Delphi SkyFi2 SA10102 Manual de usuario
Guide
User
SKYFi2
™
Radio
Satellite
Receiver
Warning: This manual contains important safety and operating information. Please read
and follow the instructions in this manual. Failure to do so could result in personal injury,
death, and/or damage to your SKYFi2 Receiver and/or to your vehicle or other property.
For Position Only
Need photo of SKYFi2
This device complies with Part 15 of
the FCC rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Important: The FCC and FAA have not
certified the Delphi XM SKYFi2
Satellite Radio Receiver for use
in any aircraft (neither portable nor
permanent installation). Therefore,
Delphi cannot support this type of
application or installation.
Welcome
Thank you for purchasing a Delphi XM SKYFi2 Satellite Radio
Receiver. Your SKYFi2 gives you access to over 120 XM
Satellite Radio channels of music, news, and information from
coast to coast.*
*XM subscription required for reception. Not available in Alaska or Hawaii.
((SKYFi2))
SKYFi2 improves upon the award-
winning SKYFi Satellite Radio Receiver
by offering these new features:
• Built-in FM wireless modulator.
Listen to XM through any nearby
FM radio without using any wires.
•LivePause. Hear an instant replay or
take a break (up to 30 minutes)
without missing a beat.
•TuneSelect. Finds your favorite
songs by artist name or song title if
they’re playing on any XM channel.
• Personal stock and sports tickers.
Track your favorite stocks and sports
scores right on SKYFi2’s display.
•A brighter, white LED backlit display
for even better visibility.
•More versatile vehicle mounting
options.
To use the SKYFi2 Satellite Radio
Receiver, you must have a Vehicle Kit
[PART NUMBER], Home Kit [PART
NUMBER], or Marine Kit [PART
NUMBER].
Caution: Your SKYFi2 must be used with the enclosed connecting devices or other approved acces-
sories to ensure maximum performance and safety. Do not modify or alter wires or connections in any
way. Shortening wires or connections may prevent proper functioning of a protection circuit, which
may damage your receiver and will void your warranty.
((Vehicle Kit)) ((Home Kit)) ((Marine Kit))
Vehicle Kit [PART NUMBER] Home Kit [PART NUMBER] Marine Kit [PART NUMBER]
About Delphi
Delphi is a worldwide leader in mobile
electronics, vehicle components, and
audio technology. Delphi created the
first in-dash car radio in 1936 and
continues its strong tradition of inno-
vation in the audio industry. With its
exciting line of satellite radio products,
Delphi offers a broad portfolio of
products to answer a wide variety of
information and entertainment needs.
About XM
One big idea can change everything.
And XM Satellite Radio is one big
idea: Radio to the Power of X®.
America’s most popular satellite radio
service offers over 120 digital chan-
nels of sheer variety: music, sports,
talk, comedy, drama, news, traffic and
weather, kids programming, and more.
All 68 XM music channels are 100 per-
cent commercial-free, and XM’s instant
traffic and weather channels provide the
most comprehensive, in-depth infor-
mation on traffic incidents, delays, and
road conditions available on radio.
These services are available for a low
monthly subscription, and additional
devices may qualify for a reduced fee
through the XM Family Plan.
3
Contents
Getting Started
Activating SKYFi2 . . . . . . . . . . . . . 4
SKYFi2 Receiver
SKYFi2 Display Screen . . . . . . . . . 6
SKYFi2 Controls . . . . . . . . . . . . . . . 6
SKYFi2 Remote Control . . . . . . . . 7
Basic Operations
Turning SKYFi2 On and Off . . . . . 8
Selecting Channels . . . . . . . . . . . . 8
Scroll Wheel . . . . . . . . . . . . . . . . . . 8
Direct Entry . . . . . . . . . . . . . . . . . . . 9
Using Presets . . . . . . . . . . . . . . . . . 9
Changing the Display . . . . . . . . . 10
Memorizing Song Information . . 10
Advanced Features
Listening to XM Over an
FM Radio . . . . . . . . . . . . . . . . . . 12
Adjusting the Screen
Brightness and Contrast . . . . . 13
Adjusting Audio Level . . . . . . . . . 13
Auto-On . . . . . . . . . . . . . . . . . . . . 14
Auto-Off and Sleep Timer . . . . . . 14
Aiming the Home Antenna . . . . . 14
TuneSelect . . . . . . . . . . . . . . . . . . 15
Stock Ticker . . . . . . . . . . . . . . . . . 16
Info Extras . . . . . . . . . . . . . . . . . . 17
LivePause . . . . . . . . . . . . . . . . . . . 17
Recall Last Channel . . . . . . . . . . . 18
Direct Tune . . . . . . . . . . . . . . . . . . 18
Search . . . . . . . . . . . . . . . . . . . . . . 18
Skipping Channels While Tuning . 18
Setting the Clock . . . . . . . . . . . . . 19
Restoring Factory Default . . . . . . 19
Reference
Care . . . . . . . . . . . . . . . . . . . . . . . . 20
Accessories . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . 22
Contacting Technical Support
and Customer Service . . . . . . . 24
Technical Information . . . . . . . . . 24
Warranty
XM Satellite Radio Limited
Consumer Warranty . . . . . . . . . 24
4
Warning: Failure to properly follow all
installation instructions could result in personal
injury, death, and/or damage to your SKYFi2
Receiver and/or to your vehicle or other property.
