Dell EMC Unity 480 Manual del propietario

Dell EMC Unity™All Flash and Unity Hybrid

Unity 480/F, Unity 680/F, Unity 880/F

Hardware Information Guide

302-005-520

REV 01

Published June 2019

Dell believes the information in this publication is accurate as of its publication date. The information is subject to change without notice.

THE INFORMATION IN THIS PUBLICATION IS PROVIDED “AS-IS.“ DELL MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND

WITH RESPECT TO THE INFORMATION IN THIS PUBLICATION, AND SPECIFICALLY DISCLAIMS IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. USE, COPYING, AND DISTRIBUTION OF ANY DELL SOFTWARE DESCRIBED

IN THIS PUBLICATION REQUIRES AN APPLICABLE SOFTWARE LICENSE.

Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be the property of their respective owners.

Published in the USA.

Dell EMC

Hopkinton, Massachusetts 01748-9103

1-508-435-1000 In North America 1-866-464-7381

www.DellEMC.com

2Unity 480/F, Unity 680/F, Unity 880/F Hardware Information Guide

Additional resources 5

DPE component descriptions 7

2U, 25-drive DPE component overview........................................................8

DPE front view............................................................................................. 9

System identification tags..............................................................10

DPE rear view.............................................................................................. 11

DPE embedded modules and 4-port cards...................................... 11

DPE I/O module types....................................................................14

DPE power supply.......................................................................... 16

Storage processor assembly internal components.......................................17

Technical specifications 19

Technical specifications............................................................................. 20

Dimensions and weight................................................................................21

Power requirements....................................................................................21

Operating environment requirements......................................................... 22

DPE airflow....................................................................................23

Environmental recovery.................................................................24

Shipping and storage requirements............................................... 24

Shock and Vibration.......................................................................24

Fire suppressant disclaimer........................................................... 25

Air quality requirements.................................................................25

Chapter 1

Chapter 2

CONTENTS

Unity 480/F, Unity 680/F, Unity 880/F Hardware Information Guide 3

CONTENTS

4Unity 480/F, Unity 680/F, Unity 880/F Hardware Information Guide

Additional resources

As part of an improvement effort, revisions of the software and hardware are

periodically released. Therefore, some functions described in this document might not

be supported by all versions of the software or hardware currently in use. The product

release notes provide the most up-to-date information on product features. Contact

your technical support professional if a product does not function properly or does not

function as described in this document.

Where to get help

Support, product, and licensing information can be obtained as follows:

Product information

For product and feature documentation or release notes, go to Unity Technical

Documentation at: www.emc.com/en-us/documentation/unity-family.htm.

Troubleshooting

For information about products, software updates, licensing, and service, go to Online

Support (registration required) at: https://Support.EMC.com. After logging in, locate

the appropriate Support by Product page.

Technical support

For technical support and service requests, go to Online Support at: https://

Support.EMC.com. After logging in, locate Create a service request. To open a

service request, you must have a valid support agreement. Contact your Sales

Representative for details about obtaining a valid support agreement or to answer any

questions about your account.

Special notice conventions used in this document

DANGER

Indicates a hazardous situation which, if not avoided, will result in death or

serious injury.

WARNING

Indicates a hazardous situation which, if not avoided, could result in death or

serious injury.

CAUTION

Indicates a hazardous situation which, if not avoided, could result in minor or

moderate injury.

NOTICE

Addresses practices not related to personal injury.

Note

Presents information that is important, but not hazard-related.

Additional resources 5

Additional resources

6Unity 480/F, Unity 680/F, Unity 880/F Hardware Information Guide

CHAPTER 1

DPE component descriptions

l2U, 25-drive DPE component overview............................................................... 8

lDPE front view.....................................................................................................9

lDPE rear view......................................................................................................11

lStorage processor assembly internal components.............................................. 17

DPE component descriptions 7

2U, 25-drive DPE component overview

The 25-drive DPE is two rack units (U), 8.9 cm (3.5 in.) high, 79.2 cm (31.2 in.) deep,

and includes slots for twenty-five 2.5-in. drives.

The DPE consists of the following components:

lDrives

lMidplane

lStorage processor assembly

lPower supply module

lEMI shielding

Drives

Each drive consists of one drive in a carrier. The drive carriers are metal and plastic

assemblies that provide smooth, reliable contact with the enclosure slot guides and

midplane connectors. Each carrier has a handle with a latch and spring clips. The latch

holds the drive in place to ensure proper connection with the midplane. Drive activity

and fault LEDs are located on the front of the enclosure.

SAS and SAS flash drives are supported. The drives are populated in the system from

left to right.

Note

The first four drive slots are reserved for system drives, and should not be removed.

You can visually distinguish between drive types by their different latch and handle

mechanisms and by type, capacity, and speed labels on each drive. You can add or

remove a drive while the DPE is powered on, but you should exercise special care

when removing modules while they are in use. Drives are sensitive electronic

components.

Midplane

The midplane separates the front-facing drives from the rear-facing SP assemblies. It

distributes power and signals to all components in the enclosure. The SP assemblies

and drives plug directly into the midplane.

Storage processor assembly

Each DPE contains two SP assemblies. The SP assembly is the intelligent component

providing the compute capability of the DPE. Acting as the control center, each SP

assembly includes status LEDs.

Storage processor assembly power supply module

Each SP assembly contains a power supply module that connects the system to an

exterior power source. Redundant power supplies can keep the entire DPE running if

one power supply fails. The power supplies include LEDs to indicate component status.

A latch on the module locks it into place to ensure proper connection.

EMI shielding

EMI compliance requires a properly installed electromagnetic interference (EMI)

shield in front of the DPE drives. When installed in cabinets that include a front door,

the DPE includes a simple EMI shield. Other installations require a front bezel that has

a locking latch and integrated EMI shield. Remove the bezel or shield to remove and

install the drives.

DPE component descriptions

8Unity 480/F, Unity 680/F, Unity 880/F Hardware Information Guide

DPE front view

On the front, the DPE contains the following elements:

lDrives in 2.5 in. carriers

lStatus LEDs

Figure 1 DPE front view

Table 1 DPE component locations

Location Description

SAS or SAS Flash drives

Drive fault LED

Drive ready/activity LED

DPE power on LED

Figure 2 DPE and disk drive LEDs

Table 2 DPE and disk drive LEDs

LED Location State Description

Disk drive fault Amber Fault has occurred.

Off No fault has occurred, normal

operation.

DPE component descriptions

DPE front view 9

Table 2 DPE and disk drive LEDs (continued)

LED Location State Description

Disk drive active Blue Disk drive activity.

Off Disk drive is powered off.

DPE fault/power Blue Power is on. No fault has

occurred, normal operation.

Amber Power is on. Fault has occurred

within the enclosure.

Off Power is off.

System identification tags

The Product Serial Number Tag (PSNT) and World Wide Name Seed are serialized

labels that allow customer support to track nested hardware material in the field.

Product Serial Number Tag

The PSNT for the 25-slot DPE is a black pull-out tag that is located between the

drives in slots 16 and 17.

Figure 3 PSNT location

World Wide Name (WWN) Seed Tag

The World Wide Name (WWN) Seed tag is a blue pull-out tag that is located between

the drives in slot 7 and 8.

Figure 4 WWN Seed tag location

DPE component descriptions

10 Unity 480/F, Unity 680/F, Unity 880/F Hardware Information Guide
