium

Case Cover Aluminium

Dimensions (L x W x D) 215 x 115 x 50 mm

Unit Weight

0.81 kg

Indicator Green LED (DC OK)

Cooling System Forced Cooling

Terminal PMT-4V350W1AM☐ M3.5 x 9 Pins (Rated 300V/15A)

PMT-4V350W1AN M3.5 x 9 Pins (Rated 300V/20A)

Wire

AWG 14-12

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

Environment

Surrounding Air Temperature Operating -20°C to +70°C

Storage -40°C to +85°C

Power De-rating > 50°C de-rate power by 4% / °C,

> 60°C de-rate power by 1% / °C

< 100Vac de-rate power by 3% / V,

< 200Vac de-rate power by 1.5% / V

Operating Humidity 5 to 95% RH (Non-Condensing)

Operating Altitude 0 to 5,000 Meters

Shock Test (Non-Operating) IEC 60068-2-27, Half Sine: 50G for a duration of 11ms

3 times per direction,18 times in total

Vibration Operating IEC 60068-2-6, Sine Wave: 10Hz to 150Hz @ 25m/S²

(2.5G peak); 90 min per axis for all X, Y, Z direction

Non-Operating IEC 60068-2-6, Random: 5Hz to 500Hz @ 2.09Grms

peak; 20 min per axis for all X, Y, Z direction

Pollution Degree 2

Protections

Overvoltage < 4.83~7.00V, SELV Output, Latch Mode

Overload / Overcurrent > 105~135% of rated load current, Hiccup Mode,

Non-Latching (Auto-Recovery)

Over Temperature Hiccup Mode, Non-Latching

(Auto-Recovery when the fault is removed)

Short Circuit Hiccup Mode, Non-Latching

(Auto-Recovery when the fault is removed)

Protection Against Shock Class I with PE* connection

*PE: Primary Earth

Reliability Data

MTBF > 700,000 hrs. as per Telcordia SR-332

I/P: 100Vac, O/P: 100% load, Ta: 35°C

Expected Cap Life Time 10 years (115Vac & 230Vac, 50% load @ 40°C)

Safety Standards / Directives

Electrical Safety UL/cUL recognized to UL 60950-1 and CSA C22.2

No. 60950-1, CB scheme to IEC 60950-1

Material and Parts RoHS Directive 2011/65/EU Compliant

Galvanic Isolation Input to Output 3.0KVac

Input to Ground 1.5KVac

Output to Ground 0.5KVac

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

EMC

EMC / Emissions* CISPR 22, EN 55022, FCC Title 47: Class A

(With Delta EMI filter P/N: 10DKAW5)

Immunity to* EN 55024

Electrostatic Discharge IEC 61000-4-2 Level 4 Criteria A

Air Discharge: 15kV

Contact Discharge: 8kV

Radiated Field IEC 61000-4-3 Level 3 Criteria A

80MHz-1GHz, 10V/M with 1kHz tone / 80% modulation

Electrical Fast Transient / Burst IEC 61000-4-4 Level 3 Criteria A

2kV

Surge IEC 61000-4-5 Level 3 Criteria A

Common Mode2): 2kV

Differential Mode3): 1kV

Conducted IEC 61000-4-6 Level 3 Criteria A

150kHz-80MHz, 10Vrms

Power Frequency Magnetic Fields IEC 61000-4-8 Criteria A

10A/Meter

Voltage Dips IEC 61000-4-11 100% dip; 1 cycle (20ms); Self Recoverable

Low Energy Pulse Test (Ring Wave) IEC 61000-4-12 Level 3 Criteria A

Common Mode2): 2kV

Differential Mode3): 1kV

Harmonic Current Emission NA

Voltage Fluctuation and Flicker* IEC/EN 61000-3-3

*Fulfills tested conditions

1) Criteria A: Normal performance within the specification limits

2) Asymmetrical: Common mode (Line to earth)

