Dell UP3214Q Manual de usuario

Dell UltraSharp 32 Monitor

User’s Guide

Model No. : UP3214Q

Regulatory model: UP3214Qt

Regulatory type: UP3214Q001

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the

written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of

Dell Inc.; Microsoft and Windows are either trademarks or registered

trademarks of Microsoft. Corporation in the United States and/or other

countries, Intel is a registered trademark of Intel Corporation in the U.S.

and other countries; and ATI is a trademark of Advanced Micro Devices,

Inc. ENERGY STAR is a registered trademark of the U.S. Environmental

Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined

that this product meets the ENERGY STAR guidelines for energy

efficiency.

Other trademarks and trade names may be used in this document

to refer to either the entities claiming the marks and names or their

products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

2014 – 03 Rev. A01

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or

loss of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

Contents 3

Contents

1 About Your Monitor .......................5

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . .5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . .6

Identifying Parts and Controls . . . . . . . . . . . . . . . . . . .7

Monitor Specifications . . . . . . . . . . . . . . . . . . . . . . 10

Plug and Play Capability . . . . . . . . . . . . . . . . . . . . . 18

LCD Monitor Quality and Pixel Policy. . . . . . . . . . . . . .18

Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . 19

2 Setting Up the Monitor ...................20

Attaching the Stand. . . . . . . . . . . . . . . . . . . . . . . .20

Connecting Your Monitor . . . . . . . . . . . . . . . . . . . . 20

Organizing the Cables . . . . . . . . . . . . . . . . . . . . . . 22

Attaching the Cable Cover. . . . . . . . . . . . . . . . . . . .22

Removing the Stand . . . . . . . . . . . . . . . . . . . . . . . 23

Wall Mounting (Optional) . . . . . . . . . . . . . . . . . . . . 23

3 Operating the Monitor ....................25

Using the Front Panel Controls . . . . . . . . . . . . . . . . . 25

Using the On-Screen Display (OSD) Menu . . . . . . . . . . .27

Setting the Maximum Resolution . . . . . . . . . . . . . . . . 44

Setting Up the DP1.2 Display . . . . . . . . . . . . . . . . . . 45

Using the Tilt, Swivel, and Vertical Extension. . . . . . . . . .48

4 Troubleshooting .........................49

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Built-in Diagnostics. . . . . . . . . . . . . . . . . . . . . . . .50

Common Problems . . . . . . . . . . . . . . . . . . . . . . . 52

Product Specific Problems. . . . . . . . . . . . . . . . . . . .55

Troubleshooting the Card Reader. . . . . . . . . . . . . . . .56

4Contents

5 Appendix ................................58

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 58

FCC Notices (U.S. Only) and Other Regulatory Information . 58

Contact Dell. . . . . . . . . . . . . . . . . . . . . . . . . . . .58

6 Setting Up Your Monitor Display ...........59

Setting the display resolution to 3840 x 2160 (maximum) . . 59

If you have a Dell™ desktop or a Dell™ portable computer

with internet access . . . . . . . . . . . . . . . . . . . . . . . 60

If you have non Dell™ desktop, portable computer,

or graphic card . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Procedures for setting up dual monitors in

Windows Vista®, Windows®7 or Windows®8 . . . . . . . . 62

About Your Monitor 5

About Your Monitor

Package Contents

Your monitor ships with the components shown below. Ensure that you have

received all the components and Contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Some features or media may not be available in certain countries.

NOTE: To set up with any other stand, please refer to the respective stand

setup guide for setup instructions.

• Monitor

• Stand

• Cable Cover

6About Your Monitor

• Power cable (varies by

countries)

• DisplayPort cable (Mini-

DP to DP)

• USB 3.0 upstream cable

(enables the USB ports

on the monitor)

UP3 21 4Q Ul tr aS ha rp M on it orDel l

™

P/N 8FH9F Rev. A00

P/N 90.7V7 39.001

October 2013

Made in China

• Drivers and

Documentation media

• Quick Setup Guide

• Product and Safety

Information Guide

• Factory Calibration

Report

Product Features

The Dell UltraSharp 32 Monitor (Model # UP3214Q) has an active matrix,

thinfilm transistor (TFT), liquid crystal display (LCD), and LED backlight. The

monitor features include:

• 80.1 cm (31.5-inch) active area display (Measured diagonally) 3840 x 2160

resolution, plus full-screen support for lower resolutions.

