Dell AC511 Manual de usuario



Dell USB Soundbar

AC511

User’s Guide



Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells

you how to avoid the problem

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

property laws. Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions. All other

marks and names mentioned herein may be trademarks of their respective companies.

2016 - 02

Rev. A01



Contents

Setup................................................................................................................................................................................4

System Requirements..............................................................................................................................................4

Contents of the Box.................................................................................................................................................4

Features.......................................................................................................................................................................5

Setting Up Your Dell USB Soundbar.....................................................................................................................6

Troubleshooting.......................................................................................................................................................9

Specifications..........................................................................................................................................................14

Statutory information.................................................................................................................................................15

Warranty...................................................................................................................................................................15



Setup

System Requirements

One USB port (for the USB cable)

Microsoft Windows 7/Microsoft Windows 8/Microsoft Windows 10

Contents of the Box

1 Dell USB soundbar

documents

NOTE: The documents that shipped with the soundbar may vary based

on your region.



Features



3 4 5 6

1 USB cable 2

aux-in port

3 headphone port 4

left T-Hook for soundbar mounting

5 right T-Hook for soundbar mounting 6

power LED

7 volume knob



Setting Up Your Dell USB Soundbar

1. After unpacking the unit, check the contents of the box.

2. Remove the slot covers at the bottom of the Dell monitor.



3. Connect the soundbar to the Dell monitor.

4. Connect the USB cable to the Dell monitor.



NOTE: If the soundbar is not detected, connect the uplink cable that

came with your Dell monitor. Connect one end of the uplink cable to

the USB port on the Dell monitor and to the USB port on your Dell

computer.

5. Direct the control volume level of the computer.



Troubleshooting



Problems Possible Causes Possible solutions

Soundbar is not

functioning properly

Soundbar is not

detected or

synchronized

1. If required for your Dell monitor, connect

one end of the uplink cable to the USB port

on the Dell monitor and to the USB port on

your Dell computer.

2. Once the USB cable is plugged into the

USB power source, observe if the white

LED on the right of the soundbar lights up.

3. If the LED is not lit, check if the USB is

properly inserted to the USB port.

4. If LED is lit and the soundbar does not

function, remove or unplug the soundbar

from the system and restart the computer.

5. Plug in the soundbar again and check if the

LED lights up.

6. If the soundbar still fails to connect, check

if the soundbar is present in Device

Manager.

7. Swap the USB soundbar to another USB

port.

8. If the other USB port works, the first USB

port maybe faulty.

If the other USB port does not work, follow the

steps below.

1. Swap with a known-good USB speaker or

device (e.g. keyboard) or connect the

soundbar to another system.

2. If there is no other mouse or system

available to test with, use a known good

USB keyboard (or any other USB device) to

see if it works on the same USB port.

3. If the known good USB device is not

working on the same port, or the original

soundbar works properly on another

system, the former system's USB I/O may

be defective.

4. If the known good USB device works, or

the soundbar does not work properly on

another system, replace the soundbar.

No Sound Soundbar has power –

power LED indicator is

1. If playing through USB streaming, ensure

that a music file is playing from the

platform and the volume level is not 0%.



2. If playing through external music devices

such as MP3 player, iPod/iPad/iPhone or

any other Android phone, ensure that the

aux-in cable is properly connected.

3. Ensure that the external music device

volume is not 0%.

4. If playing through USB streaming, set all

Windows volume controls to their

maximum.

5. Play some audio content on the computer

(for example, an audio CD or MP3 player).

6. Turn the volume to a higher level by

rotating the soundbar volume knob

clockwise.

7. Clean or reseat all cables.

8. Test the soundbar with a different music

source (for example, a portable CD player

or an MP3 player).

9. Go to the control panel of the computer

and click on Sound.

10. Try different ports.

11. Reinstall the on-board drivers or the sound

card drivers. Restart the computer.

12. Try with a known-good speaker.

No sound No sound from USB

audio source.

1. Check if a 3.5 mm aux-in cable is inserted

in the soundbar aux-in jack.

2. Remove the 3.5 mm aux-in cable from the

aux-in jack.

Distorted Sound Computer's sound

card is used as the

audio source.

1. Clear any obstructions between the

soundbar and the user.

2. Confirm that the audio line-in plug is

completely inserted into the jack of the

sound card.

3. Set all volume controls to their midpoints.

4. Decrease the volume of the audio

application.

5. Turn the volume level to lower setting by

rotating the soundbar knob

counterclockwise.

6. Clean and reseat all cables.

7. Troubleshoot the computer's sound card.

8. Test the soundbar using another audio

source (for example, a portable CD player

or an MP3 player).

9. Ensure no loose objects are touching the

soundbar.
