Dell P4317Q Manual de usuario
Model No.: P4317Q
Regulatory model: P4317Qc
User’s Guide
Dell P4317Q
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better
use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury or death.
_________________________
Information in this document is subject to change without notice.
© 2016 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission
of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; Microsoft
and Windows are either trademarks or registered trademarks of Microsoft. Corporation in
the United States and/or other countries, Intel is a registered trademark of Intel Corporation
in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices, Inc.
ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an
ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR
guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the
entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary
interest in trademarks and trade names other than its own.
2016 - 03 Rev. A00
Contents | 3
Contents
About your monitor ................................................................ 5
Package contents.......................................................................................5
Product features.........................................................................................6
Monitor specifications............................................................................... 7
Universal Serial Bus (USB) Interface .....................................................16
Identifying parts and controls................................................................18
Plug and play capability ..........................................................................21
LCD monitor quality and pixel policy...................................................21
Maintenance guidelines.......................................................................... 21
Setting up the monitor .........................................................22
Attaching the stand..................................................................................22
Connecting your monitor ......................................................................23
Removing the monitor stand.................................................................27
Wall Mounting (Optional) .......................................................................27
4| Contents
Operating your monitor.......................................................28
Power on the monitor.............................................................................28
Using the front panel controls ..............................................................28
Using the on-screen display (OSD) menu ......................................... 30
Setting up your monitor..........................................................................45
Setting the maximum resolution ..........................................................45
Using tilt .................................................................................................... 46
Troubleshooting....................................................................47
Self-test ......................................................................................................47
Built-in diagnostics ................................................................................. 48
Common problems ................................................................................ 49
Product-specific problems .................................................................... 51
Universal Serial Bus (USB) specific problems .....................................52
Mobile high-definition link (MHL) specific problems .......................52
Appendix ....................................................................................................53
FCC notices (U.S. Only) and other regulatory information.............53
Contacting Dell.........................................................................................53
About your monitor | 5
About your monitor
Package contents
Your monitor ships with the components shown below. Ensure that you have
received all the components and Contacting Dell if something is missing.
NOTE: Some items may be optional and may not ship with your monitor. Some
features or media may not be available in certain countries.
NOTE: To set up with any other stand, please refer to the respective stand setup
guide for setup instructions.
∞ Monitor
∞ Stand riser
∞ Stand base
3
2
∞ VESA cover
∞ Power cable (varies by
countries)
∞ HDMI cable
6| About your monitor
∞ mDP to DP cable
∞ DP to DP cable
∞ USB 3.0 upstream cable
(enables the USB ports on
the monitor)
DellTM UltraSharp U2715H Monitor
∞ Drivers and
Documentation Guide
∞ Quick Setup Guide
∞ Safety and Regulatory
Information
Product features
The Dell P4317Q flat panel display has an active matrix, Thin-Film Transistor (TFT),
Liquid Crystal Display (LCD), and LED backlight. The monitor features include:
∞ 107.98 cm (42.51 inch) viewable area display (measured diagonally). 3840 x 2160
resolution, plus full-screen support for lower resolutions.
∞ Plug and play capability if supported by your system.
∞ VGA and HDMI (MHL) and DP and mDP connectivity makes it simple and easy to
connect with legacy and new system.
∞ Build-in Speaker (8W x 2).
∞ On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
∞ Software and documentation media includes an Information File (INF), Image
Color Matching File (ICM), and product documentation.
∞ Dell Display Manager Software included (in the CD shipped with the monitor).
∞ Support PIP and PBP Function.
