DeLonghi CF08E Manual de usuario

66126661

- 1 -

Features

Powerful dehumidifying capability

The dehumidifier powerfully removes excess

moisture from the air creating a drier,healthier

home environment.

Excellent drying laundry function

The dehumidifier dries laundry quickly. This can

prevent laundry and furniture from becoming damp

and musty in a rainy season.

Quiet operation

For overnight operation,the QUIET mode may be

selected.

Drainage tank with a large capacity

Large 6 litre capacity water tank means the

dehumidifier requires emptying less often.

Using refrigerant for protecting environment

The dehumidifier uses no CFC refrigerant

therefore protecting the environment.

Modern Design

The dehumidifier is compact with a streamlined

appearance and modem design.

The castors at the bottom allow easy mobility.

SAVE

Saving energy

The power consumption is low.

- 2 -

The dehumidification capacity is the value obtained after the dehumidifier was continuously run in the

room temperature of 30 with the relative humidity 80%.

The amount of dehumidification is the amount per day(24 hours).

The manufacturer reserves the right to change specifications without prior notification.

The work temperature is in the range 2 to 38 . If the room temperature is beyond the range, the unit

can not operate normally.

If you pour cold water into a cup, the air around the cup is cooled, and drops of water

form on the surface of the cup. The dehumidifiertakes advantage of this phenomenon to

remove moisture.

It draws in room air, cools it with a cooling unit,

and changes the humidity to drops of water.

The drops of water fall into a drainage tank.

The dehumidified air is re-heated by a heating

unit and discharged.

Steps ,,and are repeated to remove

humidity from the room.

After the air passes through the re-heating unit, its temperature will rise a little, so that the

temperature of the room will rise by 2 to 4 . This is normal operation.

How dehumidifying works

Specifications

Power Supply

Dehumidifying Capacity

Power Consumption

Drainage Tank Capacity

Weight

Dimension(height width depth)

Model CF08E

220 240V ~ 50Hz

6.0L

20L/day

400W

14kg

545mm 380mm 261.5mm

Cooling unit Re-heating unit

Moist air Dried air

Compressor Drainage tank

- 3 -

DrainageTank

Handle

Air Outlet

Louvre

Control Panel

Refer to next page

Sensor

Do not obstruct!

Float

Guard

Water Level

Gauge

When the unit is purchased,

there may be some water left in

the drainage tank. This is from

the dehumidifying test

conducted at the factory, and

does not indicate a problem.

Back panel

Continuous

Drainage Port

Refer to page 7

Air Filter

(Back panel air inlet)

do not obstruct!

Refer to page 8

Cord Hook

Cord Band

(undo on operation)

Power Supply Plug

Castors

Refer to page 7

Description

Front panel

- 4 -

Control Panel

4. “50%”, “60%”, “70%”:Humidity indicator light.

This indicates that the current humidity setting is “50%”,

“60%” or “70%” respctively.

5. The“Continuous”light indicates the unit is operating in

cotinuous mode.

Indicator lamp

1. Full : Tank full indicator lamp

It will light when the drainage tank is full or positioned incorrectly. Empty the water out of the drainage tank,

and make sure the tank is positioned properly.

2. On/Off” :Power indicator light.

It will light when the unit is plugged in.

3. Normal”, Hi”, Quiet”:mode indicator light.

Indicates mode of dehumidification selected.

Switch function

1. “On/Off” switch

Press the switch once to turn the dehumidifier on, press it again to turn it off.

2. “Mode” switch

Each time the switch is pressed, the mode changes in the order of “Normal”, “High” and “Quiet”

and the corresponding mode indicator lamp will change with the mode of operation.

3. “Humidity” switch

Press the switch to set the humidity of the room, which can be set in order of “50%”, “60%” “70%” and

“continuous”, and the corresponding humidity indicator lamp will light to display your setting humidity.

When the relative humidity of the room is lower than your humidity setting, the unit will turn off

automatically.

When the unit is initially started, the default operation is the continuous mode.

In this mode the unit will run until manually turned off,or the water tank is full.

- 5 -

Operation

1.Plug the power supply plug into the outlet and press the “ On/Off” switch

When the “ On/Off” switch is pressed during operation:

The unit turns off.

Do not turn the unit off by unplugging the power cord.

2.Setting the louvre angle

3.Switching the Unit On

4.Switching the Unit Off

Use single phase 220 240V AC power supply.

Wipe dust off of the power supply plug and insert the plug firmly,

all the way to the rubber section.

Do not use the appliance if the supply cord is damaged.

After the power supply plug is plugged into the outlet, the“On/

Off” indicator will light.