3) Symmetrical: Differential mode (Line to line)

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

Block Diagram

Device Description

1) Input & Output terminal block connector

2) DC voltage adjustment potentiometer

3) DC OK control LED (Green)

4) AC selectable switch

PMT-4V350W1AM☐: Terminal Block

PMT-4V350W1AN: Front Face

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

Dimensions

L x W x D: 215 x 115 x 50 mm (PMT-4V350W1AM☐: Terminal Block)

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

L x W x D: 215 x 115 x 50 mm (PMT-4V350W1AN: Front Face)

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

Engineering Data

De-rating

Output De-rating VS. Input Voltage

Note

1. Power supply components may degrade, or

be damaged, when the power supply is

continuously used outside the shaded region,

refer to the graph shown in Fig. 1.

2. If the output capacity is not reduced when the

surrounding air temperature >70

°C, the

device will run into Over Temperature

Protection. When activated, the output

voltage will go into bouncing mode and will

recover

when the surrounding air

temperature is lowered or the load is reduced

as far as necessary to keep the device in

working condition.

To ensure sufficient convection cooling,

always maintain a distance of ≥ 20mm from

fan ventilated surfaces while the device is in

operation.

Depending on the surrounding air

temperature and output load delivered by the

power supply, the device housing can be

very hot!

5. If the device has to be mounted in any other

orientation, please do not hesitate to contact

[email protected] for more details.

Fig. 1 De-rating for Vertical and Horizontal Mounting Orientation

> 50°C de-rate power by 4% / °C

> 60°C de-rate power by 1% / °C

No output power de-rating for the input

voltage from 100Vac to 132Vac & 200Vac to

264Vac

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

Assembly & Installation

ⒶSide Mounting: Fig. 2 and Fig. 3 show the mounting hole locations for power supply assembly onto a metal mounting surface. The

power supply shall be mounted on minimum of 4 mounting holes using M4 screw maximum 5mm length (Refer to Fig. 4 on the

next page). This is to maintain a safety distance between the screw and internal components.

ⒷBase Mounting: Fig. 2 and Fig. 3 show the mounting hole locations for power supply assembly onto a metal mounting surface. The

power supply shall be mounted on minimum of 4 mounting holes using M4 screw maximum 4mm length (Refer to Fig. 4 on the

next page).

ⒸConnector

ⒹThis surface belongs to customer’s end system or panel where the power supply is mounted.

Base Mounting (Horizontal) Base Mounting (Vertical) Side Mounting (Horizontal)

Fig. 2 Mounting Orientations

– Use flexible cable (stranded or solid) of AWG No. 14-12. The input/output connectors’ allowable current is 23A max per pin. User

should calculate and select the suitable wire specification (type/quantity/diameter) according to actual output current. The torque at

the connector shall not exceed 13Kgf.cm. The insulation stripping length should not exceed 0.275” or 7mm.

– Recommended mounting torque of the product and its mounting accessories is 9~12Kgf.cm.

Fig. 4 Assembly Reference

Fig. 3 Mounting Hole Locations and the Safety Distance

Ensure the mounted device is kept at ≥ 4mm safety distance at all sides from other components and equipments. In addition, to ensure

sufficient convection cooling, always maintain a distance of ≥ 20mm from fan ventilated surfaces while the device is in operation.

Please insert an insulation sheet between the system and product, if the safety distance is < 4mm.

Safety Distance

D1 = 4mm Min.

D2 = 20mm Min.

Only use M4 screw ≤ 5 mm through the base mounting holes at

Ⓐ

This is to keep a safe distance between the screw and internal

components.



Only use M4 screw ≤ 4 mm through the base mounting holes at Ⓑ.

This is to keep a safe distance between the screw and internal

components.

