Dell SE2717HR Manual de usuario

Model No.: SE2717H/SE2717HX/SE2717HR

Regulatory model: SE2717Hc

User’s Guide

Dell SE2717H/SE2717HX/SE2717HR

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss

of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their

respective owners.

2019– 03

Rev. A05

│3

Contents

About your monitor ......................... 6

Package contents . . . . . . . . . . . . . . . . . . . . . . 6

Product features . . . . . . . . . . . . . . . . . . . . . . .7

Identifying parts and controls . . . . . . . . . . . . . . . .9

Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Back view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Side view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Bottom view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Monitor specications . . . . . . . . . . . . . . . . . . . 12

Resolution specications . . . . . . . . . . . . . . . . . . . . . . 13

Supported video modes . . . . . . . . . . . . . . . . . . . . . . . 13

Preset display modes . . . . . . . . . . . . . . . . . . . . . . . . 13

FreeSync Graphic Card Support List . . . . . . . . . . . . . . . . 13

Electrical specications. . . . . . . . . . . . . . . . . . . . . . . 14

Physical characteristics. . . . . . . . . . . . . . . . . . . . . . . 15

Environmental characteristics . . . . . . . . . . . . . . . . . . . 16

Power management modes . . . . . . . . . . . . . . . . . . . . . 16

Pin assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Plug and play capability . . . . . . . . . . . . . . . . . . 20

LCD monitor quality and pixel policy . . . . . . . . . . . 20

Maintenance guidelines . . . . . . . . . . . . . . . . . . 20

Cleaning your monitor. . . . . . . . . . . . . . . . . . . . . . . . 20

4 │

Setting up the monitor.......................21

Connecting the stand . . . . . . . . . . . . . . . . . . . 21

Connecting your monitor . . . . . . . . . . . . . . . . . 22

Connecting the VGA cable (sold separately for SE2717HX/

SE2717HR). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Connecting the HDMI cable (sold separately for SE2717H) . . . . 22

Organizing cables . . . . . . . . . . . . . . . . . . . . . 23

Removing the stand . . . . . . . . . . . . . . . . . . . . 24

To remove the stand: . . . . . . . . . . . . . . . . . . . . . . . . 24

Operating your monitor ..................... 25

Power on the monitor . . . . . . . . . . . . . . . . . . . 25

Using the control buttons . . . . . . . . . . . . . . . . . 25

OSD controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using the on-screen display (OSD) menu. . . . . . . . . 28

Accessing the OSD menu . . . . . . . . . . . . . . . . . . . . . . 28

OSD warning messages . . . . . . . . . . . . . . . . . . . . . . . 40

Setting up your monitor . . . . . . . . . . . . . . . . . . 42

Setting the maximum resolution . . . . . . . . . . . . . . . . . . 42

If you have a non Dell desktop, portable computer, or graphics card

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Using tilt . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Troubleshooting ........................... 45

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Built-in diagnostics . . . . . . . . . . . . . . . . . . . . 46

Common problems . . . . . . . . . . . . . . . . . . . . . 47

│5

Product-specic problems . . . . . . . . . . . . . . . . 49

Appendix................................. 50

FCC notices (U.S. Only) and other regulatory information50

Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . 51

About your monitor

Package contents

Your monitor ships with the components shown in the table below. If any

component is missing, contact Dell technical support. For more information see

Contacting Dell.

NOTE: Some items may be optional and may not ship with your monitor.

Some features or media may not be available in certain countries.

NOTE: Some items may be optional and may not ship with your monitor.

Some features or media may not be available in certain countries.

NOTE: To set up your monitor with a third-party stand, refer to the respective

stand setup guide for setup instructions.

