Dell PowerVault E03J Series Manual de usuario

Dell™ PowerVault™

MD1200 and MD1220

Storage Enclosures

Hardware Owner’s

Manual

Regulatory Model: E03J Series and E04J Series

Regulatory Type: E03J001 and E04J001

book.book Page 1 Monday, December 7, 2009 4:51 PM

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, OpenManage, PowerEdge, and PowerVault are

trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Regulatory Model: E03J Series and E04J Series

Regulatory Type: E03J001 and E04J001

October 2009 Rev. A00

book.book Page 2 Monday, December 7, 2009 4:51 PM

Contents 3

Contents

1 About Your Enclosure . . . . . . . . . . . . . . . . 7

Front-Panel Features and Indicators . . . . . . . . . . . 7

Front-Bezel Features and Indicators . . . . . . . . . . . 9

Hard-Drive Indicator Patterns . . . . . . . . . . . . . . 11

Back-Panel Features and Indicators . . . . . . . . . . 12

Enclosure Management Module . . . . . . . . . . . . 13

Enclosure Failover When Two EMMs are

Installed. . . . . . . . . . . . . . . . . . . . . . . 16

EMM Thermal Shutdown . . . . . . . . . . . . . . 16

Enclosure Alarms . . . . . . . . . . . . . . . . . . 16

Power Indicator Codes . . . . . . . . . . . . . . . . . 17

Other Information You May Need . . . . . . . . . . . . 18

2 Operating Your Storage Enclosure . . . . . 19

Before You Begin . . . . . . . . . . . . . . . . . . . . 19

Cabling Your Enclosure . . . . . . . . . . . . . . . . . 19

Connecting the Enclosure . . . . . . . . . . . . . . . . 20

Changing Your Enclosure’s Operating Mode . . . . . . 25

Managing Your Storage Enclosure . . . . . . . . . . . 26

book.book Page 3 Monday, December 7, 2009 4:51 PM

4Contents

Downloading Firmware . . . . . . . . . . . . . . . . . 26

3 Installing Enclosure Components . . . . . 27

Recommended Tools . . . . . . . . . . . . . . . . . . . 27

Front Bezel (Optional) . . . . . . . . . . . . . . . . . . 27

Removing the Front Bezel. . . . . . . . . . . . . . 27

Installing the Front Bezel . . . . . . . . . . . . . . 28

Hard Drives. . . . . . . . . . . . . . . . . . . . . . . . 29

Removing a Drive Blank. . . . . . . . . . . . . . . 29

Installing a Drive Blank . . . . . . . . . . . . . . . 31

Removing a Hard Drive . . . . . . . . . . . . . . . 31

Installing a Hard Drive . . . . . . . . . . . . . . . 32

Removing a Hard Drive From a Hard-Drive

Carrier. . . . . . . . . . . . . . . . . . . . . . . . 33

Installing a Hard Drive Into a Drive Carrier . . . . . 35

Enclosure Management Module. . . . . . . . . . . . . 35

Removing an EMM Blank . . . . . . . . . . . . . . 35

Installing an EMM Blank . . . . . . . . . . . . . . 36

Removing an EMM . . . . . . . . . . . . . . . . . 37

Installing an EMM. . . . . . . . . . . . . . . . . . 39

Power Supply/Cooling Fan Module . . . . . . . . . . . 39

Removing a Power Supply/Cooling Fan Module . . 39

Installing a Power Supply/Cooling Fan Module . . 41

Control Panel . . . . . . . . . . . . . . . . . . . . . . . 42

Removing the Control Panel . . . . . . . . . . . . 42

Installing the Control Panel . . . . . . . . . . . . . 44

Backplane . . . . . . . . . . . . . . . . . . . . . . . . 44

Removing the Backplane . . . . . . . . . . . . . . 44

book.book Page 4 Monday, December 7, 2009 4:51 PM

Contents 5

Installing the Backplane . . . . . . . . . . . . . . 47

4 Troubleshooting Your Enclosure . . . . . . . 49

Safety First—For You and Your Enclosure . . . . . . . 49

Troubleshooting Enclosure Startup Failure . . . . . . . 49

Troubleshooting Loss of Communication . . . . . . . . 49

Troubleshooting External Connections . . . . . . . . . 49

Troubleshooting Power Supply/Cooling Fan Module . . 50

Troubleshooting Enclosure Cooling Problems . . . . . 51

Troubleshooting Enclosure Management Modules. . . 52

Troubleshooting Hard Drives . . . . . . . . . . . . . . 53

Troubleshooting Enclosure Connections . . . . . . . . 54

Troubleshooting a Wet Enclosure . . . . . . . . . . . . 54

Troubleshooting a Damaged Enclosure . . . . . . . . . 55

5 Getting Help. . . . . . . . . . . . . . . . . . . . . . . 57

Contacting Dell . . . . . . . . . . . . . . . . . . . . . 57

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

book.book Page 5 Monday, December 7, 2009 4:51 PM

6Contents

book.book Page 6 Monday, December 7, 2009 4:51 PM

About Your Enclosure 7

About Your Enclosure

Front-Panel Features and Indicators

Figure 1-1. Front-Panel Features and Indicators—Dell™ PowerVault™ MD1200

Figure 1-2. Front-Panel Features and Indicators—Dell PowerVault MD1220

book.book Page 7 Monday, December 7, 2009 4:51 PM

8About Your Enclosure

Item Indicator, Button, or

Connector

Icon Description

1 Enclosure status LED The enclosure status LED lights when

the enclosure power is on.

Lights blue during normal operation and

when the host server is identifying

the enclosure.

Blinks blue when a host server is

identifying the enclosure or when the

system identification button is pressed.

Lights amber when the enclosure is

turned on or is reset.

Blinks amber when the enclosure is in

the fault state.

2 Power LED The power LED lights when at least one

power supply is supplying power to

the enclosure.

3 Split mode LED The split mode LED lights when

the enclosure is in a split-mode

configuration.

If the LED is not lit, it indicates that

the enclosure is in a unified-mode

configuration.

4 System identification

button

The system identification button on the

front control panel can be used to locate

a particular enclosure within a rack.

When the button is pushed, the system

status indicators on the control panel

and the EMM blinks blue until the

button is pushed again.

book.book Page 8 Monday, December 7, 2009 4:51 PM

About Your Enclosure 9

Front-Bezel Features and Indicators

Figure 1-3. Front-Bezel Features and Indicators

5 Hard drives PowerVault MD1200—Up to 12 3.5-inch

SAS hot-swappable hard drives.

PowerVault MD1220—Up to 24 2.5-inch

SAS hot-swappable hard drives.

6 Enclosure mode

switch

When set in the top position, the

enclosure is configured in unified mode.

When set in the bottom position, the

enclosure is configured in split mode.

Item Indicator, Button, or

Connector

Icon Description

book.book Page 9 Monday, December 7, 2009 4:51 PM

10 About Your Enclosure

Item Indicator, Button, or

Connector

Icon Description

1 Enclosure status LED The enclosure status LED lights when

the enclosure power is on.

Lights blue during normal operation and

when the host server is identifying

the enclosure.

Blinks blue when a host server is

identifying the enclosure or when the

system identification button is pressed.

Lights amber when the enclosure is

turned on or is reset.

Blinks amber when the enclosure is in

the fault state.

2 Power LED The power LED lights when at least one

power supply is supplying power to

the enclosure.

3 Split mode LED The split mode LED lights when

the enclosure is in a split-mode

configuration.

If the LED is not lit, it indicates that

the enclosure is in a unified-mode

configuration.

book.book Page 10 Monday, December 7, 2009 4:51 PM
