Dell PowerVault MD3220i Series Manual de usuario

Dell™ PowerVault™

MD3200i and MD3220i

RAID Enclosures

Getting Started

With Your System

Guide de mise en route

Introducao ao uso do sistema

Pasos iniciales con el sistema

Dell™ PowerVault™

MD3200i and MD3220i

RAID Enclosures

Getting Started

With Your System

Regulatory Model Series E03J and E04J

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data

if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and PowerVault are trademarks of Dell Inc.;

MicrosoftandWindowsServerareeithertrademarksorregisteredtrademarksofMicrosoftCorporation

in the United States and/or other countries; Red Hat and Red Hat Enterprise Linux are registered

trademarks of Red Hat, Inc. in the United States and other countries; SUSE is a registered trademark

of Novell, Inc. in the United States and other countries; VMwareis aregisteredtrademark ofVMware,

Inc. in the United States and/or other jurisdictions.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Regulatory Model Series E03J and E04J

February 2010 P/N TFKD1 Rev. A00

Contents 3

Contents

Before You Begin . . . . . . . . . . . . . . . . . . . . . 5

Completing the iSCSI Worksheet . . . . . . . . . . . . . 6

Other Documentation and Media You May Need . . . . . 7

Preparing the Host Server . . . . . . . . . . . . . . . . . 8

Supported Operating Systems . . . . . . . . . . . . 8

Additional NICs for iSCSI . . . . . . . . . . . . . . . 8

NIC Configuration. . . . . . . . . . . . . . . . . . . 9

Installation and Configuration. . . . . . . . . . . . . . . 9

Unpacking the System . . . . . . . . . . . . . . . . 9

Installing the Rails and System in a Rack . . . . . . 9

Connecting the Power Cable(s) . . . . . . . . . . 10

Securing the Power Cable(s) . . . . . . . . . . . . 10

Cabling Your Expansion Enclosure . . . . . . . . . 11

Turning On the Enclosure. . . . . . . . . . . . . . 11

Cabling Your Direct-Attached Hosts . . . . . . . . 12

Cabling Your SAN-Attached Hosts . . . . . . . . . 13

Installing the Bezel . . . . . . . . . . . . . . . . . 15

Installing the MD Storage Software . . . . . . . . 15

Enabling Premium Features (Optional) . . . . . . . 16

Locating Your Service Tag. . . . . . . . . . . . . . . . 16

NOM Information (Mexico Only) . . . . . . . . . . . . 17

Technical Specifications . . . . . . . . . . . . . . . . 17

4Contents

Getting Started With Your System 5

Before You Begin

Before setting up your Dell™ PowerVault™ MD32xxi RAID enclosure,

you must consider certain best practices to ensure that your RAID enclosure

operates at maximum efficiency and offers full redundancy (if required).

• It is recommended that you use a dedicated IP SAN for iSCSI data

transmission. Management traffic can be isolated on a separate

management network.

• Complete the iSCSI configuration worksheet before configuring iSCSI.

See "Completing the iSCSI Worksheet" on page 6. This worksheet gathers

physical network information in a single source.

• After completing the iSCSI worksheet, draw the configuration before

setting up the solution.

• Always configure redundant iSCSI data paths to provide alternate paths to

and from the host server should one of the data paths become disabled.

• If multiple NICs are installed on a host, it is recommeded that you use

different subnets for management and iSCSI data links.

• Throughout the network, always use a Category 5e (or higher)

Ethernet cable.

• Before connecting any cables between the host server and storage array,

physically label each port and connector.

• Always follow proper power-up and power-down procedures when cycling

power across the network. You must also ensure that critical network

components are on separate power circuits.

NOTE: The illustrations in this document show cabling for only one PowerVault

MD32xxi RAID enclosure in a SAN environment. The illustrations also show only

the default IP addresses for the PowerVault MD32xxi RAID enclosure. To cable

more than one PowerVault MD32xxi RAID enclosure in a SAN environment,

see the Deployment Guide.

6Getting Started With Your System

Completing the iSCSI Worksheet

IPv4 Settings

Mutual

CHAP Secret

Target CHAP

Secret

host server

PowerVault

MD32xxi

192.168.130.101 (In 0 default)

192.168.131.101 (In 1 default)

192.168.132.101 (In 2 default)

192.168.133.101 (In 3 default) 192.168.128.101 (management network port)

192.168.130.102 (In 0 default)

192.168.131.102 (In 1 default)

192.168.132.102 (In 2 default)

192.168.133.102 (In 3 default) 192.168.128.102 (management network port)

If you need additional space for more than one host server, use an additional sheet.

iSCSI port 1

iSCSI port 2

iSCSI port 3

iSCSI port 4

Management port

Static IP address (host server) Subnet mask Default gateway

___ . ___ . ___ . ___

NOTE: The host server can support up to four NICs.

Getting Started With Your System 7

NOTE: For information about the IPv6 worksheet, see the Deployment Guide.

Other Documentation and Media You May Need

WARNING: See the safety and regulatory information that shipped with

your system. Warranty information may be included within this document or

as a separate document.

NOTE: All PowerVault MD32xxi documents are available at

support.dell.com/manuals.

• The rack documentation included with your rack solution describes how

to install your system into a rack.

• The

Owner’s Manual

provides information about system features and

describes how to troubleshoot the system and install or replace system

components.

• The

Deployment Guide

provides information about installing and

configuring the software and hardware.

• The

CLI Guide

provides information about using the command line

interface (CLI) to configure and manage your storage array.

Static IP address (storage array) Subnet mask Default gateway

___ . ___ . ___ . ___

iSCSI controller 0, In 0

iSCSI controller 0, In 1

iSCSI controller 0, In 2

iSCSI controller 0, In 3

Management port cntrl 0

iSCSI controller 1, In 0

iSCSI controller 1, In 1

iSCSI controller 1, In 2

iSCSI controller 1, In 3

Management port cntrl 1

___ . ___ . ___ . ___

8Getting Started With Your System

•The

SMI-S Programmer’s Guide

provides information about using

the SMI-S provider and SMI-S programming.

• Any media that ships with your system that provides documentation

and tools for configuring and managing your system, including those

pertaining to the operating system, system management software,

system updates, and system components that you purchased

with your system.

NOTE: Always check for updates on support.dell.com/manuals and read the

updates first because they often supersede information in other documents.

Preparing the Host Server

Supported Operating Systems

• Microsoft

Windows Server

•RedHat

Enterprise Linux

•SUSE

Linux Enterprise Server

• VMware

NOTE: For the latest information on all supported operating system versions,

see the Support Matrix at support.dell.com/manuals.

Additional NICs for iSCSI

When installing additional NICs, it is recommended that:

• You use dedicated redundant storage networks for iSCSI traffic.

If a dedicated network is not feasible, isolate the iSCSI traffic from

general network traffic using virtual local area networks (VLAN).

• You use additional NICs dedicated for iSCSI traffic.

• The NICs must be added in pairs for redundancy (up to four NICs).

NOTE: A single NIC is also supported.
