Dell SE3223Q Manual de usuario

Monitor Model: SE3223Q

Regulatory Model: SE3223Qc

Dell SE3223Q Monitor

Dell Display Manager

User’s Guide

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective

owners.

2022 – 03

Rev. A00

Contents | 3

Contents

Overview ....................................................... 4

Selecting Quick Settings options..................... 5

Setting basic display options........................... 7

Assigning preset modes to applications............ 9

Organizing windows with Easy Arrange ...........10

Managing multiple video inputs ...................... 13

Restoring Application Positions...................... 15

Attaching DDM to an active window ............... 17

Applying energy conservation options............. 18

Defining shortcut keys................................... 19

Troubleshooting........................................... 20

4| Overview

Overview

Dell Display Manager (DDM) is an application that enables you to configure the

supported Dell monitor settings such as brightness, contrast, and preset modes.

After its installation, Dell Display Manager is accessible from the notification tray.

Information about monitors connected to the computer is available when the mouse

is pointed over the notification tray icon.

NOTE: Dell Display Manager uses Display Data Channel Command

Interface (DDC/CI) channel to communicate with your monitor. Ensure

that DDC/CI is enabled in the menu as shown in the following image.

Input Source

Color

Display

Dell 32 Monitor

Brightness / Contrast

DDC/CI On

Display Info

LCD Conditioning

Reset Others

Factory Reset

Service Tag

Firmware

Personalize

PIP/PBP

Others

Self-Diagnostic

Selecting Quick Settings options | 5

Selecting Quick Settings options

Click the Dell Display Manager’s notification tray. The Quick Setings window is

displayed.

If more than one supported Dell monitor is connected to the computer, a specific

target monitor can be selected from the Display drop-down list.

In the Quick Settings window, you can also change the following:

* Resolution

* Auto Mode or Manual Mode the screen appearance

* Brightness and contrast levels

* Easy Arrange window layouts for the monitor

6| Selecting Quick Settings options

In the Quick Settings window, click Open Dell Display Manager for configuring

the advanced settings.

Feature Function Description

Quick DDM Access Shortcut key to

open DDM user

interface (UI).

Ctrl+Shift+D

Control individual

monitor in multi-

monitor setup

Select the monitor from the drop-down

list.

Move DDM UI to the monitor to be

controlled.

Press Ctrl+Shift+D to open the mini UI

under the mouse pointer.

Setting basic display options | 7

Setting basic display options

Select Manual Mode to manually select a Preset Mode or select Auto Mode

that applies a preset mode based on the active application. An on-screen message

displays the current preset mode whenever it changes. The selected monitor’s

brightness and contrast levels can also be directly adjusted from the Basic tab.

Chroma Vision

NOTE: When multiple Dell monitors are connected, select “Enable

display matrix control” to apply brightness, contrast, and color presets

controls to all monitors.

8| Setting basic display options

Assigning preset modes to applications | 9

Assigning preset modes to applications

The Auto Mode tab enables you to associate a specific Preset Mode with a

specific application, and apply it automatically. When Auto Mode is enabled, Dell

Display Manager will automatically switch to the corresponding Preset Mode

whenever the associated application is activated. The Preset Mode assigned to a

particular application may be the same on each connected monitor, or it can vary

from one monitor to the next.

Dell Display Manager is pre-configured for many popular applications. To add a new

application to the Application list, drag the application from the desktop, Windows

Start Menu, or elsewhere, and drop it onto the current list.

NOTE: Preset Mode assignments for batch les, scripts, loaders,

and non-executable les such as zip archives or packed les, are not

supported.

You can also configure the Game preset mode to be used whenever a Direct3D

application runs in full-screen mode. To prevent an application from using mode,

assign a different preset mode to it.

10 | Organizing windows with Easy Arrange

Organizing windows with Easy Arrange

On supported Dell monitors, the Easy Arrange tab enables you to easily arrange the

open windows in one of the predefined layouts by dragging them in the zones. Press

“>” or use Page Up/Page Down key to find more layouts. To create a custom layout,

arrange the open windows, and then click Save.

To get started with Easy Arrange, choose a target monitor and select one of

the predefined layouts. The regions for that layout are displayed momentarily on

the monitor. Next, drag an open window across the monitor. While the window is

being dragged, the current window layout is displayed and an active region gets

highlighted as the window passes over it. At any time, drop the window into the

active region to place the window in that region.

To create a custom window layout, size and position the windows on the desktop,

and then click Save in Easy Arrange. The size and position of the windows is saved

as a custom layout and the custom layout icon is created.

NOTE: This option does not save or remember the applications that are

open. Only the size and position of the windows is saved.
