Dell S2715H Manual de usuario

Model: S2715H

Regulatory model: S2715Ht

Dell S2715H

User’s Guide

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions.

All other marks and names mentioned herein may be trademarks of their respective companies.

2014 – 07 Rev. A00

Contents

1 About Your Monitor ................................ 5

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Identifying Parts and Controls. . . . . . . . . . . . . . . . . . . . . . . . . . 8

Monitor Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

LCD Monitor Quality and Pixel Policy . . . . . . . . . . . . . . . . . . . . 20

2 Setting Up the Monitor ............................ 21

Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Connecting Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Organizing Your Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Attaching the Cable Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Removing the Monitor Stand . . . . . . . . . . . . . . . . . . . . . . . . . 25

Removing the Cable Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Wall Mounting (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3 Operating the Monitor ............................. 27

Turning on the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using the Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . 27

Using the On-Screen Display (OSD) Menu . . . . . . . . . . . . . . . . . 29

Using Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contents | 3

4| Contents

4 Troubleshooting ..................................43

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Product Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Mobile High-Definition Link (MHL) Specific Problems . . . . . . . . . . 47

Speakers Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . 47

5 Appendix .........................................48

Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

FCC Notices (U.S. only) and Other Regulatory Information . . . . . . . 48

Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Setting Up Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

About Your Monitor | 5

About Your Monitor

Package Contents

Your monitor ships with the components shown below. Make sure that you have

received all the components and contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Somefeatures or media may not be available in certain countries.

Monitor

Stand riser

Stand base

Cable cover

Power cable (varies by country)

6| About Your Monitor

Power adapter

USB cable

HDMI cable

•Drivers and documentation media

•Quick Setup Guide

•Safety and Regulatory Information

About Your Monitor | 7

Product Features

The Dell S2715H flat panel monitor has an active matrix, thin-film transistor (TFT), liquid

crystal display (LCD), and light emitting diode (LED) backlight. The monitor features

include:

• 68.58cm (27-inch) viewable area display (measured diagonally).

1920x1080 resolution with full-screen support for lower resolutions.

• Wide viewing angle to allow viewing from a sitting or standing position, or while

moving from side-to-side.

• Mega dynamic contrast ratio (8,000,000:1).

• Tilt capability.

• Ultra-thin bezel minimizes the bezel gap in multi-monitor usage, enabling easier

set up with an elegant viewing experience.

• Extensive digital connectivity with HDMI (MHL) helps future-proof your monitor.

• Removable stand and video electronics standards association (VESA) 100mm

mounting holes for flexible mounting solutions.

• Plug and play capable.

• Color gamut of 72% (CIE1931).

• On-screen display (OSD) adjustments for easy setup and screen optimization.

• Software and documentation media includes an information file (INF), Image-color

matching file (ICM), and product documentation.

• Dell display manager software (available on the disc shipped with the monitor).

• Energy saver feature for energy star compliance.

• Security-lock slot.

• Stand lock.

• Capability of switching from wide aspect to standard aspect ratio while maintaining

image quality.

• EPEAT Gold rating.

• BFR/PVC- reduced.

• TCO-certified displays.

• Arsenic-free glass and mercury-free for the panel only.

• 0.5 W standby power when in the sleep mode.

• Energy gauge shows the energy level being consumed by the monitor in real time.

8| About Your Monitor

Identifying Parts and Controls

Front view

Label Description

1Headphone port

WARNING:Excessive sound pressure from earphones or headphones can

cause hearing damage or loss.

2Function buttons (For more information, see Operating the Monitor)

3Power on/off button (with LED indicator)

Back View

Label Description Use

1VESA mounting holes

(100mmx100mm - behind

attached VESA cover)

Wall mount monitor using

VESA-compatible wall mount kit

(100mmx100mm).

2Regulatory label Lists the regulatory approvals.

3Stand-release button Release stand from monitor.

4Security-lock slot Secures monitor with security lock

(sold separately).

5Barcode, serial number, and

Service Tag label Refer to this label if you need to contact

Dell for technical support.

6Cable-management slot Use to organize cables by placing them

through the slot.

12 3

About Your Monitor | 9

Bottom View

Label Description Use

1Stand lock Lock the stand to the monitor using a M3 x 10 mm

screw (screw not included).

2Power-adapter port Connect the power adapter.

3HDMI (MHL) port Connect your computer with HDMI cable or MHL

devices with MHL cable (optional).

4VGA port Connect your computer with VGA cable (optional).

5Audio-in port Connect to your computer audio output (optional).

6USB upstream port Connect the USB cable to your computer and the

monitor to enable the USB ports on the monitor.

7USB downstream ports (2) Connect USB devices.

NOTE: You must connect the USB upstream cable

to the monitor and your computer to be able to use

these ports.

2 3 4 5 6 7

10 | About Your Monitor

Monitor Specifications

Flat Panel Specifications

Screen type Active matrix - TFT LCD

Panel type In-plane switching (IPS)

Viewable image:

Diagonal 68.58 cm (27 inches)

Active Area:

Horizontal 597.89 mm (23.54 inches)

Vertical 336.31 mm (13.24 inches)

Area 201076.39 mm2(311.67inch2)

Pixel pitch 0.3114 mm x 0.3114 mm

Viewing angle:

Vertical 178° (typical)

Horizontal 178° (typical)

Luminance output 250 cd/m² (typical)

Contrast ratio 1000 to 1 (typical)

8,000,000 to 1 (mega dynamic contrast on)

Faceplate coating Glare with hard coating (3H)

Backlight LED edgelight system

Response time 6 ms (typical) with Overdrive

Color depth 16.77 million colors

Color gamut CIE 1931*(72%)

*Color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test standards.

Resolution Specifications

Horizontal scan range 30 kHz to 83 kHz (automatic)

Vertical scan range 56 Hz to 75 Hz (automatic)

Maximum preset resolution 1920x1080 at 60 Hz

Video display capabilities

(VGA & HDMI playback)

480i, 480p, 576i, 576p, 720p, 1080i, 1080p