Before operation please check and make sure the louver has been

opened to ensure adequate air flow.

Set louvre to desired angle (when room temperature is above

32 set louvre to vertical position to allow maximum air flow.)

Press the “On/Off” switch, the unit operates in CONTINUOUS

mode automatically.

Normal Mode: Press the mode button until the “ Normal” mode is

selected.This setting allows medium air flow.

Hi Mode:Press the mode button until the “Hi” mode is selected.

This setting allows maximum air flow,and is ideal for enhanced

dehumification,drying clothes etc.

(When the indoor temperature is below 15 or above 35 , the

inbuilt protection device will allow operation in “Hi” mode only.)

Quiet mode: Press the mode switch until the “Quiet”mode is

selected.This setting allows minimum air flow,and is ideal for over-

night operation.

230-240VAC

220-240V AC

- 6 -

Abstergent

Gasoline

Thinner

Operation

Draining the water

The drainage tank is full

When the drainage tank becomes full (approx, 6 Litres), the full indicator lights to alert the user, and the

unit turns off automatically. Empty the water from the tank and discard it.

Drainage steps Notation for drainage

1. Remove the drainage tank

Lightly pressing on the sides of the tank with

both hands, pull it gently out.

Do not remove the bubble packing from the float

on the unit. The float on the unit will no longer be

able to detect without the bubble packing when the

water level is full, and water may leak from the

tank.

If the drainage tank is dirty, wash it with cold or

lukewarm water. Do not use detergent, scouring

pads, chemically treated cloths, or other cleaning

solutions as it may damage the drainage tank.

When replacing the drainage tank, press the tank

firmly into place with both hands. If the tank is not

positioned properly, the “ Tank Full” sensor will

activate, and the dehumidifier will not operate.

Check to make sure the guards are firmly attached

to the tank. If they are not, the drainage tank will

be harder to remove.

If the drainage tank is removed while the unit is in

operation, or immediately after operation has

stopped, water which is still in the cooling unit may

drip out on the base plate. Wait at least 30 minutes

before removing the drainage tank.(If water has

dripped, wipe it up.)

Take hold of the handle, and then remove the tank.

2. Discard the water

3. Place the drainage tank back in it’s

compartment.

Drain water

from this point

Guard

- 7 -

The unit has an optional continuous drainage port. Water can be continually drained by connecting a rubber

hose (15mm I.D), to this drainage port.When setting up the dehumidifier for continuous drainage, always

turn the unit off and unplug the supply plug.

2. Push the hose into the continuous drainage port

Pass a rubber hose (15mm I.D) through the continuous

drainage port, and press it firmly into the drainage port in

the main unit, making sure water does not leak.

The height of drain piping should always be lower than the

height of the drainage port.

Make sure there are no kinks or obstructions in the rubber

hose which may prevent the water draining out.

3.Return the drainage tank to its original position

Check the hose periodically to make sure it is still connected

and has not been obstructed.

1. Disconnect the drainage tank and open the

continuous drainage port.

Use sidecutters or similar tool to cut away the continuous

drainage port in the side of the main unit.

Operation

Draining the water

Continuous drainage of water

1.Drain the water.

2.Lift up the handle.

3.Move the unit.

1.If the floor is made of a material that scratches easily, or if the floor is uneven, lift up the unit and move

it. Also avoid rolling the unit on castors if the floor has shagpile carpet.

2.Tilt it within range of 20 to 30 degrees, as a rule (if you tip it too far, you may scratch the floor or water

may leak.)

3.Be careful that the power supply cord doesn't get pinched under the unit.

Moving the dehumidifier (using castors)

Note:

At least 50 cm At least 20 cm

At least 20 cm

Ensurethedehumidifierhas adequateclearance

between the unit and nearby walls as shown

below.

- 8 -

Wipe it with a soft cloth

Use a soft,clean cloth to wipe the surface.

(Do not use volatile chemicals detergents,chemically treated cloths

or other cleaning solutions.These could possibly damage the unit.)

Cleaning the air filter

The air filter should be cleaned approximately once every two

weeks.

1.Remove the air filter

Press downward on the tabs on the air filter to remove it.

3.Attach the air filter

Insert the lower tabs of the air filter into the main unit and

press the air filter until you hear the tabs click into place.

2.Clean the air filter

Run a vacuum cleaner lightly over the surface of the air

filter to remove dirt. If the air filter is very dirty, wash it with

warm water and a neutral cleaning solvent and dry it

throughly.

Caring for the dehumidifier

Maintenance

Cleaning the Unit

weeks.
