Dell S2719DM Manual de usuario

Model: S2719DM

Regulatory model: S2719DMt

Dell S2719DM

User’s Guide

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

2018 – 02

Rev. A00

Contents

About Your Monitor ..................................... 5

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Identifying Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Monitor Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

LCD Monitor Quality and Pixel Policy. . . . . . . . . . . . . . . . . . . . . . .15

Setting Up the Monitor.................................. 16

Using the Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting Your Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Organizing Your Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Operating the Monitor .................................. 19

Turning on the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Using the Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . 19

Front-Panel Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Using the On-Screen Display (OSD) Menu . . . . . . . . . . . . . . . . . . . 22

Troubleshooting ....................................... 35

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Contents | 3

4 | Contents

Recover HDMI version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Product Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Appendix .............................................. 41

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

FCC Notices (U.S. only) and Other Regulatory Information . . . . . . . . 41

Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Setting Up Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

About Your Monitor | 5

About Your Monitor

Package Contents

Your monitor ships with the components shown below. Make sure that you have received all

the components and contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Somefeatures or media may not be available in certain countries.

Monitor with stand

Power cable (varies by country)

Power adapter

HDMI 2.0 cable

•Quick Setup Guide

•Safety,Environmental,and

Regulatory Information

6 | About Your Monitor

Product Features

The Dell S2719DM monitor has an active matrix, thinfilm transistor (TFT), liquid crystal

display (LCD), and LED backlight. The monitor features include:

• 68.47cm (27-inch) viewable area display (measured diagonally). 2560x1440 resolution

with full-screen support for lower resolutions.

• Mega dynamic contrast ratio (8,000,000:1).

• Wide viewing angles with high color gamut.

• Tilt adjustment capability.

• Plug and play capable if supported by your system.

• Minimize eye discomfort with a flicker-free screen.

• The possible long-term effects of blue light emission from the monitor may cause

damage to the eyes, including eye fatigue or digital eye strain. ComfortView feature is

designed to reduce the amount of blue light emitted from the monitor to optimize eye

comfort.

• Adapted High Dynamic Range appropriate for monitor usage.

• Supports AMD FreeSync™ technology.

• On-screen display (OSD) adjustments for easy setup and screen optimization.

• Energy Star Certified.

• CFR/BFR/PVC- Reduced (Circuit boards are made from CFR/BFR/PVC-free

laminates).

• TCO-certified displays.

• EPEAT Silver Compliant.

• RoHS Compliant.

• Arsenic-free glass and mercury-free for the panel only.

• 0.5 W standby power when in the sleep mode.

About Your Monitor | 7

Identifying Parts and Controls

Front view

Label Description

1Function buttons (For more information, see Operating the Monitor)

2Power on/off button (with LED indicator)

8 | About Your Monitor

Back and Bottom View

Label Description Use

1Audio line-out port Connect speakers to playback audio coming through

HDMI audio channels.

Only supports 2-channel audio.

NOTE: The audio line-out port does not support

headphones.

WARNING: Excessive sound pressure from

earphones or headphones can cause hearing

damage or loss.

2HDMI1 connector Connect your computer with HDMI cable.

3HDMI2 connector

4DC power connector To connect the monitor power adapter.

5Cable-management slot Use to organize cables by placing them through the

slot.

6Regulatory label, barcode,

serial number, and Service

Tag label

Lists the regulatory approvals. See this label if you

need to contact Dell for technical support.

NOTE: The rating label is located at the base of the

stand.

About Your Monitor | 9

Monitor Specifications

Screen type Active matrix - TFT LCD

Panel Type Plane To Line Switching

Aspect ratio 16:9

Viewable image dimensions

Diagonal 68.47 cm (27 inches)

Active Area

Horizontal 569.74 mm (22.43 inches)

Vertical 335.66 mm (13.21 inches)

Area 191239.86 mm² (296.30 inches²)

Pixel pitch 0.233 mm x 0.233 mm

Pixel per inch (PPI) 109

Viewing angle

Horizontal 178° (typical)

Vertical 178° (typical)

Brightness 400 cd/m² (typical)

600 cd/m² (peak)

Contrast ratio 1000 to 1 (typical)

8,000,000 to 1 (dynamic contrast on)

Faceplate coating Anti-glare treatment of the front polarizer (3H)

Backlight White LED, EDGELIGHT system

Response Time (Gray to Gray) 5 ms (FAST mode)

8 ms (NORMAL mode)

Color depth 16.7 million colors

Color gamut sRGB 1931 coverage ≥ 99%

DCI-P3 1976 coverage 85% (typical)

Connectivity •2 x HDMI2.0 with HDCP2.2(combine HDMI1.4 with

HDCP 1.4)

•1 x Analog 2.0 audio line out (3.5mm jack)

Border width (edge of monitor to

active area)

7.10 mm (Top)

7.10 mm (Left/Right)

8.00 mm (Bottom)

Adjustability

Tilt

Swivel

-5° to 21°

Dell Display Manager (DDM)

Compatibility

Easy Arrange

and other key features

10 | About Your Monitor

Resolution Specifications

Horizontal scan range 30 kHz to 120 kHz (HDMI1.4)

30 kHz to 140 kHz (HDMI2.0)

Vertical scan range 48 Hz to 75 Hz (HDMI1.4/HDMI2.0)

Maximum preset resolution 2560 x 1440 at 60 Hz

Video input capabilities

(HDMI playback)

480p,576p, 720p,1080p (HDMI1.4/HDMI2.0)

2160p(HDMI2.0)

Preset Display Modes

Display Mode Horizontal

Frequency

(kHz)

Vertical

Frequency

(Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/

Vertical)

720 x 400 31.5 70.0 28.3 -/+

VESA, 640 x 480 31.5 60.0 25.2 -/-

VESA, 640 x 480 37.5 75.0 31.5 -/-

VESA, 800 x 600 37.9 60.3 40.0 +/+

VESA, 800 x 600 46.9 75.0 49.5 +/+

VESA, 1024 x 768 48.4 60.0 65.0 -/-

VESA, 1024 x 768 60.0 75.0 78.8 +/+

VESA, 1152 x 864 67.5 75.0 108.0 +/+

VESA, 1280 x 1024 64.0 60.0 108.0 +/+

VESA, 1280 x 1024 80.0 75.0 135.0 +/+

VESA, 1600x 1200 75.0 60.0 162.0 +/+

VESA, 1920 x 1080 67.5 60.0 148.5 +/+

CVT, 2560 x 1440 88.8 60.0 241.5 +/-