• Tilt, swivel and vertical extension adjustment capabilities.

• Removable pedestal and Video Electronics Standards Association (VESA™)

100 mm mounting holes for flexible mounting solutions.

• Plug and play capability if supported by your system.

About Your Monitor 7

• On-Screen Display (OSD) adjustments for ease of set-up and screen

optimization.

• Software and documentation media includes an information file (INF),

Image color Matching File (ICM), Dell Display Manager software application

and product documentation. Dell Display Manager included (comes in the

CD attached with the monitor).

• Security lock slot.

• Asset Management Capability.

• Energy Star Compliant.

• EPEAT Gold Compliant.

• RoHS compliant.

• BFR/PVC Free monitor (excluding cables).

• Arsenic-Free glass and Mercury Free for Panel only.

• Energy Gauge shows the energy level being consumed by the monitor in

real time.

• TCO Certified Displays.

Identifying Parts and Controls

Front View

Front view Front panel controls

Label Description

1 Function buttons (For more information, see Operating the Monitor)

2 Power On/Off button (with LED indicator)

8About Your Monitor

Back View

Back view Back view with monitor stand

Label Description Use

1 VESA mounting holes (100

mm x 100 mm - behind

attached VESA Cover)

Wall mount monitor using VESA-

compatible wall mount kit (100 mm x

100 mm).

2 Regulatory label Lists the regulatory approvals.

3 Security lock slot Secures monitor with security cable

lock.

4 Barcode serial number label Refer to this label if you need to

contact Dell for technical support.

5 Stand release button Release stand from monitor.

6 USB downstream port with

battery charging

Connect your USB device. You can

only use this connector after you

have connected the USB cable to

the computer and USB upstream

connector on the monitor.

7 Cable management slot Use to organize cables by placing them

through the slot.

About Your Monitor 9

Side View

Card Reader Slot

Bottom View

123456

7 7

Label Description Use

1 AC power connector To connect the monitor power cable.

2 DisplayPort in

connector

Connect your computer with DP cable.

3 Mini DisplayPort in

connector

Connect your computer with Mini DP to DP

cable.

4 HDMI connector Connect your computer with HDMI cable.

5 USB upstream port Connect the USB cable that comes with your

monitor to the computer. Once this cable is

connected, you can use the USB downstream

connectors on the monitor.

6 USB downstream ports Connect your USB device. You can only use

this connector after you have connected

the USB cable to the computer and USB

upstream connector on the monitor.

7 Dell Soundbar

mounting slots

Attaches the optional Dell Soundbar. (Sealed

by removable plastic sheets)

NOTE: Dell soundbar is sold separately.

10 About Your Monitor

Monitor Specifications

Flat panel Specifications

Screen type Active matrix - TFT LCD

Panel type In Plane Switching

Viewable image dimensions

Diagonal

Horizontal

Vertical

80.1 cm (31.5-inches viewable image size)

697.9 mm (27.5 inches)

392.6 mm (15.5 inches)

Pixel pitch 0.182 mm

Viewing angle 176° (vertical) typ, 176° (horizontal) typ

Luminance output 350 cd/m² (typ)

Contrast ratio 1000:1 (typ)

Faceplate coating Antiglare with hard-coating 3H

Backlight LED edge light system

Response Time 8 ms typical

Color depth 1.0737 B (10 Bits)

Color gamut (Typical) 100% (sRGB) 99% (Adobe RGB)

Resolution Specifications

Horizontal scan range 30 kHz to 140 kHz (automatic)

Vertical scan range 24 Hz to 75 Hz (automatic)

Maximum resolution 3840x2160 at 60Hz DP1.2*

3840x2160 at 30Hz HDMI

* To display 3840 x 2160 at 60 Hz, DP1.2 must be enabled and the DP source’s

graphics card must be DP1.2 certified with MST feature, capable of supporting

resolution up to 3840 x 2160 at 60Hz and its driver supports DisplayID v1.3.

Video Supported Modes

Video display capabilities (HDMI playback) 480p, 576p, 720p and 1080p

Preset Display Modes

Display Mode Horizontal

Frequency

(kHz)

Vertical

Frequency

(Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/

Vertical)

720 x 400 31.5 70.0 28.3 -/+

640 x 480 31.5 60.0 25.2 -/-
