Dell™PowerEdge™850SystemsInstallationandTroubleshootingGuide

Introduction

Indicators, Messages, and Codes

Running the System Diagnostics

Troubleshooting Your System

Installing System Components

Installing Drives

Service-Only Parts Replacement Procedures

Getting Help

Jumpers, Switches, and Connectors

I/O Connectors

Notes, Notices, and Cautions

Abbreviations and Acronyms

For a complete list of abbreviations and acronyms, see the Glossary in your User's Guide.

Information in this document is subject to change without notice.

©2005DellInc.Allrightsreserved.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, PowerEdge, PowerVault, PowerApp, Dell OpenManage, Inspiron, Dell Precision, Dimension, OptiPlex, and Latitude are trademarks of Dell

Inc.; Intel, Pentium, and Celeron are registered trademarks of Intel Corporation; EMC is a registered trademark of EMC Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Initial release: April 2005

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Back to Contents Page

Jumpers, Switches, and Connectors

Dell™PowerEdge™800SystemsInstallationandTroubleshootingGuide

Jumpers—A General Explanation

System Board Jumpers

System Board Connectors

SCSI Backplane Connectors

Disabling a Forgotten Password

This section provides specific information about the system jumpers. It also provides some basic information on jumpers and switches and describes the

connectors on the various boards in the system.

Jumpers—A General Explanation

Jumpers provide a convenient and reversible way of reconfiguring the circuitry on a printed circuit board. When reconfiguring the system, you may need to

change jumper settings on circuit boards or drives.



Jumpers

Jumpers are small blocks on a circuit board with two or more pins emerging from them. Plastic plugs containing a wire fit down over the pins. The wire connects

the pins and creates a circuit. To change a jumper setting, pull the plug off its pin(s) and carefully fit it down onto the pin(s) indicated. FigureA-1 shows an

example of a jumper.

Figure A-1. Example Jumper

A jumper is referred to as open or unjumpered when the plug is pushed down over only one pin or if there is no plug at all. When the plug is pushed down

over two pins, the jumper is referred to as jumpered. The jumper setting is often shown in text as two numbers, such as 1–2. The number 1 is printed on the

circuitboardwithatrianglesothatyoucanidentifyeachpinnumberbasedonthelocationofpin1.

FigureA-2 shows the location and default settings of the server-module jumper blocks. See TableA-1 for the designations, default settings, and functions of

the jumpers.

System Board Jumpers

FigureA-2 shows the location of the configuration jumpers on the system board. TableA-1 lists the jumper settings.

Figure A-2. System Board Jumpers

NOTE: To access the jumpers, remove the memory cooling shroud by lifting the release latch and sliding the shroud toward the front of the system. See

Figure6-1.

Table A-1.SystemBoardJumperSettings

System Board Connectors

See FigureA-3 and TableA-2 for the location and description of the system board connectors.

Figure A-3. System Board Connectors



Jumper



Setting



Description

PASSWD_EN

(default)

The password feature is enabled.

The password feature is disabled.

NVRAM_CLR

(default)

The configuration settings in NVRAM are retained at system boot.

The configuration settings in NVRAM are cleared at next system boot.

Table A-2.SystemBoardConnectors

SCSI Backplane Connectors

See FigureA-4 for the location and description of the connectors on the back of the optional SCSI backplane board.

Figure A-4. Connectors on Back of SCSI Backplane



Connector



Description

12V

Power connector

BACK_FAN

Fan power connector

BATTERY

Connector for the 3.0-V coin battery

BP_I2C

Connector for the baseboard management controller (BMC) inter-IC (I2C) cable for the optional SCSI backplane

CPU

Processor connector

DIMMn_ x

Memory module connector (4)

FDD

Diskette drive connector

FRONT_FAN

Fan power connector

FRONT_PANEL

Control panel connector

IDE

IDE optical device connector

SLOT_n

PCI expansion slot connector

PWR_CONN

Power connector

RAC_CONN

Connector for the remote access controller (RAC)

SATA_n

SATA hard-drive connector

Disabling a Forgotten Password

The system's software security features include a system password and a setup password, which are discussed in detail in "Using the System Setup Program"

in your User's Guide.Thepasswordjumperenablesthesepasswordfeaturesordisablesthemandclearsanypassword(s)currentlyinuse.



1. Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.



2. Open the system. See "Opening the System" in "Troubleshooting Your System."



3. Remove the memory cooling shroud by lifting the release latch and sliding the shroud toward the front of the system. See Figure6-1.



4. Remove the password jumper plug.

See FigureA-2 to locate the password jumper on the system board.



5. Replace the memory cooling shroud.



6. Close the system. See "Closing the System" in "Troubleshooting Your System."



7. Reconnect the system to the electrical outlet, and turn on the system.

The existing passwords are not disabled (erased) until the system boots with the password jumper plug removed. However, before you assign a new

system and/or setup password, you must install the jumper plug.



8. Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.



9. Open the system.



10. Remove the memory cooling shroud.



11. Reinstall the password jumper plug in its original position to enable the password protection feature.



12. Reinstall the memory cooling shroud.



13. Close the system, reconnect the system to the electrical outlet, and turn on the system.



14. Assign a new system and/or setup password.

To assign a new password using the System Setup program, see "Using the System Setup Program" in your User's Guide.

Back to Contents Page



CAUTION: See your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting

against electrostatic discharge.

NOTE: If you assign a new system and/or setup password with the jumper plug still removed, the system disables the new password(s) the next

time it boots.

Back to Contents Page

I/O Connectors

Dell™PowerEdge™800SystemsInstallationandTroubleshootingGuide

Serial Connector

Parallel Connector

PS/2-Compatible Keyboard and Mouse Connectors

Video Connector

USB Connectors

Integrated NIC Connectors

Network Cable Requirements

I/O connectors are the gateways that the system uses to communicate with external devices, such as a keyboard, mouse, printer, or monitor. This section

describes the various connectors on your system. If you reconfigure the hardware connected to the system, you may also need the pin number and signal

information for these connectors. FigureB-1 illustrates the connectors on the system.

Figure B-1. I/O Connectors

TableB-1 shows the icons used to label the connectors on the system.

Table B-1. I/O Connector Icons

Serial Connector

Serial connectors support devices such as external modems, printers, and mice that require serial data transmission. The serial connector is also used by the

BMC to provide remote access to the system. The serial connector uses a 9-pin D-subminiature connector.



Icon



Connector

Serial connector

Parallel connector

Mouse connector

Keyboard connector

Video connector

USB connector

NIC connector

Serial Connector Autoconfiguration

The default designation of the integrated serial connector is COM1. When you add an expansion card containing a serial connector that has the same

designation as the integrated connector, the system's autoconfiguration feature remaps (reassigns) the integrated serial connector to the next available

designation. Both the new and the remapped COM connectors share the same IRQ setting. COM1 and COM3 share IRQ4, while COM2 and COM4 share IRQ3.

Before adding a card that remaps the COM connectors, check the documentation that came with the software to make sure that the software can

accommodate the new COM connector designation.

FigureB-2 illustrates the pin numbers for the serial connector and TableB-2 defines the pin assignments for the connector.

Figure B-2. Serial Connector Pin Numbers

Table B-2.SerialConnectorPinAssignments

Parallel Connector

The integrated parallel connector, intended primarily for use by printers that require data in parallel format, uses a 25-pin D-subminiature connector on the

system's back panel. The default designation of the system's parallel connector is LPT1. If you add an expansion card containing a parallel connector

configured as LPT1 (IRQ7, I/O address 378h), use the System Setup program to remap the integrated parallel connector. See "Using the System Setup

Program" in the User's Guide. FigureB-3 illustrates the pin numbers for the parallel connector and TableB-3 defines the pin assignments for the connector.

Figure B-3. Parallel Connector Pin Numbers

Table B-3.ParallelConnectorPinAssignments

NOTE: If two COM connectors share an IRQ setting, you may not be able to use them both at the same time. In addition, if you install one or more

expansion cards with serial connectors designated as COM1 and COM3, the integrated serial connector is disabled.



Signal



I/O



Definition

DCD

Data carrier detect

SIN

Serial input

SOUT

Serial output

DTR

Data terminal ready

GND

N/A

Signal ground

DSR

Data set ready

RTS

Request to send

CTS

Clear to send

Ring indicator

Shell

N/A

Chassis ground



Signal



I/O



Definition

STB#

I/O

Strobe

PD0

I/O

Printer data bit 0

PD1

I/O

Printer data bit 1

PD2

I/O

Printer data bit 2

PD3

I/O

Printer data bit 3

PD4

I/O

Printer data bit 4

PD5

I/O

Printer data bit 5

PD6

I/O

Printer data bit 6

PD7

I/O

Printer data bit 7

ACK#

Acknowledge

PS/2-Compatible Keyboard and Mouse Connectors

The PS/2-compatible keyboard and mouse cables attach to 6-pin, miniature DIN connectors. FigureB-4 illustrates the pin numbers for these connectors and

TableB-4 defines the pin assignments for these connectors.

Figure B-4. PS/2-Compatible Keyboard and Mouse Connector Pin Numbers

Table B-4. Keyboard and Mouse Connector Pin Assignments

Video Connector

You can attach a VGA-compatible monitor to the system's integrated video controller using a 15-pin high-density D-subminiature connector on the system front

or back panel. FigureB-5 illustrates the pin numbers for the video connector and TableB-5 defines the pin assignments for the connector.

