Delta Children First Exploration Manual de usuario

32201

WARNING:

Adult assembly required because of

small parts. Keep assembly parts

out

of reach of children under 3 years.

CHOKING HAZARD

Customer Experience Center

phone: (646)-435-8726

email: [email protected]

INSTRUCTION MANUAL

Read all instructions BEFORE assembly and USE of product

KEEP INSTRUCTIONS FOR FUTURE USE.

DCP-IM-03072019-V4

www.DeltaChildren.com

First Exploration

2-in-1 Activity Walker

STYLES AND COLORS MAY VARY

REQUIRED: 2 x AA Batteries

(not included)

Screwdriver

(not included)

ADULT ASSEMBLY REQUIRED

Customer Service Tel. (646) 435-8726 www.DeltaChildren.com

Care and Maintenance

Failure to follow these warnings and instructions could result in serious injury or death.

Read all instructions before assembling unit.

KEEP INSTRUCTIONS FOR FUTURE USE. DO NOT USE THIS UNIT IF THE INSTRUCTIONS

CANNOT BE STRICTLY FOLLOWED.

WARNING:

• NEVER LEAVE CHILD UNATTENDED!

• ALWAYS KEEP CHILD IN VIEW WHILE IN WALKER.

• NEVER use near stairs or thresholds.

• Before each use clean friction components to maintain stopping performance.

• Strings can cause strangulation! DO NOT place items with a string around child’s neck, such as hood

strings or pacifier cords. DO NOT suspend strings over product or attach string to toys.

• To avoid burn injuries, always keep child away from ranges, radiators, hot liquids, space heaters,

fireplaces, etc.

• To avoid drowning, never use near pools, bathtubs, etc.

• Always check that surfaces are flat and free of objects that may cause tipping over either indoors

or outdoors.

• To reduce chance of child slipping out of seat, always check that both feet of child touch floor.

• Use only for children who can sit upright unassisted and weigh no more than 25 lbs.

• NEVER carry walker or adjust height with child in it.

• Walk behind mode is only intended for use by children 9 months - 3 years.

• Not to be used as a ride-on toy when used in the floor toy car mode.

STAIR HAZARD

AVOID SERIOUS INJURY OR DEATH BLOCK STAIRS/STEPS SECURELY BEFORE USING WALKER.

Care and Maintenance:

• Wash using mild soap and warm water only.Wipe plastic components dry and air dry seat cover.

• Keep friction components clean to maintain stopping performance

EXTENDED WARRANTY

DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFES MISHAPS!

With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if

your item stops working due to normal wear and tear, plus all those unexpected surprises.

2 YEARS OF PROTECTION

For Additional Information:

Simply visit our Website, register your product, and add the Extended Warranty

https://www.deltachildren.com/pages/product-registration

Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho,

Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire,

New York, North Carolina, North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia

Please DO NOT return this product to the store .

If you experience any difficulty with assembly, missing parts or use, please

DO NOT return this item to the store. Retail stores are unable to properly

assist you. Contact our Customer Service Department directy for assitance

646-435-8726

STOP

www.DeltaChildren.com • [email protected]

Customer Service Tel. (646) 435-8726 www.DeltaChildren.com

Walker Base

Front Swivel Wheels x2 Rear Wheels x2

Anti Slip Blocks x6

Push Behind Handle x1

Seat

Toy Tray

Parts

IMPORTANT! Please remove all parts from the package and identify them before assembly.

Part #

2030 (Exploration) - 50327

2031 (Orbit) - 50327

Part # 50420

Part #

2030 (Exploration) - 50326

2031 (Orbit) - 50326

Part #

2030 (Exploration) - 50325

2031 (Orbit) - 50325

Part # 50324

Part # 50323

Top Tray

Customer Service Tel. (646) 435-8726 www.DeltaChildren.com

Walker Assembly

Front Swivel

Wheels

Anti Slip Blocks

• Locate the walker base and 6x anti slip blocks.