PMT Panel Mount Power

Supply

4.2V 252W 1

Phase

/ PMT-4V350W1A

□

TECHNICAL DATASHEET

All parameters are specified at 25°C ambient unless otherwise indicated.

www.DeltaPSU.com (October 2014, Rev. 02)

Safety Instructions

– Must select correct AC input voltage before turning on (Refer to the “Device Description” on Page 5).

– If user’s mounting orientation is not according to the recommended mounting orientations, please consult Delta for further

information.

– The device is not recommended to be placed on low thermal conductive surface. For example, plastics.

– The enclosure of the device can become very hot depending on the ambient temperature and load of the power supply. Do not

touch the device while it is in operation or immediately after power is turned OFF. Risk of burning!

– Do not touch the terminals while power is being supplied. Risk of electric shock.

– Prevent any foreign metal, particles or conductors from entering the device through the openings during installation.

It may cause electric shock, safety hazard, fire and/or product failure.

– Warning: When connecting the device, secure Earth connection before connecting L and N. When disconnecting the device,

remove L and N connections before removing the Earth connection. The power supply must be mounted by metal screws onto a

grounded metal surface. It is highly recommended that the Earth terminal on the connector be connected to the grounded metal

surface.

Accessories

LM-01: Top Fixing Bracket

This bracket is used to fix the power supply onto a flat

surface from the top.

–

Este manual sirve para los siguientes modelos

Otros manuales de Fuente de alimentación de Delta

Delta

Delta PMC-12V035W1AA Manual de usuario

Delta

Delta PJB-24V100WA Manual de instrucciones

Delta

Delta MCS-600 Series Manual de instrucciones

Delta

Delta PMC Series Manual de usuario

Delta

Delta PCM-48V600W1B Series Manual de usuario

Delta

Delta DRS-24V100W1A Series Manual de instrucciones

Delta

Delta D750 Manual de usuario

Delta

Delta DRP024V480W1B Series Manual de instrucciones

Delta

Delta CliQ DRP024V120W1AA Guía de inicio rápido

Delta

Delta PMF-24V200WC Manual de usuario

Delta

Delta LYTE DRL-24V240W1A Series Manual de instrucciones

Delta

Delta sync 24V 100W Series Manual de instrucciones

Delta

Delta PMC-12V100W1AA Manual de usuario

Delta

Delta PMU-27V155WC A Series Manual de usuario

Delta

Delta CliQ Manual de usuario

Delta

Delta GPS-650JB E A22 Manual de usuario

Delta

Delta PMC-24V050W1AA Manual de usuario

Delta

Delta PMT Series Manual de instrucciones

Delta

Delta DPS-0220 Manual de usuario

Delta

Delta PMC-24V600W1RW Manual de usuario

Delta

Delta PMC-05V035W1AA Manual de usuario

Delta

Delta HPP-1K5A01KAT Manual de usuario

Delta

Delta PM 24V200W1AI Series Manual de usuario

Delta

Delta PMC Series Manual de usuario

Manuales populares de Fuente de alimentación de otras marcas

Monacor

Monacor PS-12CCD Manual de usuario

VOLTIMA

VOLTIMA MagicBox 15 Manual de usuario

Agilent Technologies

Agilent Technologies 6032A Manual de usuario

Miller

Miller Auto Deltaweld 452 Manual de usuario

BCP

BCP PUOUBK Hoja de instrucciones

HC 2210 Manual de usuario

Puls

Puls CT5.241 Manual de usuario

OCZ

OCZ ZX1250W Manual de usuario

iseg

iseg ECH 238 Manual de usuario

Power

Power XXL A Series Manual de usuario

Agilent Technologies

Agilent Technologies 6631B Manual de usuario

Renogy

Renogy PHOENIX 300 Manual de usuario

HP 6200B Manual de servicio

Epson

Epson Stylus Scan 2500 Manual de funcionamiento

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manual de usuario

Puls

Puls MiniLine ML50.100 Manual de usuario

Puls

Puls AS-Interface SLA4.100 Manual de usuario

Kenwood

Kenwood PS-60 Manual de usuario