• Monitor

• Stand riser

• Stand base

• Power Cable (Varies by

Countries)

• VGA Cable (for SE2717H)

6 │About your monitor

• HDMI Cable (for SE2717HX/

SE2717HR)

Dell

SE2717H/SE2717HX/HR Monitor

• Drivers and Documentation

Media

• Quick Setup Guide

• Safety and Regulatory

Information

Product features

The Dell SE2717H/SE2717HX/SE2717HR at panel display has an active matrix,

Thin-Film Transistor (TFT), Liquid Crystal Display (LCD), anti-static, and LED

backlight. The monitor features include:

• SE2717H/SE2717HX/SE2717HR: 68.6 cm (27 inch) viewable area display

(measured diagonally). 1920 x 1080 resolution, plus full-screen support for

lower resolutions.

• Wide viewing angle to allow viewing from a sitting or standing position, or

while moving from side-to-side.

• VGA and HDMI connectivity makes it simple and easy to connect with legacy

and new systems.

• Plug and play capability if supported by your system.

• On-Screen Display (OSD) adjustments for ease of set-up and screen

optimization.

• Software and documentation media includes an Information File (INF), Image

Color Matching File (ICM), and product documentation.

• Dell Display Manager Software included (in the CD shipped with the monitor).

• Energy Saver feature for Energy Star compliance.

• Security-lock slot.

• BFR/PVC-reduced.

• Arsenic-Free glass and Mercury-Free for the panel only.

• High Dynamic Contrast Ratio (8,000,000:1).

About your monitor │7

• 0.3 W standby power when in the sleep mode.

• Energy Gauge shows the energy level being consumed by the monitor in real

time.

• Supports AMD FreeSync™ technology.

• Optimize eye comfort with a flicker-free screen.

• ComfortView feature is designed to reduce the amount of blue light emitted

from the monitor to optimize eye comfort. See the Safety Instructions.

8 │About your monitor

Identifying parts and controls

Front view

1 2

Control buttons

Label Description

1Function buttons (For more information, see Operating your monitor)

2Power On/Off button

NOTE: For displays with glossy bezels the user should consider the

placement of the display as the bezel may cause disturbing reflections

from surrounding light and bright surfaces.

About your monitor │9

Back view

Dateof Mfg/

TPVElectronics(Fujian) Co., Ltd.

080-200-3800

S/N: CN-12MWY-

64180-341-001L

-A00

SVC Tag:

xxxxxxx

Express Service

Code:

xxx xxx xxx x

Dateof Mfg/⭕ӝᰛᵕ⭕⭘ᰛᵕ: May. 2015

XXXXX

R33037

RoHS

XXXXXXX-XXXXX

MSIP-REM-TPF-SE2717Hc

㐔㷡㢬ڊ㥐㦤㣄ڕ

TPVElectronics(Fujian) Co., Ltd.

080-200-3800

[

XXXXXX-XX

Consumode energía: xx.x Wh

Consumode energía en modo de espera: x.x Wh

Удельнаямощность рабочего режима - x.xxxВт/см²

Потребляемаямощность изделием в режиме ожидания - x.xx Вт

Потребляемаямощность изделием в выключенном режиме - x.xx Вт

䆜䃔ֵ⭞䚄ᓜᚆۭᇩ㿌࣑

䊂

SE2717H/SE2717HX

SE2717Hc

SE2717H/SE2717HX

SE2717Hc

1.5A

CANICES-3(B)/BMB-3(B)

Apparatetmålko plesjordetskkontakt.

Apparatenskallanslutas ll jordat uag.

Laiteonliiteävä suojakoskemilla varusteuun pistorasiaan.

Apparatetsskpropskal lslues en skkontakt med jord,

somgiverforbindelse l skpro ppensjord.

Dateof Mf

TPVElectro

nics(Fu

ujian)Co.,Ltd.ujian)Co.,Ltd.

080-20

200-3800

-2

Back View without monitor stand Back View with monitor stand

Label Description Use

1Security-lock slot Secures monitor with security lock

(security lock not included).

2Barcode serial number and Service

Tag label

Refer to this label if you need to

contact Dell for technical support.

The Dell service tag is used for Dell

warranty and customer service

management purposes and for

records of the base system.

3Regulatory label Lists the regulatory approvals.

4Stand release button Releases stand from monitor.

5Cable management slot Uses to organize cables by placing

them through the slot.

10 │About your monitor
