Dell™ PowerEdge™

SC1420 Systems

Information Update

信息更新

Mise à jour des informations

Aktuelle Informationen

アップデート情報

정보 업데이트

Actualización de información

www.dell.com | support.dell.com

Dell™ PowerEdge™

SC1420 Systems

Information Update

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how

to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Abbreviations and Acronyms

For a complete list of abbreviations and acronyms, see "Glossary" in your

User’s Guide

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarksusedinthistext:Dell,theDELLlogo,andPowerEdgearetrademarksofDellInc.;Microsoft and Windows are registered trademarks

of Microsoft Corporation;Red Hat is a registered trademark of Red Hat, Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

October 2004 P/N J4706 Rev. A05

Contents 3

Contents

Installing Microsoft Windows Small Business Server 2003 . . . . . . . . . 5

Installing Red Hat Enterprise Linux ES (version 3) . . . . . . . . . . . . . . 5

Memory Cooling Fan and Shroud . . . . . . . . . . . . . . . . . . . . . . 5

Installing the Memory Cooling Fan and Shroud . . . . . . . . . . . . . 6

System Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 7

System Setup Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Assigning a System Password . . . . . . . . . . . . . . . . . . . . . . . 14

Using Your System Password to Secure Your System . . . . . . . . . . 15

Operating With an Admin Password Set . . . . . . . . . . . . . . . . . . 15

Systems With Four Hard Drives or a Tape Backup Unit. . . . . . . . . . . . 16

Installing SCSI Hard Drives . . . . . . . . . . . . . . . . . . . . . . . . 16

Missing Memory in Systems With PCI Express ("Memory Hole") . . . . . . . 17

4Contents

Figures

Figure 1-1. Installing the Memory Cooling Fan and Shroud . . . 6

Figure 1-2. Main System Setup Program Screen . . . . . . . . 8

Figure 1-3. Installing SCSI Hard Drives . . . . . . . . . . . . 16

Tables

Table 1-1. System Messages . . . . . . . . . . . . . . . . . 7

Table 1-2. System Options . . . . . . . . . . . . . . . . . . 9

Table 1-3. Drive Options . . . . . . . . . . . . . . . . . . . 9

Table 1-4. Onboard Devices Options . . . . . . . . . . . . 10

Table 1-5. Performance Options . . . . . . . . . . . . . . 11

Table 1-6. Security Options . . . . . . . . . . . . . . . . 11

Table 1-7. Power Management Options . . . . . . . . . . . 12

Table 1-8. Maintenance Options . . . . . . . . . . . . . . 13

Table 1-9. POST Behavior Options . . . . . . . . . . . . . 13

Information Update 5

This document provides updated information for your system on the following topics:

• Installing Microsoft

Windows

Small Business Server 2003

• Installing Red Hat

Enterprise Linux ES (version 3)

• Memory cooling fan and shroud

• System error messages

• System setup options

• Execute Disable feature (System Setup options/Security options)

• Assigning a system password

• Operating with an admin password set

• Systems with four hard drives or a tape backup unit

• Installing SCSI hard drives

• Missing Memory in Systems With PCI Express ("Memory Hole")

Installing Microsoft Windows Small Business Server 2003

If you install Microsoft Windows Small Business Server 2003 on a Dell™ PowerEdge™

1420, the

installation process may appear to cease with about thirteen minutes remaining during the time

when Windows reports that it is registering components. During this portion of the installation,

Windows installs additional security updates and patches, which may take significantly longer to

install than the reported expected time remaining. While these updates are installing, you should

take no action and allow the installation the necessary time to complete. Dell testing has shown the

delay to range from 5 to over 45 minutes, depending upon your hardware configuration. Microsoft

has documented this behavior in Knowledge Base article #839492.

Installing Red Hat Enterprise Linux ES (version 3)

Before installing Linux on your system, change the

SATA Operation

option under the

Drives

in the System Setup program to

RAID Off

Memory Cooling Fan and Shroud

NOTICE: If you install more than 4 GB of memory, you must install the memory cooling fan and shroud

to prevent the memory from overheating. If you do not install the memory cooling fan and shroud, you will

receive an error message stating that you must install a fan or remove some memory.

6Information Update

www.dell.com | support.dell.com

Installing the Memory Cooling Fan and Shroud

CAUTION: See your System Information Guide for complete information about safety precautions,

working inside the computer, and protecting against electrostatic discharge.

Turn off the system and attached peripherals, and disconnect the system from the electrical

outlet.

Open the system.

Align the memory cooling fan and shroud tabs with the holes on the back panel.

See Figure 1-1.

Figure 1-1. Installing the Memory Cooling Fan and Shroud

Insert the tabs and lower the memory cooling fan and shroud until it snaps into place.

Connect the memory cooling fan and shroud power cable to the system board. See Figure 1-1.

Close the system.

Reconnect the system to the electrical outlet, and turn on the system.

cooling fan

and shroud

shroud tabs (4)

power cable

Information Update 7

System Error Messages

Table 1-1 lists the system error messages that have been added to POST.

Table 1-1. System Messages

Message Causes Corrective Actions

Alert! Memory fan has

failed or is not present.

A memory fan is required

for the current memory

configuration. Please see

the documentation that

came with your computer

for more information.

Greater than 4 GB memory installed

without installing required memory

fan.

Install or replace the memory cooling fan

and shroud.

Alert! Operating in debug

mode. Please populate

memory in pairs for normal

operation.

Only one memory module with a

capacity greater than 256 MB is

installed in DIMM_1.

You will see this error message when

troubleshooting memory modules. After

you have completed the troubleshooting

procedures, populate the memory in

identical pairs. See "Troubleshooting

System Memory" and "Memory

Installation Guidelines" in your

Installation and Troubleshooting Guide.

Alert! Unable to

initialize fan controller.

Faulty system board. See "Getting Help" in your Installation

and Troubleshooting Guide.

Error! Memory configured

incorrectly. Please enter

Setup for Memory Info

details.

The memory modules are installed

incorrectly.

See "Memory Installation Guidelines"

in your Installation and Troubleshooting

Guide.

8Information Update

www.dell.com | support.dell.com

System Setup Options

Main Screen

Figure 1-2 shows an example of the main screen.

Figure 1-2. Main System Setup Program Screen
