Specifications: Dell™ W2300 LCD TV User's Guide
General •Flat Panel •Resolution •PC Display Modes •TV Display Modes •HDTV Display Modes •SDTV •Electrical •
Physical Characteristics •Environmental •Power Management Modes •TV and Video Power Management Modes •
Pin Assignments •Plug and Play Capability
General
Model number W2300 LCD TV
Flat Panel
Screen dimensions
Screen type Active matrix - TFT LCD
Screen dimensions 23 inches (23-inch viewable image size)
Preset display area:
Horizontal 501.12± 3 mm (20.04 inches ± 0.12 inches)
Vertical 300.67± 3 mm (12.03 inches ± 0.12 inches)
Pixel pitch 0.3915 mm
Viewing angle +/- 88° (vertical) typ, +/- 88° (horizontal) typ
Luminance output 450 CD/m ²(typ)
Contrast ratio 400 to 1 (typ)
Faceplate coating Anti-glare
Backlight CCFL (12)
Panel Weight 2.7 Kg/ 5.95lbs
Resolution
Horizontal scan range 30 kHz to 61kHz (automatic)
Vertical scan range 56 Hz to 75 Hz (automatic)
Optimal preset resolution 1280 x 768 at 60 Hz
Highest preset resolution 1280 x 768 at 75 Hz
* Highest addressable resolution 1280 x 768 at 60 Hz
* Addressable means the LCD TV will sync up to this mode.
However, Dell does not guarantee the image will be sized, shaped and centered correctly.
PC Display Modes
Display Mode Horizontal
Frequency (kHz) Vertical Frequency
(Hz) Pixel Clock
(MHz) Sync Polarity
(Horizontal/Vertical)
VGA, 720x 400 31.469 70.087 28.3 -/+
VGA, 640x 480 31.469 59.940 25.2 -/-
Exhibit 3
Installstion and Operating Instructions
TV Display Modes
Americas model
HDTV Display Modes
SDTV
VESA, 640 x 480 37.500 75.000 31.5 -/-
VESA, 800 x 600 37.879 60.317 40.0 +/+
VESA, 800 x 600 46.875 75.000 49.5 +/+
VESA, 1024 x 768 48.363 60.004 65.0 -/-
VESA, 1024 x 768 60.023 75.029 78.8 +/+
VESA, 1280 x 768 47.776 59.870 79.5 -/+
VESA, 1280 x 768 60.289 74.893 102.25 -/+
VESA, 1280 x 768 47.396 59.995 68.25 +/-
Band Assignment AIR CH CATV CH
CH Video Carrier (MHz) CH Video Carrier (MHz)
STD
VHF LOW 02-06 55.25-83.25 02-15 55.25-127.25
VHF HIGH 07-13 175.25-211.25 16-44 133.25-343.25
UHF 14-69 471.25-801.25 45-125 349.25-799.25
Display Mode Horizontal
Frequency (kHz) Vertical Frequency
(Hz) Pixel Clock
(MHz) Scan
1920 X 1080i 33.75 60 74.25 Interlace
1280 X 720P 45 60 74.25 Progressive
1920 X 1080i 28.125 50 74.25 Interlace
1280 X 720P 37.5 50 74.25 Progressive
Characteristics PAL NTSCM
Lines per picture 625 frames 525 frames
Field frequency, nominal value 60 fields/s 59.94 fields/s
Nominal video bandwidth 5HMz 4.2 MHz
Norminal line period 64µs 63.5555µs
Line-blanking interval 12±0.3µs 10.9±0.2µs
Interval between time datum (0H) and back edge of line-
blanking pulse 10.5µs 9.2 to 10.3 µs
Front porch 1.5±0.3µs 1.27 to 2.22µs
Synchronizing pulse 4.7±0.2µs 4.7±0.1µs
Build-up time of the line blacking pulse 0.3±0.1µs =/< 0.48µs
Build-up time of the line synchronizing pulse 0.2±0.1µs =/< 0.25µs
Start of sub-carrier burst 5.6±0.1µs 5.3(4.71 to 5.71)µs
Duration of sub-carrier burst 2.25±0.23 (10±1
cycles)µs 2.23±3.11 (9±1 cycles)µs
Electrical for PC
Video input signals Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input
impedance
Digital DVI-D TMDS, 600mV for each differential line, positive
polarity at 50 ohm input impedance
Synchronization input signals Separate horizontal and vertical synchronizations, polarity-free TTL
level, Composite
AC input voltage / frequency 90 to 264 VAC / 50 or 60 Hz + 2Hz
Physical Characteristics
Connector type 15-pin D-subminiature, blue connector; DVI-D, white connector
Signal cable type Analog: Detachable, D-sub, 15pin, shipped detached to the LCD
TV
Digital: Detachable, DVI-D, Solid pins, shipped detached from the
LCD TV
Dimensions: (without packing)
Height 448.0 mm (17.63 inches)
Width 758.0 mm (29.84 inches)
Depth 265.5 mm (10.45 inches)
Weight (LCD TV only) 13.8 Kg (30.4 lbs)
Weight (with packaging) 18.7 Kg (41.21 lbs)
Environmental
Temperature:
Operating 0°C to 35°C (32°F to 95°F)
Nonoperating Storage: 0 to 60°C (32°F to 140°F)
Shipping: -20 to 60°C(-4°F to 140°F)
Humidity:
Operating 10% to 80% (noncondensing)
Nonoperating Storage: 5% to 90% (noncondensing)
Shipping: 5% to 90%(noncondensing)
Altitude:
Power Management Modes
If you have VESA's DPMS compliance display card or software installed in your PC, the LCD TV can automatically
reduce its power consumption when not in use. This is referred to as 'Power Save Mode'*. If input from keyboard,
mouse or other input devices is detected by the computer, the LCD TV will automatically "wake up". The following
table shows the power consumption and signaling of this automatic power saving feature:
PC display power management mode
TV and Video Power Management Modes
* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.
ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, DELL has determined that this product
meets the ENERGY STAR® guidelines for energy efficiency.
Operating 3,657.6m (12,000 ft) max
Nonoperating 12,192 m (40,000 ft) max
Thermal dissipation 239BTU/hour (typical at PC model)
342 BTU/hour (typical at TV model))
Power Management Definition
VESA Modes Video H-sync V-sync Power Used LED color
ON Active Yes Yes 70W (typical) Green
OFF Blanked No No < 3 W Amber
NOTE: In Power Saving Mode, Press Any Key on Keyboard or Move Mouse.
Activate the computer and 'wake up' the LCD TV to gain access to the OSD.
Power management Definition
Display Video Power State Power
Used LED color
ON Active Always On 100W
(typical) Green
Stand by Blanked Off after 30minutes of no
signal < 3W Amber
Power switch off Active/Blanked Off < 1W OFF
This monitor is ENERGY STAR®-compliant as well as TCO '99 power management
Pin Assignments
15-pin D-Sub connector:
24
p
in di
g
ital-onl
y
DVI cable:
NOTE: This LCD TV automatically returns to normal operation when horizontal and vertical sync return, which
occurs when you move the computer's mouse or press a key on the keyboard.
Pin Number LCD TV Side of the 15-Pin
Side Signal Cable
1Red
2Green
3Blue
4GND
5Self test
6Red GND
7Green GND
8Blue GND
9+5V (supply form PC)
10 Sync GND
11 GND
12 Bi-directional data (SDA)
13 H. Sync
14 V. Sync (vclk)
15 Data clock (SCL)
Note: Pin 1 is at the top right.
Plug and Play Capability
You can install the LCD TV in any Plug and Play-compatible system. The LCD TV automatically provides the compute
r
system with its Extended Display Identification Data (EDID) using Display Data Channel (DDC) protocols so the
system can configure itself and optimize the LCD TV settings.
Back to Contents Page
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1T.M.D.S. Data 2- 9T.M.D.S. Data 1- 17 T.M.D.S. Data 0-
2T.M.D.S. Data 2+ 10 T.M.D.S. Data 1+ 18 T.M.D.S. Data 0+
3T.M.D.S. Data 2 Shield 11 T.M.D.S. Data 1 Shield 19 T.M.D.S. Data 0 Shield
4No Pin 12 No Pin 20 No Pin
5No Pin 13 No Pin 21 No Pin
6DDC Clock 14 +5V Power 22 T.M.D.S. Clock Shield
7DDC Data 15 Self test 23 T.M.D.S. Clock +
8No Connect 16 Hot Plug Detect 24 T.M.D.S. Clock -
Height-Adjustable Stand (HAS): Dell™ W2300 LCD TV User's
Guide
Attaching HAS • Cable Management • Tilt_Swivel • Vertical Adjustment • Removing HAS
Attaching HAS
Lay LCD TV on a flat, soft, and clean surface or use the foam cushion shipped with your LCD TV. Attach stand to LCD
TV by aligning tabs on stand to the LCD TV.
Cable Management
Run all cables through the provided cable sleeve and then run the sleeve (with cables) through the cable clip in the
back of HAS.
Tilt/Swivel
With the attached pedestal, you can tilt and/or swivel the LCD TV for the most comfortable viewing angle.
Vertical Adjustment
Press the Lock Down button at the bottom of the HAS to make any vertical adjustment. HAS travels vertically.
Removing HAS
Lay LCD TV on a flat, soft, and clean surface or use the foam cushion shipped with your LCD TV. Press the release
button, and pull up the base.
Attaching the Cables: Dell™ W2300 LCD TV User's Guide
Connecting Your PC • Connecting as a TV • Connecting your DVD/VCD/VCR/CATV Box • Connecting A/V outputs
Connecting your PC
CAUTION: Before performing any of the setup procedures listed below, read and follow the safety
instructions.
A. Connection through blue VGA & lime green audio cable
1. Connect one end of the blue VGA cable to the VGA plug on W2300, and connect the other end to the VGA
plug on your PC.
2. Connect one end of the lime green audio cable to the audio jack by the D-sub plug on W2300, and connect
the other end to the Audio jack on your PC.
OR
B. Connection through white DVI cable & lime green audio cable
1. Connect one end of the white DVI cable to the DVI plug on W2300, and connect the other end to the DVI
plug on your PC.
2. Connect one end of the lime green audio cable to the audio jack by the DVI plug on W2300, and connect the
other end to the audio jack on your PC.
Connecting as a TV
Cable TV • Antenna • TV to VCR
Cable TV
Antenna
1. If your Cable TV signal is a single, round cable (75 ohm), then you're ready to connect to the TV.
Connect the TV cable to the ANTENNA/CABLE plug on the TV.
2. If you have a cable converter box, connect the cable TV signal to the IN (put) plug on the converter,
connect the OUT(put) plug from the converter to the 75 (ohm) plug on the TV.
3. Verify that the On Screen Display (OSD) is set to Cable.
Note: The connecting cable for the converter is supplied by the Cable TV company.
