Dell™ PowerEdge™
M1000e, M910, M905, M805,
M710HD, M710, M610x, M610,
M605, and M600
Getting Started
With Your System
Guide de mise en route
Primeiros passos com o sistema
Procedimientos iniciales con el sistema
Dell™ PowerEdge™
M1000e, M910, M905, M805,
M710HD, M710, M610x, M610,
M605, and M600
Getting Started
With Your System
Model BMX01, HHB Series, FHB Series
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use
of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data
if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
____________________
Information in this document is subject to change without notice.
© 2010 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and PowerEdge are trademarks of Dell Inc.;
Citrix is a trademark of Citrix Systems, Inc. and/or one or more of its subsidiaries, and may be
registered in the United States Patent and Trademark Office and in other countries; Intel is a
registered trademark of Intel Corporation in the U.S. and other countries; Microsoft,Windows,
and Windows Server are either trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries; Red Hat and Red Hat Enterprise Linux are registered trademarks
of Red Hat Inc. in the United States and other countries; SUSE is a registered trademarks of Novell, Inc.,
in the United States and other countries; VMware is a registered trademark or trademark (the "Marks")
of VMware, Inc. in the United States and/or other jurisdictions; Solaris is a trademark of Sun
Microsystems, Inc. in the United States and other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Model BMX01, HHB Series, FHB Series
March 2010 P/N W7NC1 Rev. A00
Getting Started With Your System 3
Installation and Configuration
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
This section describes the steps required to set up your system for the first time.
Unpack the System
Unpack your system and identify each item.
Installing the Rails and System in a Rack
Assemble the rails and install the system in the rack following the
safety instructions and the rack installation instructions provided
with your enclosure.
4Getting Started With Your System
Installing the Blades
Beginning at the top, slide the modules into the enclosure from left to right.
When the blade is securely installed, the handle returns to the closed position.
Connecting the CMC and KVM Modules
Connect the serial cable and network cable(s) from the management
system to the CMC module. If a second, optional CMC module is installed,
connect it as well.
Connect the keyboard, mouse, and monitor to the optional iKVM module.
Getting Started With Your System 5
Connecting the System to Power
Connect the system’s power cables to the system power supplies.
CAUTION: To prevent the power cables from being disconnected accidentally,
use the plastic clip on each power supply to secure the power cable to the
power supply, and use the Velcro strap to secure the cable to the strain-relief bar.
Plug the other end of the power cables into a power distribution unit (PDU).
CAUTION: Do not plug the power cables directly into a power outlet; you must
use a PDU. For optimal system functionality, a minimum of three power supplies
are required.
6Getting Started With Your System
Turning On the System
Press the power button on the enclosure. The power indicator should light.
NOTE: Once you have connected the system to the power supplies, there may
be a minimal delay before you can turn on your system.
Turning On the Blades
Press the power button on each blade, or power on the blades using
the systems management software.
Getting Started With Your System 7
Complete the Operating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system
for the first time, see the installation and configuration documentation
for your operating system. Be sure the operating system is installed before
installing hardware or software not purchased with the system.
Supported Operating Systems
Operating System
M710HD
M910 M905 M805 M710 M610 M610x M605
Citrix®XenServer 5.5
Citrix®XenServer 5.6
Microsoft®Windows
Server®2008 Hyper-V Server
Microsoft Windows®Essential
Business Server 2008 Standard
and Premium Editions
Microsoft Windows HPC
Server 2008 (x64)
Microsoft Windows
Server 2008 Standard and
Enterprise (x86) Editions
Microsoft Windows Web
Server 2008 (x86) Edition
Microsoft Windows Web
Server 2008 (x86) Edition
with SP2
Microsoft Windows
Server 2008 Standard and
Enterprise (x86)
Editions with SP2
Microsoft Windows
Server 2008 Standard,
Enterprise, and
Datacenter (x64) Editions
Microsoft Windows Web
Server 2008 (x64) Edition
8Getting Started With Your System
Microsoft Windows Web
Server 2008 (x64) Edition
with SP2
Microsoft Windows Server 2008
R2 Standard, Enterprise, and
Datacenter (x64) Editions
Microsoft Windows Server 2003
Standard and Enterprise
Editions
Microsoft Windows Server 2003
Web Edition
Microsoft Windows
Server 2003
Standard Enterprise, and Web
Editions with SP1 and later
Microsoft Windows Server 2003
R2 Standard and Enterprise
(x86) Editions
Microsoft Windows Server 2003
Standard and Enterprise (x64)
Editions
Microsoft Windows
Server 2003 R2 Standard and
Enterprise (x64) Editions
Microsoft Windows
Server 2003 R2 Datacenter
(x64) Edition
Microsoft Windows
Server 2003 R2 Standard,
Enterprise, and Datacenter
(x64) Editions with SP2
Red Hat®Enterprise Linux®
AS, ES, and WS (version 4.0)
Update 5 (x86)
Red Hat Enterprise Linux AS,
ES, and WS (version 4.0)
Update 5 (x86_64)
Red Hat Enterprise Linux AS
and ES (version 4.7) (x86)
Red Hat Enterprise Linux AS
and ES (version 4.7) (x86_64)
Operating System
M710HD
M910 M905 M805 M710 M610 M610x M605