• Insert the anti slip blocks into the receiving holes on the base.

• Push anti slip blocks all the way down until tightly secured to

the walker base.

• Pull up on the anti slip blocks to assure they are properly

inserted.

Rear Wheels

• Locate 2x front swivel wheels and walker base.

• Place the walker on a solid flat surface with the bottom facing

upwards.

• Insert the pins of the front swivel wheels into their housings until

they click into position.

• Pull upward on wheels to assure they are properly inserted.

• Locate 2x rear wheels and walker base.

• Insert the rear wheels into their housings until they click into place.

• Pull upward on wheels to assure they are properly inserted.

• Locate the walker base

• To raise the walker, hold the base with one hand while lifting

up the top tray with the other.

Top Tray

Walker

Base

Customer Service Tel. (646) 435-8726 www.DeltaChildren.com

Walker Assembly

• Insert the 3 pins on the front of the seat pad into the

receiving hole openings of the top tray front opening.

• Push the front seat pins down until you hear them

“click” into a lock postition.

Attaching seat pad FRONT pins to the top tray: Attaching seat pad REAR pins to the top tray:

• Insert the 6 pins on the back of the seat pad into the receiving

hole openings of the top tray back opening.

• Push the back seat pins down until you hear them “click”

into a lock postition.

FRONT PINS

REAR PINS

Customer Service Tel. (646) 435-8726 www.DeltaChildren.com

Battery Safety Information

In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or

ruin your product. To avoid battery leakage:

• Do no mix old and new batteries or batteries of different types: Alkaline, standard (carbon zinc) or

rechargeable (nickel-cadmium).

• Insert batteries as indicated inside battery compartment.

• Remove batteries during long periods of non-use. Always remove exhausted batteries from the

product. Dispose of batteries safely. Do not dispose of product in a fire. The batteries inside may

explode or leak.

• Never short-circuit the battery terminals.

• Use only batteries of the same or equivalent type as recommended.

• Do not charge non-rechargeable batteries.

• Remove rechargeable batteries from the product before charging.

• If removable, rechargeable batteries are used, they are only to be charged under adult supervision.

• When discarding batteries, be sure to dispose of them in the proper manner, according to your

state and local regulations.

Inserting Battery

unlocked view

• Locate the battery cover on bottom of toy tray.

• Use a Phillips head screw driver to unfasten the battery

cover.

• Slide upward to release top

• Lift cover to open battery compartment.

• Insert AA batteries (x2) as shown in the picture.

• Close battery cover. Use a Phillips head screw driver to

fasten the battery cover closed.

Walker Assembly

• On the bottom of the toy tray locate the lock slots and lock tabs

on top tray.

• Align toy tray to top tray insert. While holding down the toy tray

push up the top tray lock tabs and turn to fasten.

• Locate push behind handle.

• Place the push behind handle into the back of the walker

housing and push down until the push pins “CLICK” into a fully

locked position.

• To release push behind handle, press the push pins inward on

both sides and lift upward to fully remove.

top tray

lock tabs

toy tray lock tabs

toy tray

lock slots

• Turn the safety button lengthwise and press the button until

the mechanism is released. With the button still pressed in,

select new height. 3 different height positions are available.

• When the new position has been selected, release the

button and check it has turned 90 degrees back to original

position.

• When folding the walker, turn to unlock as shown in step

push the button to release and hold the button down as shown

in step . Carefully lower the walker into complete folded

position.

WARNING

DO NOT adjust the seat height with the baby in the

walker. Remove the baby from the walker when

adjusting the seat height.

To adjust the height and fold the walker, locate slider joint

beneath the top tray

unlocked positionlocked position

SAFETY BUTTON

Adjust the Height and Fold

Delta Children's Products Corp.

114 West 26th Street

New York, NY 10001

646-435-8726

www.DeltaChildren.com

Customer Service Tel. (646) 435-8726 www.DeltaChildren.com