About your monitor | 7
Monitor specifications
Model P4317Q
Screen type Active matrix - TFT LCD
Panel type In-plane Switching
Viewable image
Bezel width
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
566.40 mm (22.30 in)
107.98 cm (42.51 in)
941.18 mm (37.05 in)
529.42 mm (20.84 in)
1274.79 cm2(197.59 inch2)
Pixel pitch 0.2451 x 0.2451 mm
Viewing angle (vertical
/ horizontal)
178° / 178° (typical)
Brightness 350 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Aspect Ratio 16:9
Display screen coating Anti-Glare with 2H hardness
Backlight Technology white LED edgelight system
Response time 8 ms
Color depth 1.06 Billion colors
PIP / PBP Yes
Connectivity 1 x DP 1.2
1 x mDP 1.2
2 x HDMI 1.4 (MHL)
1 x VGA
1 x USB 3.0 port - Upstream
4 x USB 3.0 port
1 x Audio Input
1 x Headphone Output
1 x RS232
Audio output 8W x 2
Built in device - usb Upstream x 1
Downstream x 4 (including one Charging Port)
8| About your monitor
DDM compatibility Yes
Adjustability
Tilt -5° to 10°
Security Security lock slot (cable lock sold separately)
* 72% (CIE 1931), 82%(CIE 1976)
Resolution specifications
Model P4317Q
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
3840 x 2160 at 60 Hz (DP only)
Preset display modes
Display Mode Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal /
Vertical)
VESA, 720 x 400 31.5 70.1 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1440 x 900 55.5 60.0 88.8 +/-
VESA, 1440 x 900 70.1 75.0 136.8 -/+
**VESA, 1920 x 1080 67.5 60.0 148.5 +/+
VESA, 3840 x 2160 67.5 30.0 297.0 +/+
*VESA, 3840 x 2160 135.0 60.0 594.0 +/+
* Requires a graphics card that supports DisplayPort 1.2
** PBP mode maximum resolution support 1920x1080@60Hz
About your monitor | 9
Electrical specifications
Model P4317Q
Video input signals ∞ Analog RGB, 0.7 Volts +/-5%, positive polarity at 75
ohm input impedance
∞ HDMI1.4, 600 mV for each differential line, positive
polarity at 100 ohm input impedance
Synchronization input
signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on
green)
AC input voltage/frequency/
current
100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/
2 A
Inrush current 120 V:30 A (Max.)
240 V:60 A (Max.)
Physical characteristics
Model P4317Q
Signal cable type ∞ Analog: detachable, D-Sub, 15 pins
∞ Digital: detachable, HDMI, 19 pins
∞ Digital: detachable, mDP, 20 pins
∞ Digital: detachable, DP, 20 pins
Dimensions (with stand)
Height 658.0 mm (25.90 in)
Width 973.1 mm (38.31 in)
Depth 250.0 mm (9.84 in)
Dimensions (without stand)
Height 566.4 mm (22.29 in)
Width 973.1 mm (38.31 in)
Depth 83.0 mm (3.27 in)
Stand dimensions
Height 488.6 mm (19.24 in)
Width 320.0 mm (12.60 in)
Depth 250.0 mm (9.84 in)
Weight
Weight with packaging 24.4 kg (53.78 lb)
Weight with stand
assembly and cables
17.93 kg (39.51 lb)
10 | About your monitor
Weight without stand
assembly
14.11 kg (31.09 lb)
Weight of stand
assembly
3.3 kg (7.26 lb)
Caution: Any third-party arm or pole purchased separately should support the weight
of the monitor as well as any external brackets and interface plates.
Environmental characteristics
Model P4317Q
Temperature
Operating 0°C to 40°C (32°F to 104°F)
Non-operating Storage ∞ -20°C to 60°C (-4°F to 140°F)
∞ -20°C to 60°C (-4°F to 140°F)
Shipping
Humidity
Operating 10% to 80% (non-condensing)
Non-operating ∞ Storage: 5% to 90% (non-condensing)
∞ Shipping: 5% to 90% (non-condensing)
Altitude
Operating (maximum) 5,000 m (16,400 ft)
Non-operating (maximum) 12,192 m (40,000 ft)
Thermal dissipation ∞ 494.9 BTU/hour (maximum)
∞ 238.9 BTU/hour (typical)
Power management modes
If you have VESA's DPM™ compliance display card or software installed in your PC,