Figure B-5. Video Connector Pin Numbers

Table B-5. Video Connector Pin Assignments

BUSY

Busy

Paper end

SLCT

Select

AFD#

Automatic feed

ERR#

Error

INIT#

Initialize printer

SLIN#

Select in

18–25

GND

N/A

Ground



Signal



I/O



Definition

KBDATA or MDATA

I/O

Keyboard data or mouse data

N/A

No connection

GND

N/A

Signal ground

FVcc

N/A

Fused supply voltage

KBCLK or MCLK

I/O

Keyboard clock or mouse clock

N/A

No connection

Shell

N/A

Chassis ground

NOTE: Installing a video card automatically disables the system's integrated video controller.



Signal



I/O



Definition

RED

Red video

GREEN

Green video

BLUE

Blue video

N/A

No connection

5–8, 10

GND

N/A

Signal ground

VCC

N/A

Vcc

N/A

No connection

DDC data out

Monitor detect data

USB Connectors

The system's USB connectors support USB-compliant peripherals such as keyboards, mice, and printers and may also support USB-compliant devices such as

diskette drives and optical drives. FigureB-6 illustrates the pin numbers for the USB connector and TableB-6 defines the pin assignments for the connector.

Figure B-6. USB Connector Pin Numbers

Table B-6. USB Connector Pin Assignments

Integrated NIC Connectors

Each of the system's integrated NICs function as a separate network expansion card while providing fast communication between servers and workstations.

FigureB-7 illustrates the pin numbers for the NIC connector and TableB-7 defines the pin assignments for the connectors.

Figure B-7. NIC Connector

Table B-7. NIC Connector Pin Assignments

Network Cable Requirements

The NIC supports a UTP Ethernet cable equipped with a standard RJ45-compatible plug.

Observe the following cabling restrictions.

HSYNC

Horizontal synchronization

VSYNC

Vertical synchronization

N/A

No connection

NOTICE: Do not attach a USB device or a combination of USB devices that draw a maximum current of more than 500 mA per channel or +5 V. Attaching

devices that exceed this threshold may cause the USB connectors to shut down. See the documentation that accompanied the USB devices for their

maximum current ratings.



Signal



I/O



Definition

Vcc

N/A

Supply voltage

DATA

Data in

+DATA

Data out

GND

N/A

Signal ground



Signal



I/O



Definition

TD+

Data out (+)

TD–

Data out (–)

RD+

Data in (+)

N/A

No connection

N/A

No connection

RD–

Data in (–)

N/A

No connection

N/A

No connection

lUse Category 5 or greater wiring and connectors.

lDo not exceed a cable run length (from a workstation to a hub) of 100 m (328 ft).

For detailed guidelines on operation of a network, see "Systems Considerations of Multi-Segment Networks" in the IEEE 802.3 standard.

Back to Contents Page



NOTICE: To avoid line interference, voice and data lines must be in separate sheaths.

Otros manuales para PowerEdge 850

Tabla de contenidos

Otros manuales de Servidor de Dell

Dell

Dell ECS EX Series Instrucciones de instalación

Dell

Dell PowerEdge T410 Manual de usuario

Dell

Dell PowerEdge 1400SC Manual de usuario

Dell

Dell PowerEdge T105 Systems Manual de usuario

Dell

Dell PowerEdge 2410 Manual de usuario

Dell

Dell Precision KR019 Manual de usuario

Dell

Dell EMC PowerEdge R750xs Manual

Dell

Dell VMware ESX Server 3i Manual de usuario

Dell

Dell PowerEdge 500SC Manual técnico

Dell

Dell PowerEdge R510 Manual de usuario

Dell

Dell PowerEdge C5230 Manual de usuario

Dell

Dell PowerEdge T620 Manual

Dell

Dell PowerEdge C6100 Manual de usuario

Dell

Dell PowerEdge R860 Manual

Dell

Dell PowerEdge C410X Manual de lista de piezas

Dell

Dell PowerEdge R210 Manual técnico

Dell

Dell PowerEdge systems 6300 Manual de lista de piezas

Dell

Dell PowerEdge C6220 II Manual de usuario

Dell

Dell PowerEdge R730 Guía de inicio rápido

Dell

Dell PowerEdge R920 Manual de usuario

Dell

Dell PowerEdge E31S Series Manual de usuario

Dell

Dell PowerEdge 4200 Series Manual de usuario

Dell

Dell PowerEdge C6100 Hoja de datos

Dell

Dell PowerEdge XR4520c Manual

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario

Planet

Planet NAS-7410 Manual de usuario

Lenovo

Lenovo ThinkSystem SR635 V3 Manual de usuario

Fujitsu

Fujitsu PRIMERGY BX900 Manual de usuario

Asus

Asus RS700DA-E6 PS4 Manual de usuario