Warning: When using this product it is
always important to keep your hands on the
wheel. Not doing so could result in personal
injury, death, and/or damage to your SKYFi2
Receiver and/or to your vehicle or other property.
Getting Started
Getting Started
Activating SKYFi2
To quickly begin enjoying XM
Satellite Radio with your SKYFi2,
follow these simple steps:
1. Set up your SKYFi2 Receiver using
the installation instructions included
in the SKYFi Home Kit, SKYFi
Vehicle Kit, Delphi XM SKYFi
Marine Kit, or with the help of a
professional installer.
2. Press the power button to turn on
your SKYFi2 and verify that it is
playing Channel 1, the XM
Preview Channel.
3. Select Channel 0. The receiver’s
eight-character XM Satellite Radio
ID will appear on the display.
Write the ID here:
Note: Carefully check your XM Radio ID.
The letters I, O, S, and F are not used.
4. Activate your XM Satellite Radio
service. To subscribe, make sure
you have your XM Satellite Radio
ID and a major credit card. Contact
XM at http://activate.xmradio.com
or by calling 1.800.852.9696.
5. After subscribing, make sure you
keep your receiver on for at least
one hour in order to activate the
full channel lineup.
5
SKYFi2 Receiver
SKYFi2 Receiver
SKYFi2 Receiver Controls
Use your SKYFi2 control buttons
to operate various functions.
LivePause
Pause or instant replay.
Number keys
Selects a channel directly or
selects presets.
Jump button
Switches to previous
channel.
Search button
Changes search mode
between category or
scanning.
Preset/direct button
Selects between direct
channel entry or presets.
Menu button
Selects and changes
configuration options.
Memory button
Saves and recalls song
information such as artist
and title.
Display button
Changes information
on display.
Power button
Powers on and off.
Enter button
Confirms selected channel or
menu option.
Scroll wheel
Previews channels; also
selects various menu options.
Category search
Immediately selects a different channel.
Figure 1. SKYFi2 Receiver.
6
SKYFi2 Receiver
SKYFi2 Receiver Display
Screen
While tuned to an XM channel, the
SKYFi2 default display contains
information about that channel and
the SKYFi2 settings. See figure 2.
Your SKYFi2 display can be
customized. See the Basic Operations
section, beginning on page 8.
Figure 2. SKYFi2 Receiver display screen.
Signal strength
indicator
(zero to three bars)
Keypad mode
(DIRECT, Preset A,
or Preset B)
Additional
information
Artist name
Song title
Channel number
Channel name
Clock
7
SKYFi2 Receiver
SKYFi2 Remote Control
Figure 3. SKYFi2 Remote Control.
Power button
Powers on and off.
Channel button
Previews channels; also selects various menu
options.
LivePause button
Pause or instant replay.
XM button
Confirms selected channel or menu option.
Mute button
Mutes the audio.
Preset/direct button
Selects between direct channel entry or presets.
+- buttons
Immediately selects a different channel.
Number keys
Selects a channel directly or selects presets.
Display button
Changes information on display.
Memory button
Saves and recalls song information such as artist
and title.
Need Remote Control
8
Basic Operations
Warning: When using this product it is
always important to keep your eyes on the road
and your hands on the wheel. Failure to do so
could result in personal injury, death, and/or
damage to your SKYFi2 Receiver and/or to your
vehicle or other property.
Basic Operations
Turning SKYFi2 On and Off
1. To turn on: press .
2. To turn off: press .
If SKYFi2 is installed in a vehicle, you
may use the ignition key to power
SKYFi2 on or off. This will not affect
SKYFi2 in any way.
Selecting Channels
You may select channels by using the
scroll wheel, by pushing one of the pre-
set buttons, or by keying in the channel
number. You can also use the equivalent
buttons on the remote control.
Scroll Wheel
1. Turn the scroll wheel
2. When you find your desired
channel, press the “XM” button
to select it.
You can also set up SKYFi2 so that you
do not have to press the “XM” button
to select a channel. See “Direct Tune”
in “Advanced Features” (page 12).
